1

Quick Install Guide

PG-9172 | G.hn Powerline Adapter

A

Understanding the Powerline Adapter

Network Indicator

Displays Connection Strength

Displays Network Status

Connection is Secure When Lit

Configuration Button

(Enables Device Synchronization)

Reset Button

Connection Indicator

Security Indicator

B

Initial Device Setup

NOTE: A minimum of two G.hn Powerline Adapters are required to create a proper connection. Follow

Steps 1-4 to add additional G.hn Adapters to your network.

1.Plug the Powerline Adapter into the power outlet.

FOR PRESS USE ONLY

2

Note: For maximum performance, please plug the Powerline Adapter

directly into the wall outlet. Do not plug into a power strip or surge

protector,as network performance could degrade significantly.

2.Connect the Powerline Adapter to anetwork device with an Ethernet

(RJ-45) cable. (Wait 10 seconds for Network Indicator to light up GREEN

which indicates a good connection, a flashing GREEN light indicates that the

device is sending data).

Network Device

(Modem, Router, or Access Point)

Ethernet Cable

C

Device Connection

3. Plug the additional Powerline Adapter into a power outlet near the

Internet-enabled device (ex. TV, PC, STB, DVR, etc.).

4. Connect the Powerline Adapter to the device with an Ethernet cable.

(The Connection Indicators and Network Indicators

on the front of

both Powerline Adapters should be

GREEN representing a strong

connection).

3

D

Security Setup

Note: G.hn Adapters will automatically connect in “non-secure”

mode. It is highly recommended to follow Steps 5 and 6 to create

a secure connection.

5.Press the “Config” Button for 3 seconds till you see the Security

Indicator start flashing GREEN on EACH of the Powerline Adapters

you want to be “connected.” (The Security Indicator will light up

GREEN when successfully connected AND the Connection Indicator

on the front of the Powerline Adapter should be solid GREEN when

they are paired ~representing a strong connection).

6.Repeat Steps 3 to 5 to add additional adapters/devices. Please

note that up to 16 devices can be connected to a Powerline G.hn

Network.

4

NOTE: For instructions on advanced features, FAQ, etc., please

visit our online Product Webpage:

http://us.comtrend.com/products/public/product/home-networking/pg-

9172.html

For more information: Facebook: https://facebook.com/Comtrend

Website: http://us.comtrend.com/

Support: Visit our website or call 1-877-COMTREND

(1-877-266-8736)

E

Your device is now connected!
