Cochlear Nucleus 7 Manuale utente
Nucleus®7
RemoteControl
User Guide
CR310
DRAFT ONLY FOR CLINICAL TESTING
ii NUCLEUS®7 REMOTE CONTROL USER GUIDE
The Cochlear™Nucleus®7 Remote Control (model number:
CR310) is a hand-held device for controlling the commonly used
functions of your Cochlear Nucleus 7 Sound Processor (model
number: CP1000).
The remote control allows you to:
• change programs
• turn volume or sensitivity (if available) up and down
• turn True Wireless™Accessories on and off
• turn telecoil on and off.
If you have two Nucleus 7 Sound Processors (bilateral), your
remote control can communicate with both processors at once.
This guide is intended for Cochlear implant recipients and their
carers using the Nucleus 7 Sound Processor. For more
information, refer to the Nucleus 7 Sound Processor User Guide.
Symbols used in this guide
NOTE
Important information or advice.
TIP
Time saving hint.
CAUTION (no harm)
Special care to be taken to ensure safety and
effectiveness. Could cause damage to equipment.
WARNING (harmful)
Potential safety hazards and serious adverse reactions.
Could cause harm to person.
DRAFT ONLY FOR USABILITY TESTING
1NUCLEUS®7 REMOTE CONTROL USER GUIDE
Nucleus 7 Remote Control
Other indicators on your remote control
Low battery in
remote control Accessory on
Telecoil on
Next
program button
Previous
program button
Telecoil
button
Program
Pin for
attaching
lanyard
On/Off
switch
Volume or
sensitivity up
button
Volume or
sensitivity down
button
Volume or
sensitivity
Processor(s)
paired
DRAFT ONLY FOR USABILITY TESTING
2NUCLEUS®7 REMOTE CONTROL USER GUIDE
Battery
CAUTION
Use ONLY disposable CR2032 or 5004LC 3V standard lithium
coin cell batteries in your remote control.
NEVER use rechargeable coin cell batteries or other battery
types.
DRAFT ONLY FOR USABILITY TESTING
3NUCLEUS®7 REMOTE CONTROL USER GUIDE
Travel
Your remote control transmits high frequency radio waves
when switched on. Switch it off before takeoff and landing.
DRAFT ONLY FOR USABILITY TESTING
4NUCLEUS®7 REMOTE CONTROL USER GUIDE
Pair
Pairing allows two devices to communicate with each other.
Your clinician may have already paired your remote control
with your processor. If not, you will need to pair it the first
time you use it.
If your remote control is not
paired to any processor, it
displays dashes (shown left)
and “blinks” when you press
buttons.
Pair your processor and remote control
1. Turn on your processor
and remote control.
They must both be
“awake” and on at all
times while pairing.
2. Place the coil on the
back of your
remote control.
DRAFT ONLY FOR USABILITY TESTING
5NUCLEUS®7 REMOTE CONTROL USER GUIDE
3. The remote control
will show pairing in
progress.
4. The remote control
then shows
successful pairing of
either left (L) or
right(R) processor.
5. If you have two
processors (bilateral),
repeat steps 2-4 for
your second processor.
DRAFT ONLY FOR USABILITY TESTING
6NUCLEUS®7 REMOTE CONTROL USER GUIDE
Wireless accessories
If you use Cochlear True Wireless™Accessories with your
processor, your remote control can be used to control the
wireless accessory and monitor its status.
NOTE
Before you can stream audio, you must first pair the wireless
accessory to your processor. See the True Wireless Accessories
User Guide for details.
To use a Mini Microphone or TV Streamer
1. To start streaming audio,
long-press the telecoil button.
The accessory icon will appear.
TIP
You can long-press the telecoil button again to select the
next paired wireless accessory.
2. To stop streaming audio,
short-press the telecoil button.
The accessory icon will
disappear.
NOTE
You use the controls on the Phone Clip to make and receive
calls.
DRAFT ONLY FOR USABILITY TESTING
7NUCLEUS®7 REMOTE CONTROL USER GUIDE
Telecoil
Your clinician can set up your processor with manual telecoil
so you can listen to room hearing loops.
You can not use telecoil at the same time as a wireless
accessory.
NOTE
We recommend you use a Cochlear Wireless Phone Clip to
make phone calls. See the True Wireless Accessories User Guide.
Turn telecoil on (if set up)
1. Short-press the telecoil button
once.
The telecoil icon will appear.
Turn telecoil off
1. Short-press the telecoil button
once.
The telecoil icon will disappear.
DRAFT ONLY FOR USABILITY TESTING
8NUCLEUS®7 REMOTE CONTROL USER GUIDE
Other information
Physical configuration
The remote control comprises:
• analogue and digital integrated circuits based on a
micro-processor design, with bidirectional wireless
communication capabilities
• buttons and a switch for operation of unit
• buttons for remote control of sound processor”
• a display for indicating system status and activity
• in-built coil sensor
• lanyard pin.
Materials
The remote control housing and buttons are made of
polycarbonate and acrylonitrile butadiene styrene (ABS). The
display is made of ABS.
Environmental conditions
CONDITION MINIMUM MAXIMUM
Storage & transport temperature -10° C (14° F) +55° C (+131° F)
Storage & transport humidity 0% RH 90% RH
Operating temperature +5° C (+41° F) +40° C (+104° F)
Operating relative humidity 0% RH 90% RH
Operating pressure 700 hPa 1060 hPa
DRAFT ONLY FOR USABILITY TESTING
