Coredy TA100 Scheda tecnica
Coredy TA100
Nano Travel Router/Access Point/ Repeater
V2.0
GET STARTED
Table of contents
Introduction.........................................................
Overview..............................................................
Environment Requirements...............................
Default Patameters.............................................
Mode Introduction..............................................
AP/Access Point Mode....................................
Repeater (Range Extender) Mode..................
Router Mode....................................................
Quick Installation................................................
AP (Access Point) Mode..................................
Repeater (Range Extender) Mode..................
Option 1. Using WPS..................................
Option 2. Using a Web Browser..................
Router Mode....................................................
Other Settings....................................................
WPS Connection Function..............................
Basic Settings..................................................
Login password settings..................................
Firmware Upgrade...........................................
Save/Load/Reset Settings...............................
Troubleshooting & Support...............................
WARRANTY.........................................................
CONTACT US......................................................
STATEMENT........................................................
1
1
3
5
5
5
6
7
8
8
12
13
16
21
27
27
28
29
30
31
32
36
36
37
-1-
Introduction
Overview
Coredy TA100 Nano Travel Router/Access
Point/Repeater has a ultra compact size,
mainly designed for travel. It could help
quickly create your own a secure a Wi-Fi
hotspot . TA100 could be powered by an
outlet via a charger (not incluced in the
package), a power bank, a power station or a
computer. And it provide up to 150Mbps
speed for video streaming, online gaming
and internet calls.
Package Contents
Coredy TA100 Nano Travel Router x 1
User Manual x 1
-2-
LED:
LED
ON: It is Power ON
OFF: It is Power OFF
Flashing:
In the WPS connecting mode
WPS: It is used to establish a secure Wi-Fi
connection between this TA100 and other
WPS capable devices, like Wireless Router,
AP, Cellphones and etc.
Reset: This button is used to restore the
TA100 to its factory default settings. With the
TA100 power on, using a paper clip or similar
LED
USB Cable
Router AP/Repeater
Router
AP/Repeater
Reset
LAN/ WAN
WPS
RESET
MODEL:CD565N1
-3-
Environment Requirements
small point to press and hold the Reset
button for 3~6 seconds, then release the
button and wait the TA100 to reboot to its
factory default settings.
Router AP/Repeater: You can select your
using mode physically.
LAN/WAN: Use this port to connect to your
Modem while in Router mode. In Access
Point mode, use it to receive network access
from your local network.
USB Cable: It is used to powering up the
TA100 Nano Router. It could be pluged into a
running computer, a powerbank or a power
outlet via a charger (not included in the
package) for power.
Place the TA100 in a well-ventilated place far
from any heater or heating vent.
-4-
Note: To minimize wireless interference,
place your Router/AP/Repeater in an open
space area, away from other Bluetooth
devices or radioactive devices such as
cordless phone, microwave, etc.
Place the TA100 in a location where it can be
connected to the various devices as well as
to a power source.
Avoid direct irradiation of any strong light
(such as sunlight)
Keep at least 2 inches (5 cm) of clear space
around the TA100.
Operating Temperature:0~40°C (32~104 °F )
Operating Humidity: 10%~90%RH, Non-
condensing.
Router
AP/Repeater
Keep away from
-5-
Default Patameters
Mode Introduction
AP/Access Point Mode
Create a wireless network from an Ethernet
connection. This mode is suitable for dorm
rooms or hotel rooms where there's already
a wired Router but you need a wireless
hotspot.
URL http://ap.setup
Default IP 192.168.10.1
Login Name admin
Password admin
Wireless SSID Travel Repeater
-6-
Repeater (Range Extender) Mode
Extend signal from an existing wireless
network, use a Different SSID or copy the
Same SSID of the existing Router’s
network.This mode is suitable to extend
wireless coverage, reaching devices that
were previously too far from your primary
Router to maintain a stable wireless
connection.
Note: It’s recommended to use an SSID
different from your Router.
Router
AP/Repeater
Power
INTERNET
-7-
Router Mode
Create an instant private wireless network
and share Internet to multiple Wi-Fi devices.
This mode is suitable for hotel rooms and
home networks.
Router
AP/Repeater
Power
INTERNET
Router
AP/Repeater
Power
INTERNET
-8-
Quick Installation
AP (Access Point) Mode
1. Power On
Note: Please be sure your TA100 is restored
to factory default settings before getting
start.
Switch the TA100 to the AP/Repeater
mode. Plug the USB of TA100 into an
outlet via a charger (not included in the
package), a Power Bank or a computer for
Power, the LED would be ON; and wait
about 12 seconds until the LED flash
once.
Router
AP/Repeater
Power
Router
AP/Repeater
Power Supply:
Max. Power Input:
5V~2A
