CONCORD Eye-Q Go Wireless Manuale utente

CONTENTS

ENGLISH............................................................................................1

DEUTSCH ..........................................................................................9

CONTENTS

GO Wireless QSG (512708-00) 6/6/03 9:33 PM Page 1

This Quick Start Guide provides a quick reference for

operating your new digital camera and USB Wireless

Bluetooth Adaptor. Refer to the hard copy of the User’s

Guide or the electronic version which can be found on the

PC Software Installation Disk CD-ROM for detailed

instructions on how to use all of your camera’s features.

Before using the camera, make sure to read all safety

instructions and precautions outlined in the User’s Guide.

QUICK START GUIDE

ENGLISH

GO Wireless QSG (512708-00) 6/6/03 9:33 PM Page 1

CAMERA OVERVIEW

Top/Front

Bottom/Back

1. Shutter Button

2. Mode Switch

3. Neck/Wrist Strap

Holder

4. Viewfinder

5. Flash Sensor

6. Flash

7. Self-timer LED

8. Lens

9. Slide Switch

10. Flash Ready LED

11. LCD

12. USB/TV Out Ports

13. Tripod Socket

14. Viewfinder

15. Navigation Button

16. Power Button

17. LCD On/Off Button

18. OK/Magnification

Button

19. Menu Button

20. Battery/Memory

Card Door

005/080

AWB

1600

005/080

AWB

1600

005/080

AWB

1600

005/080

AWB

1600

GO Wireless QSG (512708-00) 6/6/03 9:33 PM Page 2

TAKING PICTURES

REVIEWING PICTURES

TAKING PICTURES

1. Set the Mode

Switch to ( )

Camera Mode.

2. Position the subject

in the LCD or

viewfinder.

3. Press the Shutter

button to capture

the picture.

1. Set the camera to

( ) Review

Mode.

2. Press to

scroll through the

stored files.

JPEG

005/080

GO Wireless QSG (512708-00) 6/6/03 9:33 PM Page 3

DELETING PICTURES

1. Set the Mode

Switch to ( )

Review Mode.

2. Press the MENU

button to display

the ( ) Main

Menu.

3. Press to enter

the Delete

submenu.

4. Press to

highlight Delete

One or Delete All.

5. Press to enter

the submenu.

6. Press to

highlight Yes.

7. Press OK to select.

005/080

DELETE ONE

THIS FILE?

No

Yes

OK MENU

005/080

Delete

Thumbnail

Brightness

Transmit

MAIN MENU

Exit

Delete One

Delete All

DELETE

005/080

GO Wireless QSG (512708-00) 6/6/03 9:33 PM Page 4

INSTALLING THE SOFTWARE FOR THE USB BLUETOOTH WIRELESS ADAPTOR

INSTALLING THE SOFTWARE FOR THE USB BLUETOOTH

WIRELESS ADAPTOR

Do not plug the USB Bluetooth Wireless Adaptor into the computer before

installing the driver.

1. Insert the Bluetooth Adaptor Installation Disk into your computer’s CD-ROM

drive.

2. The installation screen will appear, click on Install Adaptor Drivers.

3. Follow the on-screen instructions to complete the installation.

Note: For more detailed instructions on installation, please refer to the USB

Bluetooth Wireless Adaptor Installation Guide in the hard copy of the User’s

Guide or the electronic version found in the PC Installation Disk and the

Bluetooth Adaptor Installation Disk.

This software is necessary to add Bluetooth functionality to your PC.

TRANSFERRING PICTURES TO THE COMPUTER WITH

BLUETOOTH

1. Make sure that your computer is on and that

Windows is running.

2. Power on your camera.

3. Remove the cap on the USB Bluetooth

Wireless Adaptor. (fig.1.1)

4. Plug the USB Bluetooth Wireless Adaptor into the

USB port located in the back or front of your

computer. (fig.1.2)

•Keep a distance of no more than 30 feet (10

meters) between the camera and the USB

Bluetooth Wireless Adaptor (2 meters is

recommended).

fig.1.1

fig.1.2

GO Wireless QSG (512708-00) 6/6/03 11:08 pm Page 5

INSTALLING THE SOFTWARE FOR THE USB BLUETOOTH WIRELESS ADAPTOR

5. Click on the XTNDConnect Blue Manager icon located on the

desktop of your icon. (fig.1.3)

6. Set the Mode Switch to ( ) Review Mode.

7. Press and until the picture that you want to transfer is

displayed on the LCD.

8. Press the MENU button to display the Main Menu.

9. Press until Transmit is highlighted. (fig.1.4)

10. Press the OK button.

•The camera will begin searching for the USB

Bluetooth Wireless Adaptor.

11. The name of the computer will be displayed on the

LCD. Press until the computer name on the

camera’s LCD is highlighted. (fig.1.5)

12. Press the OK button on the camera to start the

transfer.

13. After the transmission is completed, click on the In

Box... icon to display the transferred picture.

14. Double-click on the picture file you want to view.

•Windows will automatically open the picture with

the graphic viewer installed on your computer

such as Microsoft Photo Editor or Quicktime.

15. Rename or save the pictures in the Bluetooth In

Box.

Note: Only one picture can be transferred to the computer with Bluetooth at a

time. To transfer and view other pictures stored on the camera, repeat the steps

above.

fig.1.3

fig.1.4

005/080

Delete

Thumbnail

Brightness

Transmit

MAIN MENU

005/080

BLUETOOTH

My computer

Main Menu

fig.1.5

GO Wireless QSG (512708-00) 6/6/03 9:33 PM Page 6

INSTALLING THE CAMERA DRIVERS AND DIRECTX 9

Do not connect the camera to the computer with the USB cable provided

until the camera drivers have been installed.

Note to Windows 98SE, Windows 2000 and Windows ME users: In order to

view your stored video clips on your computer DirectX 9 must be installed.

1. Insert the PC Installation Disk into your computer’s CD-ROM drive.

2. The installation screen will appear, click on Install Camera Drivers.

3. Follow the on-screen instructions to complete the installation.

Note: For more detailed instructions on installation, please refer to the Camera

Drivers and Software Installation Guide in the hard copy of the User's Guide or

an electronic version can be found on the PC Installation Disk.

INSTALLING THE CAMERA DRIVERS AND DIRECTX 9

GO Wireless QSG (512708-00) 6/6/03 11:31 pm Page 7

CONNECTING THE CAMERA TO THE COMPUTER

DOWNLOADING PICTURES AND VIDEO CLIPS ONTO YOUR

COMPUTER USING THE MINI-USB CABLE

Downloading files from the camera:

•Internal memory: Do not insert the memory card.

•Memory Card: Insert the memory card.

Do not insert or remove the memory card when the camera is connected

to the computer.

Downloading Pictures and Video Clips onto your computer:

1. Set the camera to Pic mode.

•Set the Mode Switch to ( ).

•Press the MENU button to display the main menu.

•Press until Setup is highlighted.

•Press to enter the Setup submenu.

•In the Setup menu, press until Driver is highlighted.

•Press to change the setting to Pic.

•Press the Menu button to exit.

2. Connect the camera to the computer with the Mini-USB cable.

3. Double-click on My Computer>Removable Disk>DCIM>100GOWIR.

•The stored pictures (JPG) and video clips (AVI) stored in the internal memory

or the memory card will be displayed.

4. Click and drag the files into a directory in your computer to save them.

•To select all files, click Edit > Select all.

GO Wireless QSG (512708-00) 6/6/03 9:33 PM Page 8
