Cochlear™

Wireless Phone Clip

Quick Guide for CP900 Series users

Features of your Phone Clip

Enjoy hands-free calling direct to your CP900 Series Sound

Processor.

Hear your Bluetooth®-enabled navigation system.

Stream music from a Bluetooth-enabled device.

The Phone Clip can be easily attached to clothing. The built-in

microphone will pick up and transmit your voice, even if your phone

is several metres away.

Product overview Getting Started

Call pick-up/

hang-up button

Micro-USB connector

for charging

Microphone

inlet

Volume

control

10-30cm between mouth

and Phone Clip

Charging the battery

Plug one end of the included micro-USB charging cable into the

Phone Clip and the other into a computer, or into a power outlet via

the supplied adapter.

When the red LED indicator on top of the Phone Clip turns green

with a red blink every 2 seconds charging is complete.

Before you use your Phone Clip you should allow it to charge for

at least 3 hours, even if the indicator light shows a full charge. The

battery cannot be overcharged.

Note: The Phone Clip provides 6 hours of talk time or 80 hours of

standby time from a full charge.

Power

switch

(Not used with

CP900 series)

Phone Clip Quick Guide

Pairing with your CP900 Series Sound Processor

ASwitch off your CP900 Series Sound Processor. BSwitch on your Phone Clip and remove the silver cap.

Press the white pairing button on the Phone Clip once using the tip

of a pen or similar object.

While pairing mode is active, switch on your sound processor.

DThe LED will ﬂash yellow every two seconds and the Phone Clip will

now be in pairing mode for 20 seconds.

Switch on

Remove cap

Press the lower button.

A blue indicator light ﬂashes to show

that pairing has been successful.

Remove the Sound

Processor from your ear.

Press and hold the lower

button for two seconds.

Phone Clip Quick Guide

Light indicators (LED) on Phone Clip Connecting with your mobile phone

To receive or place phone calls with the Phone Clip, the Bluetooth®

functionality must be activated in your mobile phone. Your phone

might ask you to conﬁrm whether you would like to connect with the

Phone Clip after it is successfully paired.

If you have to connect manually, locate a list of “Paired Devices” in

your phone’s Bluetooth®menu. From this list, highlight “Hearing Aid

Phone” and select “Connect.”

You are now ready to use your Phone Clip.

On some phones you can also enable “Automatic Reconnection.”

Refer to your mobile phone’s user guide for instructions on how to

do this.

Tip! In most instances, a headset symbol on the main screen of your

mobile phone will conﬁrm that you have successfully connected.

The LED indicator at the top of your Phone Clip functions as a

multi-purpose user interface, providing information on the status

of the device.

Blinks Meaning

Normal operation (green)

Battery low (yellow)

Charging (red)

Fully charged – still connected to charger (red/green)

Ready for pairing with sound processor (yellow)

Ready for pairing with Bluetooth device (blue)

Bluetooth call active (blue)

Pairing with your mobile phone

ASwitch on your Phone Clip and remove the silver cap. BMake sure your mobile phone’s Bluetooth function is switched on.

Refer to your mobile phone user guide for instructions.

Press the blue Bluetooth pairing button on the Phone Clip once

to activate the pairing mode for 2 minutes.

During pairing mode the LED will turn blue.

DOn your mobile phone search for new Bluetooth devices and select

“Hearing Aid Phone” from the list.

EIf your mobile phone asks for a passcode, enter “0000” (four zeros).

FYour Phone Clip should now be paired with your mobile phone.

If your mobile phone asks which Bluetooth service you wish to

enable, select “Headset”.

Switch on

Remove cap

Phone Clip Quick Guide

ACE, Advance Off-Stylet, AOS, AutoNRT, Autosensitivity, Beam, Button, Carina, Clinicnet, Cochlear, コクレア , Codacs, Contour, Contour Advance, Custom Sound, ESPrit, Freedom, Hear now. And always, Hybrid, inHear, Invisible

Hearing, MET, MP3000, myCochlear, NRT, Nucleus, Nucleus in Chinese characters, Off-Stylet, SmartSound, Softip, SPrint, the elliptical logo and Whisper are either trademarks or registered trademarks of Cochlear Limited.

Ardium, Baha, Baha Divino, Baha Intenso, Baha PureSound, Baha SoftWear, DermaLock, Vistaﬁx and WindShield are either trademarks or registered trademarks of Cochlear Bone Anchored Solutions AB. Bluetooth is a registered

trademark of Bluetooth SIG.

532744 ISS6 SEP15

Support

For full details about the Phone Clip, please refer to the User Guide that was packaged with your Phone Clip, and the Wireless Accessory User Guide.

For full details about your Cochlear CP900 Series Sound Processor, please refer to its User Guide.

For further support and videos, visit the Cochlear website: www.cochlear.com

Using the Phone Clip

Managing calls with the call pick-up / hang-up button

Incoming calls:

To answer a call, press once.

To decline a call, double-click.

During a call:

To transfer a call started on your phone

to the phone clip, press once.

To put a call on hold, press and hold for

2 seconds.

To make a call:

To redial the last number, double-click.

To activate voice dialling, press and hold

for 2 seconds.

Stream music from your phone

You can use the Phone Clip to stream music from your mobile phone or

computer.

Connect the device to the Phone Clip using Bluetooth.

Start playing music on the device.

You hear the audio

streaming from

the device.

To stop streaming,

stop playing music

on the device.

Tip! To change the volume, use the

volume controls on the Phone Clip.

Cochlear Wireless Accessories:

Cochlear Bone Anchored Solutions AB Konstruktionsvägen 14, SE - 435 33 Mölnlycke, Sweden

Tel: +46 31 335 1461 Fax: +46 31 335 1460

Nucleus 6 System:

Cochlear Ltd (ABN 96 002 618 073) 1 University Avenue, Macquarie University, NSW 2109, Australia

Tel: +61 2 9428 6555 Fax: +61 2 9428 6352

Cochlear Ltd (ABN 96 002 618 073) 14 Mars Road, Lane Cove, NSW 2066, Australia

Tel: +61 2 9428 6555 Fax: +61 2 9428 6352

Regional Ofﬁces:

Cochlear Americas 13059 E Peakview Avenue, Centennial, CO 80111, USA

Tel: +1 303 790 9010 Fax: +1 303 792 9025

Cochlear Deutschland GmbH & Co. KG Karl-Wiechert-Allee 76A, 30625 Hannover, Germany

Tel: +49 511 542 770 Fax: +49 511 542 7770

株式会社日本コクレア（Nihon Cochlear Co Ltd）〒 113-0033 東京都文京区本郷2-3-7 お茶の水元町ビル

Tel: +81 3 3817 0241 Fax: +81 3 3817 0245

www.cochlear.com
