CORBERO CCV3SL60 Scheda tecnica

Induction Hob

Instruction Manual / Installation Manual

MODEL:

CCV3SL60

Congratulations on the purchase of your new Induction Hob.

We recommend that you spend some time to read this Instruction / Installation

Manual in order to fully understand how to install correctly and operate it.

For installation, please read the installation section.

Read all the safety instructions carefully before use and keep this Instruction /

Installation Manual for future reference.

Product Overview

Top View

Control Panel

1. max. 1200/1500 W zone

2. max. 2300/2600 W zone

3. max. 3000/4000 W zone

4. Glass plate

5. Control panel

1. Heating zone selection controls

2. Timer control

3. Power / Timer slider touch

control

4. Boost control

5. keylock control

6. ON/OFF control

A Word on Induction Cooking

Induction cooking is a safe, advanced, efficient, and economical cooking

technology. It works by electromagnetic vibrations generating heat directly in

the pan, rather than indirectly through heating the glass surface. The glass

becomes hot only because the pan eventually warms it up.

Before using your New Induction Hob

• Read this guide, taking special note of the ‘Safety Warnings’ section.

• Remove any protective film that may still be on your Induction hob.

Using the Touch Controls

• The controls respond to touch, so you don’t need to apply any pressure.

• Use the ball of your finger, not its tip.

• You will hear a beep each time a touch is registered.

• Make sure the controls are always clean, dry, and that there is no object (e.g.

a utensil or a cloth) covering them. Even a thin film of water may make the

controls difficult to operate.

iron pot

magnetic circuit

ceramic glass plate

induction coil

induced currents

Choosing the right Cookware

• Only use cookware with a base suitable for induction

cooking. Look for the induction symbol on the

packaging or on the bottom of the pan.

• You can check whether your cookware is suitable by carrying out

a magnet test. Move a magnet towards the base of the pan. If it

is attracted, the pan is suitable for induction.

• If you do not have a magnet:

1. Put some water in the pan you want to check.

2. Follow the steps under ‘To start cooking’.

3. If does not flash in the display and the water is heating, the pan is suitable.

• Cookware made from the following materials is not suitable: pure stainless steel, aluminium or

copper without a magnetic base, glass, wood, porcelain, ceramic, and earthenware.

Do not use cookware with jagged edges or a curved base.

Make sure that the base of your pan is smooth, sits flat against the glass, and is

the same size as the cooking zone. Use pans whose diameter is as large as the

graphic of the zone selected.Using a pot a slightly wider energy will be used at

its maximum efficiency.If you use smaller pot efficiency could be less than

expected.Pot less than 140 mm could be undetected by the hob. Always centre

your pan on the cooking zone.

Always lift pans off the Induction hob – do not slide, or they may scratch the

glass.

Using your Induction Hob

To start cooking

1. Touch the ON/OFF control.

After power on, the buzzer beeps once, all displays

show “ – “ or “ – – “, indicating that the induction

hob has entered the state of standby mode.

2. Place a suitable pan on the cooking zone that

you wish to use.

• Make sure the bottom of the pan and the surface

Of the cooking zone are clean and dry.

3. Touching the heating zone selection control,

and a indicator next to the key will flash

4. Ajust heat setting by touching the the

slider control.

• If you don’t choose a heat setting within

1 minute, the Induction hob will

automatically switch off. You will need to

start again at step 1.

• You can modify the heat setting at any time

during cooking.

If the display flashes alternately with the heat

setting

• you have not placed a pan on the correct cooking zone or,

• the pan you’re using is not suitable for induction cooking or,

• the pan is too small or not properly centered on the cooking zone.

No heating takes place unless there is a suitable pan on the cooking zone.

The display will automatically turn off after 2 minutes if no suitable pan is

placed on it.

When you have finished cooking

1. Touching the heating zone selection

control that you wish to switch off

2. Turn the cooking zone off by touching the slider

to ”○”. Make sure the displayshows”0”

3. Turn the whole cooktop off by touching the

ON/OFF control.

4. Beware of hot surfaces

H will show which cooking zone is hot to touch. It will disappear when the

surface has cooled down to a safe temperature. It can also be used as an

energy saving function if you want to heat further pans, use the hotplate

that is still hot.

Using the Boost function

Actived the boost function

1. Touching the heating zone selection control

2. Touching the boost control ,the zone indicator show “b” and the power

reach Max.

Cancel the Boost function

1. Touching the heating zone selection control

that you wish to cancel the boost function

2. Touching the "Boost" control to cancel

the Boost function, then the cooking zone will

revert to its original setting.

• The function can work in any cooking zone

• The cooking zone returns to its original setting after 5 minutes.

• If the original heat setting equals 0, it will return to 9 after 5 minutes.

Locking the Controls

• You can lock the controls to prevent unintended use (for example children

accidentally turning the cooking zones on).

• When the controls are locked, all the controls except the ON/OFF control are

disabled.

To lock the controls

Touch the keylock control. The timer indicator will show “Lo“

To unlock the controls

1. Make sure the Induction hob is turned on.

2. Touch and hold the keylock control for a while.

3. You can now start using your Induction hob.

When the hob is in the lock mode,all the controls are disable except the

ON/OFF , you can always turn the induction hob off with the ON/OFF

control in an emergency, but you shall unlock the hob first in the next

operation

Over-Temperature Protection

A temperature sensor equipped can monitor the temperature inside the

Induction hob. When an excessive temperature is monitored, the Induction hob

will stop operation automatically.

Detection of Small Articles

When an unsuitable size or non-magnetic pan (e.g. aluminium), or some other

small item (e.g. knife, fork, key) has been left on the hob, the hob automatically

go on to standby in 1 minute. The fan will keep cooking down the induction hob

for a further 1 minute.

Auto Shutdown Protection

Auto shut down is a safety protection function for your induction hob. It shut

down automatically if ever you forget to turn off your cooking. The default

working times for various power levels are shown in the below table: .

Power level 1 2 3 4 5 6 7 8 9

Default working timer (hour)

8 8 8 4 4 4 2 2 2

When the pot is removed, the induction hob can stop heating immediately and

the hob automatically switch off after 2 minutes.

People with a heart pace maker should consult with their doctor before

using this unit.

Using the Timer

You can use the timer in two different ways:

• You can use it as a minute minder. In this case, it will not turn any cooking

zone off when the set time is up.

• You can set it to turn one or more cooking zones off after the set time is up.

• You can set the timer up to 99 minutes.

Using the Timer as a Minute Minder

If you are not selecting any cooking zone

1. Make sure the cooktop is turned on.

Note: you can use the minute minder even if you’re not selecting any

cooking zone.

Touch timer control , the “10” will show in the

timer display. and the “0” fiashes.

3. Set the time by touching the slider control. (e.g. 5)

6. When the time is set, it will begin to count down immediately. The display will

4. Touch timer control again, the “1” will flash.

5. set the time by touching the slider control (e.g.9), now the timer you set is 95

minutes.

show the remaining time

7. Buzzer will beep for 30 seconds and the timer indicator

shows “- - “ when the setting time finished.

Setting the timer to turn one or more cooking zones

off

If the timer is set on one zone:

1. Touching the heating zone selection control

that you want to set the timer for.

2. Touch timer control , the “10” will show in the

timer display. and the “0” fiashes.
