Owner's Manual

Remote Vehicle Control System

IMPORTANT NOTE:The operation of the Power Code as described in this

manual is applicable to most vehicles. However, due to the engine type

and configuration of some vehicles (i.e. diesel engines), some functions

AND/OR SAFETY PRECAUTIONS may not apply.Please see your

installing dealer for more information.

PC 7400

Keyless Entry & Remote

Start System

101515-5

Table of Contents

Features and Benefits of the PowerCode PC 7400TM ..................... 3

Using Your Remote Transmitter .............................................. 4

Locking the Vehicle

Starter Disable

Unlocking the Vehicle

Two-Stage Door Unlock

Activating the Trunk Release Feature

Turning on the Vehicle Headlights

Using the Car Finder Feature

Personal Protection Alarm (Panic)

Remote Start / Stop Feature

UsingYour Remote Starter ...................................................... 6

Starting Your Vehicle

If your vehicle stalls or does not start

Remote Start Safety Features

Entering the Vehicle While it is Running via Remote Start

Pre-Heating or Pre-Cooling the Interior of the Vehicle

Turning on the Rear-Window Defroster

Using the “Quick-stop” Feature

Automatic Convenience Options ............................................ 7

System Maintenance ................................................................ 7

Changing the Remote Control Battery

Adding Remote Controls to Your System

Deleting Lost or Stolen Remote Controls from Your System

BasicTroubleshooting .............................................................. 9

Emergency Disarm Procedure .......................................... 10

Emergency Disarm Button Location

Installer Programmed Options

Your Code Systems, Inc. Limited Lifetime Warranty........... 11

Features and Benefits of the PowerCode PC 7400

Two Easy-to-Use Weather-Resistant Remote Controls

The remote controls included with the PowerCode PC 7400TM utilize

durable, moisture resistant cases and sealed rubber buttons for

reliability and long life. Rolling code technology prevents the

transmitter signals from being duplicated. The button functions are

clearly labeled to make the PowerCode PC 7400TM simple to operate.

Starter Disable

The PowerCode PC 7400TM protects your vehicle from theft by

disabling the starter when the vehicle is locked.

Remote Keyless Entry

The PowerCode PC 7400TM conveniently locks and unlocks vehicle

doors and opens the trunk or hatch by remote control.*

Personal Protection Features

Remote Panic Alarm, Headlight Control, Illuminated Entry,

and Car Finder are among an array of features that enhance

personal safety.**

Remote Start

The PowerCode PC 7400TM allows you to warm up your vehicle

and preheat or pre-cool the interior with the press of a button on

the remote control.

PowerRange

Antenna

This long-range antenna allows you to operate the PowerCode PC

7400TM from distances of up to 1/8mile. Remote-start your vehicle

from the safety of your home, apartment or office building.

* If vehicle is equipped with power door locks and they are connected to the alarm system by your installer.

** Mayrequireadditional connections, components, and/orcharges. See your installerfordetails.

* Throughoutthismanual, ‘press’ refers to pressingforless than 1 second; ‘pressandhold’ refers to pressing

formore than 1 second.

†Ifyou have chosen the SilentArmingOption, the horn willnotsound when locking or unlockinguntil the

appropriatebutton is pressed asecond time.

Press to LOCK the

Vehicle Doors*

Press and hold to turn on

headlights

Press for Car Finder

Press and Hold for

Panic Alarm

Press to UNLOCK

Vehicle Doors

Press LOCK then

Press START within 2

seconds for Remote

Start/Stop

Press to turn on Rear

Defroster*

Locking theVehicle Doors

To lock the doors, exit the vehicle, close all doors, then press* the

LOCK button. The status indicator (red warning light on the dash) will

blink steadily, once per second, if equipped.

Unlocking theVehicle Doors

To unlock the vehicle, press the UNLOCK button. The horn will “honk”

and the parking lights will flash once, and the doors will unlock.

The courtesy light will turn on for 1 minute, or until the vehicle is started.

Using Your Remote Transmitter

Press for two-car

operation (SHIFT)

Press and Hold

to open trunk

UsingYour Remote Transmitter

(cont.)

Two-Stage Door Unlock

If this feature is enabled on your system, pressing UNLOCK one time

will unlock only the driver’s door. Press UNLOCK again within 1

minute to unlock all doors.

Activating theTrunk Release Feature

Press and hold TRUNK to open the vehicle trunk or hatch (if equipped

and connected). If this button is used to operate another accessory,

the accessory will stay active for as long as the button is held.

Turning on theVehicle Headlights

Press and hold the LOCK button to turn on the vehicle headlights.

The lights will stay on for 20 seconds, or until LIGHTS is pressed again.

Using the Progressive Car Finder Feature

Press FIND on the remote control to locate your vehicle.The horn will

emit five short “honks” at low volume, increasing in volume each of

three times the button is pressed.

Personal Protection Alarm (Panic)

Press and hold the PANIC button to activate the vehicle horn and

parking lights for 30 seconds. (If the vehicle horn is connected, the

horn will “honk” for 30 seconds.) Press any remote control button to

turn off the Panic alarm.

Remote Start / Stop Feature

Press LOCK, then press START within 2 seconds on the remote control.

If all safety parameters are correct, the engine will start within 5 seconds

(diesel engines will take longer.) Press and hold START again to turn

off the vehicle. (Turn to page 6 for more on remote start features.)

Using Second Car Mode

If this feature is enabled, one transmitter will control two vehicles

equipped with a Power CodeMsystem. To operate the second vehicle,

press the shift button, then within two seconds, press the desired

function button.

UsingYour Remote Starter

StartingYourVehicle

The remote start function is activated by pressing LOCK and then

pressing START within 2 seconds on the remote control.The system

will check the vehicle to ensure that it is safe to start, and if all safety

parameters are correct, the engine will start within 5 seconds (diesel

engines will take longer.) Press and hold START again to turn off

the vehicle.

If your vehicle stalls or does not start...

If the vehicle stalls or does not start, the PowerCode PC 7400TM will

pause 5 seconds, then try 3 more times to start the vehicle (a total of

four attempts).The system pauses 5 seconds between each start

attempt. If the vehicle does not start after the fourth attempt, the

PowerCode PC 7400TM will abort the start process.

Your vehicle can be started by remote control whether the vehicle is

locked or unlocked.

Remote Start Safety Features

For safety and security reasons, the PowerCode PC 7400TM will shut

off the vehicle during remote start if any of the following occur:

• The vehicle hood is opened

• The brake is pressed before the vehicle ignition is turned on

with the key

• The engine reaches 3 times its normal idle*

As a safety precaution, the vehicle will shut off if left unattended for 12

or 25 minutes, depending on the time preset by your installer.

Entering theVehicleWhile It is Running via Remote Start

1.Press UNLOCK to unlock the door(s) and turn off the starter

disable (if it is not already off).

2.Enter the vehicle. Do not press the brake pedal.

3.Insert the key into the ignition and turn to the ON position.

4.Press the brake pedal. The remote starter disengages and the

vehicle will operate normally.

Pre-Heating or Pre-Cooling the Interior of theVehicle

Before exiting the vehicle, set the temperature controls to the desired

setting and operation. After the PowerCode PC 7400TM starts the

vehicle, the heater or air-conditioning will activate and heat or cool

the interior to your setting.

Turning on the Rear-Window Defroster (if connected)

While the vehicle is running via remote start, press DEFRST on the

remote control. The vehicle defroster will activate and run for 10

minutes, or for your vehicle’s preset time limit.

UsingYour Remote Starter

(cont’d)

Using the“Quick-stop”Feature

If you want to make a short stop and leave your vehicle running (to keep

the interior warm or cool, for instance), the quick stop feature allows you

to do this while keeping your vehicle secure and your keys with you.

To engage quick stop:

1.Stop the vehicle and place the transmission in PARK.

2.With your foot off the brake pedal, press ARM, then press START

within 2 seconds on the remote control.The parking lights will turn

on, indicating that the vehicle is now running via remote start.

3.Remove the keys from the ignition and exit the vehicle.

Press LOCK to lock the vehicle doors if desired.

Note: Do not leave children or animals unattended in the vehicle

when using the quick stop feature.

Automatic Convenience Options

The PowerCode PC 7400TM performs a variety of automatic functions to

enhance security and comfort. Some of these features are programmable

at the time of installation. Please see your installer for further details.

Illuminated Entry

When the system is UNLOCKED, the vehicle courtesy lights will turn on

for 1 minute, or until the vehicle is started or the system is re-locked.

Illuminated Exit

When turning ignitioin off, the vehicle courtesy lights will turn on for 1

minute, or until the PowerCode PC 7400TM is armed.

Ignition Lock

If all doors are closed and the vehicle is started with the key, the doors

will automatically lock.

Ignition Unlock

When removing the key from the ignition, the doors will automatically unlock.

System Maintenance

Changing the Remote Control Battery

The two 3-v lithium batteries (CR2016) supplied in your remote

control should last approximately one year, depending on usage.

When the battery begins to weaken, you will notice a decrease in

range, or the distance from your vehicle that your remote transmitter

will operate. Follow the instructions below to change the remote

transmitter battery.

1.Insert the edge of a coin into the slot at the side of the remote

control.Twist the coin to pry the remote control halves apart.

2.Remove the old batteries and replace with new ones. Be sure

to observe the (+) and (-) signs in the battery compartment.

3.Carefully snap the case halves back together, then test the

remote control.

Adding Remote Controls toYour System

The PowerCodeTM has the ability to operate from up to four (4) remote

controls. Follow these instructions to add a remote control to your

system.

1. Make sure the system is unlocked and the ignition is off.

2. Open the driver’s door.

3. Turn vehicle ignition on.

4. Press and hold emergency override button.

After 15 seconds, the horn will sound three (3) times.This

indicates that the unit has entered the remote control

programming mode.

5. Release the button.

6. Press the LOCK button (button 1) on the remote control to be

programmed.

The horn will sound once, indicating that the system has

“learned” that remote control.

7. Repeat step 6 for any additional remote controls.

8. Turn the vehicle ignition off to exit the programming mode.

Test all remote controls to ensure that they work properly.

Deleting Lost or Stolen Remote Controls fromYour System

If one of your remote controls is lost or stolen, follow these instructions

IMMEDIATELY to remove the control code from your system.

1. Have all remaining remote controls available.

2. Enter the control programming mode by following steps 1 - 5

Adding Remote Controls toYour System

3a.If you have only one remaining remote control, press the

LOCK button on that remote control four (4) times, pausing

at least 1 second in between each press. The horn must “honk”

each time you press the LOCK button.

3b.If you have two remaining remote controls, press the LOCK

button on each remote control two (2) times, pausing at least

1 second in between each press. The horn must “honk” each

time you press the LOCK button.

3c.If you have three remaining remote controls, press the

LOCK button on one remote control twice, then press the

LOCK button on the remaining remote control once.Pause at

least 1 second in between each press.The horn must “honk”

each time you press the LOCK button.

4. Turn the vehicle ignition off to exit the programming mode.

When you are finished, the lost or stolen remote control will

no longer operate your system.

UsingYour Remote Starter

(cont’d)

Basic Troubleshooting

This section outlines some of the basic issues you may experience

while becoming used to the PowerCode PC 7400TM. If you have a

problem that is not covered by this section, please consult your installer.

motpmySmotpmySmotpmySmotpmySmotpmyS melborPmelborPmelborPmelborPmelborP noituloSnoituloSnoituloSnoituloSnoituloS

seodlortnocetomeRkrowton

yrettabdaedrokaeW

tonlortnocetomeR demmargorp

yrettabegnahC

etomermargorP )8egap(lortnoc

tonlliwmetsyS tratsetomer neposidooH

desserpsiekarB

doohesolC

ekarbesaeleR

Emergency Disarm Procedure

If your remote control is lost or fails to function, use this procedure to

disarm the PowerCode PC 7400TM and start your vehicle.

1.Use the keys to enter the vehicle.

2.Insert the key into the ignition and turn to the ON position.

3.Locate and press the emergency override button.

The Starter Disable will turn off and then you will be able to

start your vehicle.

Your Emergency Disarm Button is located:

Installer Programmed Options

Ignition On Door Lock ON OFF

Ignition Off Door Unlock ON OFF

Illuminated Entry/Exit ON OFF

Siren/Horn Chirps ON OFF

Car start Run Time 12 min. 25 min.

Car Start Button Single button 2-button start

Light/AUX1 Output Duration_____________________

Defrost/AUX2 Output Duration_____________________

FCCCOMPLIANCE

This device complies with Part 15 of the FCC rules and with RSS-210 of Industry

Canada. Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including any interference that

may cause undesired operation.

Warning!

Changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

Indice

Altri manuali Code Alarm Avviamento remoto

Code Alarm

Code Alarm CA 5055 Manuale utente

Code Alarm

Code Alarm CA 411 Manuale utente

Code Alarm

Code Alarm Professional Series CA6555 Manuale utente

Code Alarm

Code Alarm CA-520 Manuale utente

Code Alarm

Code Alarm PROFESSIONAL SERIES Manuale utente

Code Alarm

Code Alarm Professional Series CA 5050 Manuale utente

Code Alarm

Code Alarm CA 4055 Manuale utente

Code Alarm

Code Alarm CA2LCD5 Manuale utente

Code Alarm

Code Alarm Professional Series CA 1050 Manuale utente

Code Alarm

Code Alarm Professional ca5054 Manuale utente

Code Alarm

Code Alarm CA 5150 Manuale utente

Code Alarm

Code Alarm CA 421 Manuale utente

Code Alarm

Code Alarm CA 4051 Manuale utente

Code Alarm

Code Alarm ca 4552 Manuale utente

Code Alarm

Code Alarm PROFESSIONAL SERIES Manuale utente

Code Alarm

Code Alarm PROFESSIONAL SERIES Manuale utente

Code Alarm

Code Alarm ca 1051 Manuale utente

Code Alarm

Code Alarm ca6553 Manuale utente

Code Alarm

Code Alarm ca5154 professional Series Manuale utente

Code Alarm

Code Alarm CA 5150 Manuale utente

Code Alarm

Code Alarm CA-550 Manuale utente

Code Alarm

Code Alarm SRT 9000 Manuale utente

Code Alarm

Code Alarm ca4053 Manuale utente

Code Alarm

Code Alarm Elite ca6555E Manuale utente

Manuali Avviamento remoto popolari di altre marche

AstroStart

AstroStart 803U Manuale utente

Durite

Durite 0-649-20 Manuale

EINHELL

EINHELL BT-PS 1000 Manuale

Linear

Linear ACCESS AK-21 Specifiche tecniche

Soundstream

Soundstream TARANTULA RS.2 Manuale utente

Jaycar Electronics

Jaycar Electronics MB3752 Manuale utente

Ultra Start

Ultra Start 72 Series Manuale utente

ADS

ADS FLASHLOGIC FLRSVW1 Manuale utente

Selecta

Selecta JS012 Manuale utente

Black Widow Security

Black Widow Security BW RAS 400 Manuale utente

Vector

Vector Power City DK080706 Supplemento

Ozito

Ozito OJS-800 Manuale utente

Profi-Partner

Profi-Partner 46387 Manuale utente

EZ STARTER

EZ STARTER EZ-45 Manuale utente

Viper

Viper 4204 Manuale utente

Essex Electronics

Essex Electronics KE-1701 Manuale utente

EINHELL

EINHELL EGS 3600 Manuale

Rooboost

Rooboost RB-1750WP Manuale utente
