Codonics Virtua Ink Cartridge Guida di riferimento



sáêíì~=fåâ=`~êíêáÇÖÉë

Virtua

Ink Cartridges (color and black) are optimized for use

with

the Virtua Medical Disc Publisher. The ink cartridge

design is fully integrated with Virtua to provide superior

image quality as well as active ink-level monitoring. nly

approved/recommended sources of Virtua Ink Cartridges

should be used with the Virtua Medical Disc Publisher to

insure labeling integrity.

råé~ÅâáåÖ

Each ink cartridge package is labeled with a "Best By" date.

Cartridges can be used for up to 6 months after the "Best By"

date.

◆

Do not remove the ink cartridge from package or foil

pouch until ready for use.

e~åÇäáåÖ

◆

The ink cartridge should only be held by the sides once it

has been removed from the foil pouch.

píçê~ÖÉ

Avoid using or storing ink cartridges in an environment

with high temperature and humidity which may cause

damage to the cartridge and ink.

◆

Storage: 1 to 43°C (34-110°F); RH 5-80% Non-

Condensing.

◆

perating: 15 to 30°C (59-104°F); RH 20-80% Non-

Condensing.

◆

Shipping: Sea Level to 5790m, Temp -40 to 60°C (-40 to

140 °F); RH 5-100% Non-Condensing not to exceed 24 hr

period.

fåëí~ääáåÖ=fåâ=`~êíêáÇÖÉë

1. Make sure the Virtua Medical Disc Publisher is not

recording/printing a disc.

2. pen the Virtua cover.

3. With the cover open, press the ink cartridge button to

move the ink cartridge carrier to the load position.

4. pen the ink carrier (purple cover for color on right side;

gray for black on left side) by pressing on the blue lever,

and if applicable, remove the existing ink cartridge from

the carrier.

Note: For proper operation on older Virtua models, a

color ink cartridge must be loaded at all times, even if

only using black ink. Please contact Codonics Technical

Support for further details.

Note: Recorders with serial numbers beginning with 84

or 101 support one tri-color ink cartridge. Black ink is not

supported in these models.

Note: Recorders with serial numbers beginning with 83

use separate ink tanks for each color. See Virtua Ink

Replacement Technical Brief (901-594-00x) for details on

replacing ink with these Recorder models.

WARNING! Do not touch the copper area of the ink

cartridge.

Note: Pressing the ink button is not required on 84-series

Recorders. n these models, the ink carriage moves to

the load position automatically when the top cover is

opened..

Note: 84-series and 101-series Recorders have only one

ink carrier, which uses color ink only. n these models,

the ink carrier cover and lever is black.

qÉÅÜåáÅ~ä=_êáÉÑ

Codonics Virtua

Ink Cartridges

All manuals and user guides at all-guides.com



Get it all with just one call

1-800-444-1198

All registered and unregistered trademarks are the property of their respective

owners. Specifications subject to change without notice.

Patents: www.codonics.com/ip/patents.

17991 Englewood Drive

Middleburg Heights, OH

44130 USA

+1.440.243.1198

+1.440.243.1334 Fax

Email info@codonics.com

www.codonics.com

Codonics Trading Co, Ltd.

317 Xianxia Rd. Building B

Unit 1412

Changning Dist., Shanghai

P.R. China, 200051

86-21-62787701

86-21-62787719 Fax

Codonics Limited KK

AQUACITY 9F,

4-16-23, Shibaura

Minato-ku, Tokyo,

108-0023 JAPAN

81-3-5730-2297

81-3-5730-2295 Fax

5. Remove the ink cartridge from the white box. Carefully

open the foil pouch from the bottom and remove the ink

cartridge.

6. Carefully and slowly remove tape from the ink cartridge

print head.

7. Insert the new ink cartridge with tape removed into the

carrier, copper end first.

8. Close the ink cartridge cover.

9. Close the Virtua Cover.

mêáåíáåÖLrë~ÖÉ

◆

Printed discs should be allowed to dry after printing.

Ideally, the printable surface should be allowed to dry

for three minutes before handling.

◆

If manually labeling a disc, write only on the label side

using a soft, felt-tip marker.

lêÇÉêáåÖ=fåÑçêã~íáçå

qÉÅÜåáÅ~ä=pìééçêí

For questions or problems with Codonics

Virtua Ink

Cartridges, please contact Codonics Technical Support.

8:30AM - 5:30PM EST, Monday-Friday (U.S. holidays

excluded)

Phone: +1.440.243.1198

Email: support@codonics.com

Website: www.codonics.com

WARNING! Never use a ballpoint pen or hard-tipped

writing instrument.

`~í~äçÖ=

kìãÄÉê

fíÉã pìééçêíÉÇ=

jçÇÉäë

1VCX-LR833 Codonics Type 1

Virtua Color

Cartridges, 4 each

81, 82, and 100-

series Recorders

1VCX-AR833 Codonics Virtua

Black Cartridges,

4 each

81 and 82-series

Recorders

1VC2-LR233 Codonics Type 2

Virtua Color

Cartridges, 4 each

84 and 101-series

Recorders using

version 5.2.1 or

greater software.

1VCX-WR833 Codonics Virtua

Black Ink

Cartridges, 4 each

83-series Recorders

1VCX-YR833 Codonics Virtua

Yellow Ink

Cartridges, 4 each

83-series Recorders

1VCX-CR833 Codonics Virtua

Cyan Ink

Cartridges, 4 each

83-series Recorders

1VCX-MR833 Codonics Virtua

Magenta Ink

Cartridges, 4 each

83-series Recorders
