Code Alarm PROFESSIONAL SERIES Manuale utente

PROFESSIONAL

SERIES

Owner’s Guide

For Models:

CASEC

CA2LED5

IMPORTANT NOTE: The operation of the Security and Convenience System as described in this manual is

applicable to most vehicles. However, due to the conguration of some vehicles, some functions AND/OR

SAFETY PRECAUTIONS may not apply. Please see your installing dealer for more information.

Deluxe Vehicle Security and

Keyless Entry System

2caSEC/ca2LED5 4280834 Owners revA

Table of Contents

Using Your Remote Control.................................................................... 3

Arming the Security System .............................................................. 3

Passive Arming Bypass..................................................................... 3

Bypassing the Shock Sensor ............................................................ 3

Hidden Alarm Function...................................................................... 3

Disarming the Security System ......................................................... 3

Two Stage Door Unlock (optional)..................................................... 4

Activating Trunk Release (optional)................................................... 4

Activating AUX 1 (optional)................................................................ 4

Entering AUX Mode and Activating Additional AUX Outputs............. 4

Using the Progressive Car Finder Feature........................................ 5

Using the Personal Protection Alarm................................................. 5

Programmed Transmitter Notication................................................ 5

Valet Mode ........................................................................................ 5

User Selectable Notication Chirps................................................... 5

User Selectable LED ......................................................................... 6

Manually Overriding the Security System ......................................... 6

Carjack Mode .................................................................................... 6

Status LED, Light Flashes and Siren/Horn Indications ....................... 7

 Additional2-WayLEDRemoteControlNotications .......................... 8

Remote Control Buttons & Functions ................................................... 9

Replacing Remote Control Batteries................................................... 10

Warranty Information ............................................................................ 12

Arming the Security System

To arm the system, exit the vehicle, close all doors, then press the button. The

parking lights will ash 2 times, indicating the system is armed, has locked the doors

(if equipped and connected) and activated the starter disable feature. The LED status

indicator will blink steadily, once per second.

NOTE: The system is equipped with a feature called Silent Choice. If enabled, the

system requires a second press of the button to activate an audible arming

response from the vehicle.

Passive Arming Bypass

If passive arming is enabled on your system, while the system is disarmed, press

+ , the system will respond with 1 chirp and the LED will turn on. The security

system will remain in this temporally bypassed state for as long as you wish. To exit

passive bypass, press the or button and the system will return to normal status.

Bypassing The Shock Sensor

To arm the system and ignore the shock sensor press button, then within 5

seconds press + , the system will respond with 1 long chirp.

NOTE: The system will only change the shock sensor setting for one arm cycle and

will be defaulted back to normal operation the next time the system is armed.

Hidden Alarm Function

Press the button rst, within 3 seconds press the button to activate the hidden

alarm function. The security system will arm with “Hidden Alarm Function” in which the

siren / horn will be silenced if the system is triggered.

Disarming the Security System

To disarm the system press the button. The parking lights will ash 1 time,

indicating the system is disarmed and has unlocked the doors (if equipped and

connected).

NOTE: The system is equipped with a feature called Silent Choice. If enabled, the

system requires a second press of the button to activate an audible disarming

response from the vehicle. If your system is set up for 2 step unlock, a third press of

unlock will activate the audible response.

*Throughout this manual, ‘press’ refers to pressing for less than 1 second; ‘press and hold’ refers to pressing for more

than 2 seconds.

Using Your Remote Control

4caSEC/ca2LED5 4280834 Owners revA

Two Stage Door Unlock (Optional)

If this feature is enabled on your system, pressing the button one time will unlock

only the driver’s door. Press again within three seconds to unlock the remaining

doors.

Activating the Trunk Release Feature (Optional)

If this feature is enabled on your system, pressing and holding the button for 3

seconds will open the vehicle’s trunk or hatch.

Activating the AUX 1 Output (Optional)

If this feature is enabled on your system, pressing the and buttons

simultaneously will activate an optional feature. This feature can be programmed for a

wide range of functions like power window or sunroof automation, please consult your

installing dealer to determine the functionality of your system.

Entering AUX Mode and Activating the Additional AUX 2 - 5 Outputs (Optional)

To access the additional AUX outputs, AUX 2, AUX 3, AUX 4, and AUX 5, you must

rst enter the transmitters AUX Mode. This will “shift” the functions of the transmitter

buttons from their standard operation to control of the AUX outputs.

AUX Mode - 4 button transmitter: Press and Hold and for 2

seconds, the transmitter LED will ash 1 time. AUX Mode will remain active

for 15 seconds. AUX Mode will exit after 15 seconds of inactivity or by

pressing and again for 2 seconds, the transmitter LED will ash 2

times to conrm exit.

Using the Progressive Car Finder Feature

Press the button to locate your vehicle. The system will ash the parking lights

and sound 5 times at low volume, increasing in volume each time the button is

pressed.

Using the Personal Protection Alarm (Panic)

Press and hold the button for 3 seconds to activate the personal protection alarm.

During panic mode, the normal function of the transmitter buttons will be suspended.

The transmitter’s and buttons can be used to lock and unlock the door (if the

option is installed). To stop the alarm, press and hold the button on the transmitter

again for 3 seconds. The system will automatically stop after 30 seconds.

Programmed Transmitter Notication

As a security precaution each time the vehicle’s ignition is turn on the status LED

light with ash the number of transmitters programmed into the system. This helps

to identify unauthorized transmitters from accessing your vehicle. If you believe an

unauthorized transmitter has been programmed to your system, contact your installing

dealer for assistance.

Valet Mode

When valet mode is activated the status LED will light solid, and all security functions

will be disabled. To enter or exit valet mode simply follow the steps outlined below:

1. Turn the vehicle’s ignition ON.

2. Push and hold the programming/valet button.

3. The LED will turn on solid when valet mode is active

4. Release the programming/valet button.

User Selectable Notication Chirps

System ARM/DISARM chirps can be toggled ON or OFF without entering the

programming feature banks.

1. Turn the ignition ON then OFF.

2. Press and release the valet/programming button 3 times. The system

will respond with 1 chirp for ON or 2 chirps for OFF.

6caSEC/ca2LED5 4280834 Owners revA

Carjack Mode (Anti-Hijack Mode)

This feature must be turned on in system programming, please consult your installing

dealer.

Triggering Carjack mode: While the ignition is ON and press and hold + for 2

seconds, the parking lights will ash 1 time and the system will act as follows;

1. 50 seconds after being triggered the siren will chirp for 15 seconds,

during this 15 seconds you will be alerted to push the valet button to

turn off Carjack mode. If Carjack mode is not turned off at this time it

will advance to the next step.

2. Following the 15 second chirps (total time now 65 seconds) the siren

will go into full sound and the parking lights will start ashing.

3. 90 seconds after trigger in, addition to the siren and parking lights, the

system will activate the starter kill. THE SYSTEM WILL REMAIN IN THIS

STATE UNTIL THE BATTERY IS DEPLETED.

OVERRIDE THE SYSTEM TO TURN OFF CARJACK MODE: Turn the ignition OFF

then On and press the valet button within 10 seconds.

Manually Overriding the Security System

Your system can be disarmed without the use of the transmitter. This is necessary,

since you will need the ability to operate your vehicle if the transmitter is lost or its

battery fails. To by-pass the alarm system;

1. Open the vehicle door. The alarm will sound.

2. Turn the ignition key to the ON position.

3. Within 10 seconds, press and release the valet push button switch.

The alarm system will stop sounding and enter the (by-passed) mode. You can now

start and operate the vehicle normally.

User Selectable LED

This feature will control whether the LED is ON or OFF when the system is Armed/

Locked and can be toggled ON or OFF without entering the programming feature

banks.

1. Turn the ignition ON, OFF, ON, OFF.

2. Press and release the valet/programming button 3 times. The system

will respond with 1 chirp for ON or 2 chirps for OFF.

Status LED, Light Flashes, and Siren/Horn Indications

Status LED Flash Indications

LED Flashes Function

OFF Disarmed

Slow Flash Armed

Fast Flash Passive Arming Countdown

ON (Solid) Valet Mode

2 Flashes Zone 2 Trigger, Hood / Trunk

3 Flashes Zone 3 Trigger, Door

4 Flashes Zone 4 Trigger, Shock Sensor

5 Flashes Zone 5 Trigger, Ignition

Siren/Horn Chirp Indications

Chirps Function

1 Disarm

2 Arm

3 Door Ajar Upon Arming

4 Disarm / Triggered

5 Car Find

Parking Light Flash Indications

Flashes Function

1 Disarm

2 Arm

3 Disarm / Triggered

5 Car Find

8caSEC/ca2LED5 4280834 Owners revA

Additional 2-Way LED Remote Control Notications

Additional 2 Way LED Remote Control Notications / Responses

The 2 Way LED remote control responses outlined below are in addition to the normal

beep/LED ash that takes place upon pressing the buttons of the remote control.

Function Sounds / LED Flashes

Arm / Lock 2 Beeps, 2 Flashes

Arm - Door Ajar 3 Beeps, 3 Flashes

Disarm / Unlock 1 Beep, 1 Flash

Disarming / System Triggered 4 Beeps, 4 Flashes

Trunk Release 1 Beep / 1 Beep, 1 Flash if vehicle

was locked.

Valet Mode ON No Response

Valet Mode Off Melody

Trigger - Warn-Away Melody, 1 Flash

Trigger - Full Trigger Melody, Flashing

Panic Mode Trigger Melody, Flashing

Anti-Carjack Mode On No Response

Anti-Carjack Mode Off 1 Beep

Car Find Melody, 1 Flash

AUX Mode ON 1 Flash

AUX Mode OFF 2 Flashes

Low Battery 2 Beeps, 2 Flashes when button is

pressed

Remote Control Buttons & Functions

4-Button

TransmitterLock Unlock Car Find /

Panic TrunkOperation Method

Lock X Press and Release

Unlock XPress and Release

2 Step Unlock XPress and Release 2 times

Trunk XPush and Hold (3 Sec)

Car FinderX

Press and Release

PanicX

Push and Hold (3 Sec)

AUX 1XXPush and Hold (3 Sec)

Shock Bypass XX Press and Release Lock then

Press Lock + Car Find

Hidden AlarmX XPress and Release Car Fnd then

Press Lock

Passive Arming

Bypass XX Press and Release

Enter AUX Mode XX Press and Hold Find + Trunk

Transmitter LED flashes 1 time

AUX 2X Push and Hold (3 Sec)

AUX 3X Push and Hold (3 Sec)

AUX 4X

Push and Hold (3 Sec)

AUX

Push and Hold (3 Sec)

AUX 2, 3, 4, 5 - Access in AUX Mode

10 caSEC/ca2LED5 4280834 Owners revA

Replacing Remote Control Batteries

4 Button Remote Control - Model CAT4M & CATMLED

The batteries inside each remote control should last approximately 1 year for the CAT4M

and 6 Months for the CATMLED under normal use. When the batteries become weak

you will notice the remote control range (the distance from the vehicle the remote control

will work) deteriorate and the small LED on the remote control will dim. Additionally, the

CATMLED will ash the LED 2 times each time a button is pressed when the battery is

low. To replace the remote control batteries:

1. Remove 1 screw then disassemble the halves of the remote

control by unsnapping the back of the case.

2. Remove the old battery, observing the +/- symbols on the

batteries and replace with a new battery.

3. Reassemble the halves of the remote control and reinstall 1 screw.

4. Test operation of the remote control.

Altri manuali per PROFESSIONAL SERIES

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Code Alarm Allarme auto

Code Alarm

Code Alarm CATX630 Istruzioni operative

Code Alarm

Code Alarm CA-120 Manuale utente

Code Alarm

Code Alarm CA 6551 SST Manuale utente

Code Alarm

Code Alarm CA 310 Manuale utente

Code Alarm

Code Alarm Professional caSECRS Manuale utente

Code Alarm

Code Alarm CATX520 Istruzioni operative

Code Alarm

Code Alarm CATX120 Istruzioni operative

Code Alarm

Code Alarm CA 170 Manuale utente

Code Alarm

Code Alarm CA 1550 Manuale utente

Code Alarm

Code Alarm CATX2LED Istruzioni operative

Code Alarm

Code Alarm CA 680 Manuale utente

Code Alarm

Code Alarm CATX2LCD Istruzioni operative

Code Alarm

Code Alarm caSEC Manuale di installazione e funzionamento

Code Alarm

Code Alarm CA 1550 Manuale utente

Code Alarm

Code Alarm CA 420 Manuale utente

Code Alarm

Code Alarm ca1554 Manuale utente

Code Alarm

Code Alarm Ca 1053 Manuale utente

Code Alarm

Code Alarm CA 421 Manuale utente

Code Alarm

Code Alarm CATX510 Istruzioni operative

Code Alarm

Code Alarm CA-330 Manuale utente

Code Alarm

Code Alarm ca6355E Manuale utente

Code Alarm

Code Alarm CATX610 Istruzioni operative

Code Alarm

Code Alarm Power Elite PC 4100 Manuale utente

Code Alarm

Code Alarm CA-670 Manuale utente

Manuali Allarme auto popolari di altre marche

Clifford

Clifford 3606X Manuale utente

Ultra Start

Ultra Start 2500M SERIES Manuale utente

Ultra Start

Ultra Start 650 Series Manuale utente

Audiovox

Audiovox Prestige Platinum+ APS-511C Manuale utente

Sparkrite

Sparkrite SRA8 Manuale utente

Viper

Viper 4708V Manuale utente

Federal Signal Corporation

Federal Signal Corporation Pathfinder Siren Series Manuale

Falcon

Falcon Predator XL3 Guida utente

Audiovox

Audiovox Auto Security XR91 Istruzioni operative

Clifford

Clifford Sabre II Manuale utente

CrimeStopper

CrimeStopper CS-8717 Guida rapida

Ultra Start

Ultra Start 450 SERIES Manuale utente

Scytek electronic

Scytek electronic Vectra X3 Manuale utente

Excalibur

Excalibur AL-1860-EDPB Manuale utente

Clifford

Clifford CYBER 2 Manuale utente

Gemini

Gemini 7057 Manuale utente

FlashLogic

FlashLogic FLRSBA PRESTIGE Manuale utente

Magicar

Magicar FAI-440 Manuale utente
