CONCORD Eye-Q Go Wireless Manuale utente

ENGLISH ..................................................................................................1

FRANÇAIS ..............................................................................................23

DEUTSCH................................................................................................45

ITALIANO ................................................................................................67

ESPAÑOL................................................................................................89

PORTUGUÊS ..........................................................................................111

CONTENTS

Eye-Q Go Instr.Manual (English) 6/6/02 10:39 am Page 23

Congratulations on the purchase of your new

camera. Your camera has been carefully

engineered and manufactured to give you

dependable operation. Read this manual

before operating the camera to become more

familiar with it and obtain the performance

that will bring you continued enjoyment for

many years.

This manual has been written and formatted

with such depth and detail so you can

maximize the features of your camera, yet

easily follow the instructions.

CONGRATULATIONS

ENGLISH

Eye-Q Go Instr.Manual (English) 6/6/02 10:39 am Page 1

FCC INFORMATION

FCC WARNING: This equipment meets the limits for a class B digital device,

pursuant to Part 15 of FCC rules. Only the cable supplied with the camera should

be used. Operation with other cables is likely to result in interference to radio

and TV reception and could void the user’s authorization to operate this

equipment. This device complies with Part 15 of the FCC Rules. Operation is

subject to the following two conditions:

•This device may not cause harmful interference.

•This device must accept any interference received, including interference that

may cause undesired operation.

Tested To Comply

With FCC Standards

for HOME OR OFFICE USE

Changes or modifications not expressly approved by the manufacturer may void

the user’s authority to operate this equipment.

USER INFORMATION

NOTE: This equipment has been tested and found to comply with the limits for a

class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment on and off, the user is

encouraged to try to correct the interference by one or more of the following

measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver

•Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

•Consult the dealer or a qualified technician for help.

IMPORTANT INFORMATION

Eye-Q Go Instr.Manual (English) 6/6/02 10:39 am Page 2

Be sure to observe the following precautions when using the camera:

•Do not take pictures or use the Internal LCD Display when

operating a vehicle or while walking.

•Do not open the case of the camera or attempt your own repairs.

Always leave service to authorized repair facilities.

•Keep the camera away from water and other liquids, and never let

it get wet. Never use when it is raining or snowing.

•Should foreign matter or water get into the unit, immediately turn

the power off and contact your local authorized service center.

•Physical damage and malfunction of this unit can cause the image

data stored in its memory to be deleted. Be sure to always keep

backup copies of data by transferring them to a personal

computer.

•Under an environment with electrostatic discharge, the camera

may malfunction and require the user to reset the camera.

•Do not leave the camera in places subject to extremely high

temperatures, such as a sealed vehicle or in direct sunlight.

•Remove the battery when the camera is not used for long periods

of time.

•Use 3V Lithium Battery (CR123A) only.

•Dispose of the battery in a manner that complies with applicable

laws.

•Do not place the camera in unstable locations where the camera

may fall and be damaged.

•Do not touch or press on the Status LCD Display or lens.

PRECAUTIONS

Eye-Q Go Instr.Manual (English) 6/6/02 10:39 am Page 3

1. Shutter Button

2. Viewfinder

3. Macro Switch

4. Battery Door

5. Capture/Review Switch

6. Self-timer LED

7. UV Filter and Lens

8. USB Connector Port

LOCATION OF CONTROLS

FRONT/TOP

Eye-Q Go Instr.Manual (English) 6/6/02 10:39 am Page 4

LOCATION OF CONTROLS (CONTINUED)

9. Status LCD

10. Diopter Adjustment Ring

11. Viewfinder/Internal LCD

Display

12. Up Button

13. Down Button

14. Lug for Neck/Wrist Strap

15. ON/OFF/Select Button

16. Self-timer/Delete Button

BACK

A. Battery Indicator

B. Macro Focus Indicator

C. Self-timer Indicator

D. Pictures Remaining Indicator

DISPLAY

Eye-Q Go Instr.Manual (English) 6/6/02 10:39 am Page 5

LOADING THE BATTERY

Before taking pictures, a fresh 3V (CR123A) Lithium

battery must be inserted into the unit.

1. Using your thumb, open the battery compartment

by pressing down on the battery door and

sliding it outwards as indicated by the arrow.

2. Insert a 3V (CR123A) Lithium battery. Make sure

to observe the polarity (+/–) as indicated in the

figure.

3. Close the battery compartment.

The camera has a battery indicator that shows the current battery level,

regardless of the mode the camera is in.

GETTING STARTED

BATTERY PRECAUTIONS

Follow these precautions when using a battery in this device:

1. Use only the size and type specified.

2. Be sure to follow the correct polarity when installing the battery. A

reversed battery may cause damage to the device.

3. If the device is not to be used for a long period of time, remove the

battery to prevent damage or injury from battery leakage.

FULL

Battery has full

power and is ready

to use.

LOW

Battery has low

power and will

need to be replaced

soon.

When battery is low, discontinue use and replace the battery.

Eye-Q Go Instr.Manual (English) 6/6/02 10:39 am Page 6

GETTING STARTED (CONTINUED)

TURNING THE CAMERA ON AND OFF

•To turn the camera on, press and

hold down the ON/OFF button ( )

until the Status LCD turns on.

•To turn your camera off, press and

hold down the ON/OFF button ( );

the Status LCD screen will turn

blank, indicating the unit has

powered off.

AUTO POWER OFF

In order to extend the battery life, your camera is equipped with an

auto-shut off circuitry that will automatically shut off the power when

the camera is left unattended or untouched for more than 30

seconds.

Eye-Q Go Instr.Manual (English) 6/6/02 10:39 am Page 7

TAKING PICTURES

1. Turn your camera on ( )

and make sure the review

switch is in CAPTURE mode.

( )

The review switch should be in

the position furthest away from

the shutter button.

2. While looking into the

viewfinder, press the SHUTTER

BUTTON until the LED in the

viewfinder stops blinking and

you hear the camera beep.

The PICTURE COUNTER will

subtract one from the total

number of pictures available.

IMPORTANT: Hold the camera steady until you hear the camera

beep and the LED stops blinking, which indicates that the picture

has been taken.

Eye-Q Go Instr.Manual (English) 6/6/02 10:39 am Page 8
