Compaq Dc7700 - Convertible Minitower PC Manuale utente

Computer Setup (F10) Utility Guide

Business PCs

Development Company, L.P. The

information contained herein is subject to

change without notice.

Microsoft, Windows, and Windows Vista are

either trademarks or registered trademarks

of Microsoft Corporation in the United States

and/or other countries.

The only warranties for HP products and

services are set forth in the express warranty

statements accompanying such products

and services. Nothing herein should be

construed as constituting an additional

warranty. HP shall not be liable for technical

or editorial errors or omissions contained

herein.

This document contains proprietary

information that is protected by copyright. No

part of this document may be photocopied,

reproduced, or translated to another

language without the prior written consent of

Hewlett-Packard Company.

Computer Setup (F10) Utility Guide

Business PCs

First Edition (May 2004)

Second Edition (September 2004)

Third Edition (May 2005)

Fourth Edition (November 2005)

Fifth Edition (May 2005)

Sixth Edition (August 2006)

Seventh Edition (January 2007)

Document Part Number: 361206-007

About This Book

This guide provides instructions on how to use Computer Setup. This tool is used to reconfigure and

modify computer default settings when new hardware is installed and for maintenance purposes.

WARNING! Text set off in this manner indicates that failure to follow directions could result in

bodily harm or loss of life.

CAUTION: Text set off in this manner indicates that failure to follow directions could result in

damage to equipment or loss of information.

NOTE: Text set off in this manner provides important supplemental information.

ENWW iii

iv About This Book ENWW

Table of contents

Computer Setup (F10) Utility

Computer Setup (F10) Utilities ............................................................................................................. 1

Using Computer Setup (F10) Utilities .................................................................................. 2

Computer Setup—File ......................................................................................................... 3

Computer Setup—Storage .................................................................................................. 4

Computer Setup—Security .................................................................................................. 7

Computer Setup—Power ..................................................................................................... 9

Computer Setup—Advanced ............................................................................................. 10

Recovering the Configuration Settings ............................................................................................... 13

ENWW v

vi ENWW

Computer Setup (F10) Utility

Computer Setup (F10) Utilities

Use Computer Setup (F10) Utility to do the following:

●Change factory default settings.

●Set the system date and time.

●Set, view, change, or verify the system configuration, including settings for processor, graphics,

memory, audio, storage, communications, and input devices.

●Modify the boot order of bootable devices such as hard drives, diskette drives, optical drives, or

USB flash media devices.

●Enable Quick Boot, which is faster than Full Boot but does not run all of the diagnostic tests run

during a Full Boot. You can set the system to:

❑always Quick Boot (default);

❑periodically Full Boot (from every 1 to 30 days); or

❑always Full Boot.

●Select Post Messages Enabled or Disabled to change the display status of Power-On Self-Test

(POST) messages. Post Messages Disabled suppresses most POST messages, such as memory

count, product name, and other non-error text messages. If a POST error occurs, the error is

displayed regardless of the mode selected. To manually switch to Post Messages Enabled during

POST, press any key (except F1 through F12).

●Establish an Ownership Tag, the text of which is displayed each time the system is turned on or

restarted.

●Enter the Asset Tag or property identification number assigned by the company to this computer.

●Enable the power-on password prompt during system restarts (warm boots) as well as during

power-on.

●Establish a setup password that controls access to Computer Setup (F10) Utility and the settings

described in this section.

●Secure integrated I/O functionality, including the serial, USB, or parallel ports, audio, or embedded

NIC, so that they cannot be used until they are unsecured.

●Enable or disable removable media boot ability.

●Enable or disable legacy diskette write ability (when supported by hardware).

ENWW Computer Setup (F10) Utilities 1

●Solve system configuration errors detected but not automatically fixed during the Power-On Self-

Test (POST).

●Replicate the system setup by saving system configuration information on diskette and restoring

it on one or more computers.

●Execute self-tests on a specified ATA hard drive (when supported by drive).

●Enable or disable DriveLock security (when supported by drive).

Using Computer Setup (F10) Utilities

Computer Setup can be accessed only by turning the computer on or restarting the system. To access

the Computer Setup Utilities menu, complete the following steps:

1. Turn on or restart the computer.

2. As soon as the computer is turned on, press F10 when the monitor light turns green to enter

Computer Setup. Press Enter to bypass the title screen, if necessary.

NOTE: If you do not press F10 at the appropriate time, you must restart the computer and

again press F10 when the monitor light turns green to access the utility.

3. Select your language from the list and press Enter.

4. A choice of five headings appears in the Computer Setup Utilities menu: File, Storage, Security,

Power and Advanced.

5. Use the arrow (left and right) keys to select the appropriate heading. Use the arrow (up and down)

keys to select the option you want, then press Enter. To return to the Computer Setup Utilities

menu, press Esc.

6. To apply and save changes, select File > Save Changes and Exit.

●If you have made changes that you do not want applied, select Ignore Changes and Exit.

●To reset to factory settings or previously saved default settings (some models), select Apply

Defaults and Exit. This option will restore the original factory system defaults.

CAUTION: Do NOT turn the computer power OFF while the ROM is saving the Computer Setup

(F10) changes because the CMOS could become corrupted. It is safe to turn off the computer

only after exiting the F10 Setup screen.

Table 1 Computer Setup (F10) Utility

Heading Table

File Table 2Computer Setup—File on page 3

Storage Table 3Computer Setup—Storage on page 4

Security Table 4Computer Setup—Security on page 7

Power Table 5Computer Setup—Power on page 9

Advanced Table 6Computer Setup—Advanced (for advanced users)

on page 10

2 Computer Setup (F10) Utility ENWW

Computer Setup—File

NOTE: Support for specific Computer Setup options may vary depending on the hardware

configuration.

Table 2 Computer Setup—File

Option Description

System Information Lists:

●Product name

●SKU number (some models)

●Processor type/speed/stepping

●Cache size (L1/L2) (dual core processors have this listed twice)

●Installed memory size/speed, number of channels (single or dual) (if applicable)

●Integrated MAC address for embedded, enabled NIC (if applicable)

●System BIOS (includes family name and version)

●Chassis serial number

●Asset tracking number

About Displays copyright notice.

Set Time and Date Allows you to set system time and date.

Flash System ROM

(some models)

Allows you to select a drive containing a new BIOS.

Replicated Setup Save to Removable Media

Saves system configuration, including CMOS, to a formatted 1.44-MB diskette, a USB flash media

device, or a diskette-like device (a storage device set to emulate a diskette drive).

Restore from Removable Media

Hiermee zet u de systeemconfiguratie terug van een diskette, een USB-flashapparaat of een

opslagapparaat waarmee een diskettedrive wordt geëmuleerd.

Default Setup Save Current Settings as Default

Saves the current system configuration settings as the default.

Restore Factory Settings as Default

Restores the factory system configuration settings as the default.

Apply Defaults and

Exit

Applies the currently selected default settings and clears any established passwords.

Ignore Changes

and Exit

Exits Computer Setup without applying or saving any changes.

Save Changes and Exit Saves changes to system configuration or default settings and exits Computer Setup.

ENWW Computer Setup (F10) Utilities 3

Computer Setup—Storage

NOTE: Support for specific Computer Setup options may vary depending on the hardware

configuration.

Table 3 Computer Setup—Storage

Option Description

Device Configuration Lists all installed BIOS-controlled storage devices.

When a device is selected, detailed information and options are displayed. The following options

may be presented.

Diskette Type (Legacy Diskettes only)

Identifies the highest capacity media type accepted by the diskette drive. Options are 3.5" 1.44 MB

and 5.25" 1.2 MB.

Drive Emulation

Allows you to select a drive emulation type for a certain storage device. (For example, a Zip drive

can be made bootable by selecting diskette emulation.)

Drive Type Emulation Options

ATAPI Zip drive:

●None (treated as Other).

●Diskette (treated as diskette drive).

Legacy Diskette: No emulation options available.

CD-ROM: No emulation options available.

ATAPI LS-120:

●None (treated as Other).

●Diskette (treated as diskette drive).

Hard Disk

●None (prevents BIOS data accesses and disables it as a boot device).

●Hard Disk (treated as hard disk).

Multisector Transfers (ATA disks only)

Specifies how many sectors are transferred per multi-sector PIO operation. Options (subject to

device capabilities) are Disabled, 8, and 16.

Transfer Mode (IDE devices only)

Specifies the active data transfer mode. Options (subject to device capabilities) are PIO 0, Max PIO,

Enhanced DMA, Ultra DMA 0, and Max UDMA.

Translation Mode (ATA disks only)

Lets you select the translation mode to be used for the device. This enables the BIOS to access

disks partitioned and formatted on other systems and may be necessary for users of older versions

of UNIX (e.g., SCO UNIX version 3.2). Options are Automatic, Bit-Shift, LBA Assisted, User, and

Off.

4 Computer Setup (F10) Utility ENWW
