COLOP e-mark Create Manuale utente

Tips &

Tricks

Content

1Explanation video

2What can you do with the e-mark®create?

3e-mark®create app

4How to setup the e-mark®create

5Printing at a glance

6How to use the app

7Free additional template designs

8Sharing imprints

9Printing 2 or 3 lines

10 Continual printing

11 Printing using the Ribbon Guide

12 Positioning of the imprint

13 Printing direction

14 Printing using the Ruler

15 Printing directly on various surfaces

16 Automatic print head cleaning

17 Manual print head and docking station cleaning

17.1 Start print head cleaning in the app

17.2 Clean the print head and docking station

18 Ink cartridge and colours

19 e-mark®create sounds

20 Reset the e-mark® create

21 How to make a backup

22 FAQs & Customer Helpline

Explanation video

What can you do

with the e-mark®create?

Textile & Lifestyle

Home & Gardening

Spring Feelings

Love & Valetine

4 5

e-mark®create app

How to setup

Printing at a glance

The e-mark®create can be used with the e-mark®create app

on phones and tablets with either Android 7.0 and iOS 11 or higher.

Download here getemarkcreateapp.colop.com

the e-mark®create

Select New Imprint in the app menu (by clicking on the 3 horizontal line icon top left)

Choose Start without template, either 1,2 or 3 lines, or select a pre-made template from your

preferred category

Arrange or change your artwork in the editor

Once your design is ready to go, select the e-mark®create icon in the top right corner

The e-mark®create will beep and the app will indicate when your print has been received

Simply swipe the device either to the left or right to print your design

A short beep indicates that the imprint is done

Assemble your e-mark®create according to the Quick Setup Guide, which you received along

with your device

Pay attention that the Wi-Fi on your phone or tablet is switched on

Install the e-mark®create app and open it

Select your preferred language and click next

Accept the Wi-Fi information and click continue

Now enter the SSID and password that came with your e-mark®create (to be found on

the Quick Setup Guide) and click connect

On iOS devices you will be asked to join the Wi-Fi connection the e-mark®create generates - click join

Attention: Never connect to the Wi-Fi through your phone settings, always connect through the app.

How to use the app

MENU GUIDE

Sharing

Imprints

If you click on one of your imprints saved under

My Imprints in the e-mark®create app, a menu opens.

Click on share/export. Now you can send your imprint via

e-mail or Whats App. To share more than one motif at the

same time, you can click on Share in the bottom menu, select

templates and click on Export & share.

Free additional

You can download a wide variety of

ready-to-use e-mark®create templates

or you can design your own unique

imprint motifs in the editor.

emark.colop.com/templates/create

template designs

IMPRINT SETTINGS

CHOOSE BETWEEN SINGLE LINE OR MULTI-LINE PRINTING CANVAS

ADJUST THE WIDTH OF YOUR CANVAS

TURN CONTINUAL MARKING ON OR OFF

CHANGE CENTER OR LATERAL PRINTING POSITION

REMOVE WHITE BACKGROUND FROM IMAGES

MIRROR OR REFLECT YOUR DESIGN

SAVE YOUR SETTINGS

CONNECT YOUR E-MARK CREATE,

CHECK BATTERY LEVELS & CHECK INK LEVELS

CHOOSE A CUSTOMISABLE TEMPLATE OR DESIGN YOUR OWN

VIEW, EDIT OR PRINT A PREVIOUS DESIGN

UPDATE PREFERENCES, CLEAN PRINT HEAD, UPDATE

FIRMWARE & CHANGE MACHINE SETTINGS

WEB INSTRUCTIONS, ORDER INK CARTRIDGES & MORE

6 7

Printing 2

In Imprint settings choose either two or three line printing

Once your design is ready to go, select the e-mark® create icon in the top right corner

The mobile printer will beep and the app will signal when your motif has been received

Follow the chart to print each line. Do not lift your device on the page until printing is complete

The e-mark®create will beep to indicate when you should change direction

or 3 lines

Continual

printing

Printing using

the Ribbon Guide

The COLOP e-mark®Ribbon Guides are the perfect

tool to print on the COLOP e-mark®Ribbon or the

COLOP e-mark® endless labels.

Don’t forget to activate Continual Marking in Imprint settings

Thread the ribbon or endless label through the Ribbon Guide by ﬁrst

going down and then up

Place the e-mark®create in middle of the Ribbon Guide

Hold down the end of the ribbon and slide the Ribbon Guide along

with the e-mark®create as long as you want to print

Note:

Do not pull the ribbon to avoid colour smears

Do not lift up the e-mark®create during the printing process to avoid print

head cleaning stains on the material

Use the respective Ribbon Guide for the 10mm, 15mm and the 25mm ribbon

Use the 15mm Ribbon Guide for the endless labels

Make sure Continual MarkingContinual Marking is turned on in Imprint settingsImprint settings

Once your design is ready to go select the e-mark® create icon in

the top right corner

The e-mark®create will beep and the app will signal when

your print has been received

Swipe the e-mark®create to print your design. The e-mark®create

will continue to print as long as it is in motion

Positioning

of the imprint

Notches on both sides of the e-mark®create, which indicate the middle of the im-

print, help to position your imprint precisely in predeﬁned spaces.

You can further choose between lateral and center starting position in the app for

better positioning.

Go to the editor and create your design

Click on the settingssettings icon in the top left corner

Select centrecentre or laterallateral under Start positonStart positon of imprintof imprint and press okok

means that the

e-mark®create

will start printing

after the markings

on the side of the

e-mark.

Lateral positioning

on the other hand

means that the

e-mark® create

already starts printing

from the middle.

Centre positioning

8 9

Notch

Printing

direction

The e-mark®create can print in any direction if you rotate the device

accordingly. You can slide from left to right or from right to left. If you

rotate your e-mark®create 90°you can print vertically. With a bit of

practice you can even print slightly curved instead of a straight line.

This makes the e-mark®create perfect for marking cardboard boxes,

greeting cards, walls, etc.

LEFT TO RIGHT

RIGHT TO LEFT

PRINT VERTICALLY

ROTATE 90° TO

ARCHED EFFECT

CURVE YOUR DESIGN

WHILE PRINTING FOR AN

Printing

using the Ruler

The COLOP e-mark®Ruler is the perfect tool to

print onto the COLOP e-mark®Wristbands and all

uneven or small objects. With the ruler exact po-

sitioning, straight imprints, printing on edges and

printing on almost any surface is possible.

Go to the editor and create your 1-line design and

send it to the e-mark®create

Place your Ruler on the object you want to print on.

If you position the e-mark®create on the left side

of your ruler swipe to the right, if you place it on the

right side swipe left.

Note:

Make sure the starting position of your imprint is set

to centercenter and insert the e-mark on the very right

or left. The e-mark®create will start printing right

at the beginning of the gap in the Ruler. Just select

1-line imprints when using the ruler.

8 9

Printing directly

on various surfaces

RECOMMENDED SURFACES (works best when ﬂat, level, and there is

enough space for the printhead and the rollers.)

PAPER/LABELS

Printer paper, cardstock, kraft paper, glitter

cardstock (5-10 minute dry time), chipboard,

construction paper, parchment paper,

mailing envelope (padded, unpadded), label

stickers, paper napkins, paper towels, crepe

paper, tissue paper, poster board, printable

photo paper (glossy & matte), untreated gift

bag, glassine treat bags, kraft paper lunch

bag.

Untreated wood, raw wood

WOOD

10 11
