QuickSpecs

Compaq S720 CRT Monitor

DA-10952 World Wide — Version 2 — September 18, 2001

ODELS

S720 CRT Monitor (North America, Greater China)

239286-001,239286-AA2 Opal

239287-001,239287-AA2 Carbon/Silver

Note: AssetControl monitor. AssetControl features are accessible with Compaq desktops featuring Intelligent Manageability.

PECIFICATIONS

Picture Tube (diagonal) 17-inch FST

Viewable (diagonal) 15.8-inch

Horizontal Dot Pitch 0.24 mm

Trio Dot Pitch 0.28 mm

Max Refresh/Preset Graphic Modes 1600 x 1200 1280 x 1024 1024 x 768

N/A 65 Hz/60 Hz 86 Hz/75, 85 Hz

800 x 600 720 x 400 640 x 480 832 x 624

110 Hz/75, 85 Hz 156 Hz/70 Hz 157 Hz/60,75, 85 Hz 74 Hz (Mac Mode)

Note: All modes are non-interlaced unless specified otherwise.

Text Mode 720 x 400

70 Hz

Preset Graphic/ Modes User-Programmable 10/6

Anti-Glare/Anti-Static Yes/Yes

Plug and Play Yes

Approvals/Certifications UL Approval Yes

ISO9241-3, -7, -8 VDT Guidelines Approval Yes

MPR-II Compliant Yes

FCC Approval Yes

Energy Star Compliant Yes

TCO 99 Compliant No

CE Marking No

GS Marking

Energy 2000 Compliant No

Yes

On-Screen Controls Yes

Language Selection German No

English Yes

Spanish Yes

Italian

Simplified Chinese No

Yes

Swedish No

Portuguese No

French Yes

Russian No

Korean No

QuickSpecs

Compaq S720 CRT Monitor

DA-10952 World Wide — Version 2 — September 18, 2001

PECIFICATIONS

(continued)

Tilt Base (up/down) 13°up/5°down

Swivel ±45°left/right

User Controls Brightness, Contrast Yes

Size and Positioning Yes

Pincushion (barrel) Yes

Trapezoid Yes

Tilt (rotation) Yes

Color temperature Yes

Parallelogram No

Pincushion Balance No

Pinbalance No

Individual color control No

Moiré Cancellation Yes

Convergence No

Vertical Linearity No

Display Timing Yes

OSD Lock/Unlock No

Serial Number Display No

Degauss Yes

Factory Reset/Recall Yes

AssetControl Yes

Note: When used with Compaq Intelligent Manageability CPUs and appropriate network software.

Pixel Clock Speed 108 MHz

Input Impedance 75 ohms

Horizontal Frequency 30 to 70 KHz

Vertical Frequency 50 to 160 Hz

Power Supply 90 to 132 & 195 to 265 VAC, 47.5 to 63 Hz Universal Auto-Sensing

Maximum Power Rating ≤75 Watts

Power Saver State < 3W

Synch Input TTL separate synch

Signal Cable Captive 15-pin D-sub video cable

Dimensions (WxDxH) 404 mm x 423 mm x 408 mm (15.9 in x 16.7 in x 16.7 in)

Weight (Packaged/Unpackaged) 16.9 kg / 14.5 kg

Operating Temperature 50°to 95°F/10°to 35°C

Operating Humidity (non-condensing) 20% to 80%

QuickSpecs

Compaq S720 CRT Monitor

DA-10952 World Wide — Version 2 — September 18, 2001

PECIFICATIONS

(continued)

48 Hour Direct Replacement

If this monitor fails during the parts warranty, Compaq guarantees that a new, or like-new monitor

replacement will be delivered within 48 hours.

Note: Certain restrictions and exclusions apply. Consult the Compaq Customer Service Support Center

for details.

Limited Warranty Three-year parts, first-year labor on-site

Note: Certain restrictions and exclusions apply. Consult the Compaq Customer Service Support Center

for details.

OMPATIBILITY

Graphics Controllers ATI RAGE Mobility

ATI RAGE LT Pro

S3 Virge max

NVIDIA Quadro2 MXR

NVIDIA Quadro2 EX

NVIDIA Quadro2 Pro

Sonic Blue FireGL2

3Dlabs Wildcat 5110

NVIDIA TNT2 Vanta

G400 Dual Head

G200 Quad MMS

NVIDIA NV10

NVIDIA TNT2 Model 64

RAGE Pro Turbo 2x

RAGE Pro Turbo 2X

Viper V730

Viper V770 Ultra

Millennium II

G200SG

G400SD

G450 Dual Head AGP

G400 Toucan

TNT2 Pro

NVIDIA NV11 (AGP)

NVIDIA NV11 Dual Head (AGP)

NVIDIA NV11 Dual Head (PCI)

NVIDIA TNT2 (AGP)

Elsa Synergy III

NVIDIA TNT2 Pro

Matrox 450 Dual Head PCI

NV15 Sapphire

M64 8 MB PCI

M64 16MB

Chipsets Intel 810

Intel 810e

Intel 815

Compaq, registered United States Patent and Trademark Office.

Other product names mentioned herein may be trademarks and/or registered trademarks of their respective companies.
