Compaq Deskpro 2000 Series Manuale utente

REFERENCE GUIDE

Compaq Deskpro 2000

Series of Personal Computers

Writer: Holly Jahangiri Saved by: Alyce Klingler-Castle Saved date: 06/10/97 3:41 PM

Pages: 2 Words: 198 Template: d:\95office\templates\commnoti.dot

File Name Notice 278019-002

Writer: Holly Jahangiri Saved by: Alyce Castle Saved date: 06/10/97 3:41 PM

Pages: 2 Words: 198 Template: d:\95office\templates\commnoti.dot

File Name Notice 278019-002

Notice

The information in this guide is subject to change without notice.

COMPAQ COMPUTER CORPORATION SHALL NOT BE LIABLE FOR

TECHNICAL OR EDITORIAL ERRORS OR OMISSIONS CONTAINED

HEREIN; NOR FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES

RESULTING FROM THE FURNISHING, PERFORMANCE, OR USE OF

THIS MATERIAL.

This guide contains information protected by copyright. No part of this guide

may be photocopied or reproduced in any form without prior written consent

from Compaq Computer Corporation.

1997 Compaq Computer Corporation.

Compaq and Deskpro are registered in the U. S. Patent and Trademark Office.

Microsoft, MS-DOS, Windows, Windows NT, and other names of Microsoft

products referenced herein are trademarks or registered trademarks of Microsoft

Corporation.

Intel and Pentium are registered trademarks of Intel Corporation.

MMX is a trademark of Intel Corporation.

The software described in this guide is furnished under a license agreement

or nondisclosure agreement. The software may be used or copied only in

accordance with the terms of the agreement.

Product names mentioned herein may be trademarks and/or registered

trademarks of their respective companies.

Reference Guide

Compaq Deskpro 2000 Series of Personal Computers

Second Edition (September 1997)

Part Number 278019-002

Compaq Computer Corporation

Writer: Holly Jahangiri Saved by: Alyce Klingler-Castle Saved date: 06/10/97 3:41 PM

Pages: 2 Words: 198 Template: d:\95office\templates\commnoti.dot

File Name Notice 278019-002

Reference Guide ix

Writer: Holly Jahangiri, Writer; Alyce Klingler-Castle, EFC Saved by: Alyce Klingler-Castle Saved date: 06/10/97 2:22 PM

Pages: 2 Words: 327 Template: d:\95office\templates\commpref.dot

File Name: Preface Part Number: 278019-002

preface

USING THIS GUIDE

This Reference Guide includes general information about your

computer, troubleshooting and diagnostics information, and

technical specifications.

Symbols and

Conventions The following format conventions distinguish elements of the

text throughout this guide:

■ Computer models featuring the Intel Pentium processor with

MMX technology will be referred to as Pentium systems.

Computer models featuring the Intel Pentium II processor

will be referred to as Pentium II systems.

■ When keys must be pressed at the same time, the action is

represented by the key names and the plus (+) symbol. For

example, Ctrl+Alt+Delete.

■ The names of files are presented in uppercase italic type as

shown here: FILENAME.

■ The names of commands, folders, or directories are

presented in uppercase type as shown here: COMMAND or

DIRECTORY. Commands that are to be entered at the

system prompt are shown on a separate line.

■ When you are asked to type something without pressing the

Enter key, you are directed to “type” the information.

■ When you need to type information and press the Enter key,

you will be directed to “enter” the information.

■ When you need to make a selection with a mouse, you will

be directed to “select” or “click” the information.

xUsing This Guide

Writer: Holly Jahangiri Saved by: Alyce Klingler-Castle Saved date: 06/10/97 2:22 PM

Pages: 2 Words: 327 Template: d:\95office\templates\commpref.dot

File Name: Preface Part Number: 278019-002

The following words and symbols mark special messages

throughout this guide:

!WARNING: Text set off in this manner indicates that failure to

follow directions could result in bodily harm or loss of life.

CAUTION: Text set off in this manner indicates that failure to

follow directions could result in damage to equipment or loss of

information.

✎Text set off in this manner presents clarifying information,

specific instructions, commentary, sidelights, or interesting

points of information.

Environmental

Commitment Compaq is committed to making environmentally friendly

products. Your computer was produced in a chlorofluorocarbons

(CFC)-free factory. All plastics used in the product are stamped

with material composition to make recycling more efficient.

Reduce, reuse, and recycle are words to live by at Compaq.

Reference Guide 1-1

Writer: Holly Jahangiri Saved By: Alyce Castle Saved Date: 06/26/97 12:09 PM

Pages: 18 Words: 2860 Template: c:\msoffice\templates\comm.dot

File Name Ch1.doc Part Number 278019-002

chapter 1

COMPUTER AT A GLANCE

Features ■ Microsoft Windows 95 or Windows NT 4.0 operating

system software

■ Intel Pentium processor with MMX technology running at a

speed of 166 MHz, 200 MHz, or 233 MHz, or Intel Pentium

II processor running at a speed of 233 MHz, 266 MHz, or

300 MHz.

MMX technology is designed to enhance performance in

applications written to take advantage of MMX instructions,

while preserving compatibility with existing software and

operating systems. Additional performance enhancements

are provided for advanced media and communication

applications, such as motion video, combined graphics with

video, image processing, audio synthesis, speech synthesis

and compression, telephony, video conferencing, and 2D

and 3D graphics.

■ Pentium systems: 16- or 32-megabyte (MB) synchronous

dynamic random access memory (SDRAM) standard;

expandable to 384 megabytes of SDRAM installed in dual

inline memory modules (DIMMs)

Pentium II systems: 32-megabyte (MB) synchronous

dynamic random access memory (SDRAM) standard;

expandable to 384 megabytes of SDRAM installed in dual

inline memory modules (DIMMs)

■ Pentium systems: 256- or 512-kilobyte (Kbyte) secondary

(L2) cache module; Pentium models with 256-Kbyte cache

expandable to 512 Kbytes

Pentium II systems: 512-kilobyte (Kbyte) secondary (L2)

cache integrated into the processor module (not expandable)

1-2 Computer at a Glance

Writer: Holly Jahangiri Saved by: Alyce Klingler-Castle Saved date: 06/26/97 12:09 PM

Pages: 18 Words: 2860 Template: c:\msoffice\templates\comm.dot

File Name Ch1.doc Part Number 278019-002

■ Peripheral Components Interconnect (PCI) chipset used for

PCI/ISA, memory, USB ports, and peripheral control

■ Super I/O controller (integrates a serial port, parallel port,

diskette drive interface, real-time clock, CMOS RAM, and

mouse and keyboard controller)

■ PCI and ISA peripheral connectors on the expansion riser

board

■ BIOS in a flash memory device supporting PCI auto-

configuration

■ Desktop chassis includes expansion slots for up to five

expansion boards:

❏ Two dedicated half-length PCI slots

❏ Two dedicated ISA-bus slots (one half-length and one

full-length)

❏ One full-length “combination” slot for either a PCI or

an ISA expansion board

■ Minitower chassis includes expansion slots for up to five

expansion boards:

❏ Two dedicated full-length PCI slots

❏ Two dedicated full-length ISA-bus slots

❏ One full-length “combination” slot for either a PCI or

an ISA expansion board

■ 145-watt (desktop models) or 185-watt (minitower models)

surge-tolerant continuous power supply, switch-selectable

for 115 and 230 VAC operation

■ One RS-232C–compatible 9-pin serial connector

■ One multimode, 25-pin enhanced parallel connector

■ Two Universal Serial Bus (USB) Plug and Play connectors

on all models, for use with USB devices such as a mouse,

keyboard, most joysticks, and other future USB peripherals

Reference Guide 1-3

Writer: Holly Jahangiri Saved By: Alyce Castle Saved Date: 06/26/97 12:09 PM

Pages: 18 Words: 2860 Template: c:\msoffice\templates\comm.dot

File Name Ch1.doc Part Number 278019-002

■ Five drive bays on desktop models:

❏ One external 3.5-inch, one-third height diskette drive

bay

❏ One internal 3.5-inch, one-third height drive bay

❏ Two external 5.25-inch half-height bays for optional

CD-ROM drive, LS-120 drive, PD-CD drive, diskette

drive, tape drive, or hard drive

❏ One internal 5.25-inch third-height bay for optional

hard drive

■ Five drive bays on minitower models:

❏ One external 3.5-inch, one-third height diskette drive

bay

❏ One internal 3.5-inch, one-third height drive bay

❏ Three external 5.25-inch half-height bays for optional

CD-ROM drive, LS-120 drive, PD-CD drive, diskette

drive, tape drive, or hard drive

■ Pentium systems: One 2.1- or 3.2-gigabyte (GB) Enhanced

IDE (EIDE) SMART II hard drive

Pentium II systems: One 2.1- or 3.2-gigabyte (GB) Ultra

ATA SMART II hard drive

All drives feature drive fault prediction.

■ One 1.44-MB, 3.5-inch high-density diskette drive installed

■ Pentium systems: One 16X slot-load IDE CD-ROM drive,

16-bit audio card, and enhanced speaker, installed on select

models

Pentium II systems: One 24X slot-load IDE CD-ROM drive,

16-bit audio card, and enhanced speaker, installed on select

models

■ Pentium systems: S3 Trio64V2/GX enhanced 64-bit

graphics controller installed with 1-MB SGRAM,

expandable to 2 MB

Pentium II systems: Matrox MGA-1064 SG Graphics

Accelerator installed with 2-MB SGRAM, expandable to 4 MB

1-4 Computer at a Glance

Writer: Holly Jahangiri Saved by: Alyce Klingler-Castle Saved date: 06/26/97 12:09 PM

Pages: 18 Words: 2860 Template: c:\msoffice\templates\comm.dot

File Name Ch1.doc Part Number 278019-002

■ Compaq Enhanced Keyboard, featuring Microsoft Windows–

specific keys

■ Mouse

■ Keyboard and mouse connectors on the back panel

■ Internal speaker mounted on system board

■ Security features, including passwords and cable lock

provision

■ Intelligent Manageability features designed to make

Compaq computers easier to inventory, configure, upgrade,

troubleshoot, protect, and maintain

■ Compaq Diagnostics and Configuration utilities, support

software, and device drivers (available in select languages)

Altri manuali per Deskpro 2000 Series

Indice

Altri manuali Compaq Scrivania

Compaq

Compaq CQ2009F - 1 GB RAM Manuale utente

Compaq

Compaq Presario CQ4000 - Desktop PC Scheda tecnica

Compaq

Compaq 517212-001 Manuale utente

Compaq

Compaq 6000 - ProLiant - 128 MB RAM Manuale di programmazione

Compaq

Compaq SR5250NX - Presario - 1 GB RAM Come usare

Compaq

Compaq T1010 - Windows-based Terminals - 48 MB RAM Manuale utente

Compaq

Compaq Presario CQ3200 - Desktop PC Scheda tecnica

Compaq

Compaq Presario S0000 Series Scheda tecnica

Compaq

Compaq Deskpro EX Manuale

Compaq

Compaq Presario 6000 Series Manuale utente

Compaq

Compaq 5000 - Professional - 32 MB RAM Manuale

Compaq

Compaq Presario SG3200 - Desktop PC Manuale utente

Compaq

Compaq dc7800 - Convertible Minitower PC Manuale utente

Compaq

Compaq Evo D300 - Convertible Minitower Manuale operativo e di manutenzione

Compaq

Compaq dc7700 - Convertible Minitower PC Istruzioni utente

Compaq

Compaq Professional Workstation AP200 Manuale

Compaq

Compaq EP Series Manuale utente

Compaq

Compaq 6005 - Pro Microtower PC Guida all'installazione

Compaq

Compaq dc5800 - Microtower PC Manuale operativo e di manutenzione

Compaq

Compaq Deskpro 4000N - Desktop PC Manuale utente

Compaq

Compaq Presario 6500 - Desktop PC Manuale utente

Compaq

Compaq Presario SR1500 - Desktop PC Istruzioni per l'installazione

Compaq

Compaq Presario Notebook PC Manuale

Compaq

Compaq 239158-999 - Mini Tower - Power Supply 250... Manuale operativo e di manutenzione

Manuali Scrivania popolari di altre marche

HP m9060n - Pavilion - Elite Scheda tecnica

Asus

Asus E210 Series Manuale utente

Dell

Dell Inspiron 600m Manuale utente

Dell

Dell Inspiron 3662 Manuale utente

TotalFlow

TotalFlow uFLO Manuale utente

HP Presario SV7000 - Desktop PC Manuale utente

HP ProDesk 400 G5 Manuale

Logitech

Logitech MK320 Manuale utente

Dell

Dell XPS 730 H2C Manuale utente

Sony

Sony Vaio Series Manuale utente

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuale utente

Alto

Alto MD 250 Manuale utente

Lenovo

Lenovo ThinkCentre Edge 72 Manuale

Lenovo

Lenovo ThinkStation D20 Manuale

Arbor Technology

Arbor Technology FPC-7800 Series Manuale utente

Sony

Sony VAIO VGX-TP1 Series Manuale utente

Asus

Asus Eee Box B204 Manuale utente

Dell

Dell Optiplex 9010 All In One Manuale utente
