Creative Muvo Muvo Micro 1GB Manuale utente

English

Your Player At A Glance

1. Play/Pause button Press and hold to turn the player on and off.

Press once to start playing tracks, and press again to pause

playback.

2. Microphone A built-in microphone that lets you make digital voice recordings.

3. LCD Displays menu options.

4. Volume Decrease button Press to decrease the volume.

5. Volume Increase button Press to increase the volume.

6. Scroller Turn the Scroller to scroll through menu options and press the

Scroller to select them. This action is also referred to as "Scroll

Select".

During playback, turn the Scroller to move between tracks, or

turn and hold the Scroller to move within a track.

Pager S CLE QS.book Page 1 Friday, October 8, 2004 7:34 AM

Using the Scroller

You can use the Scroller to select menu options. We use the term “Scroll Select” when we

want you to use the Scroller to scroll to a menu option, and then select it by pressing the

Scroller.

1. Turn the Scroller to scroll through menu options on your LCD until the option that

you want, such as Play Mode , is highlighted.

2. Press the Scroller to select this menu option.

7. Headphone jack Connect headphones to this jack.

8. Line In jack Connect external stereo sources, such as cassette players, CD

players and MiniDisc players, to this jack. Note that this is not a

digital (optical) input jack.

This jack is only found on MuVo N200 players.

9. USB port Connect your computer to this port using the supplied USB

cable.

Pager S CLE QS.book Page 2 Friday, October 8, 2004 7:34 AM

Getting Started

1Set up computer

DO NOT connect your player to your computer before setting up the software.

1. Turn on your computer.

2. If you have Windows XP or Windows 2000, you must log in as an administrator in

Windows before you can set up the software. For more information, refer to your

operating system’s online Help.

3. Insert the Installation and Applications CD into your CD-ROM/DVD-ROM drive. Your

CD should start automatically. If it does not, follow the steps below:

i. Start Windows Explorer.

ii. On the left pane, click the My Computer icon.

iii. Right-click the CD-ROM/DVD-ROM drive icon, and then click AutoPlay.

4. Follow the instructions on the screen.

5. If prompted, restart your computer.

Windows 98 SE users must install a device driver before using the player. This driver is

automatically installed when you set up the software on Windows 98 SE.

Pager S CLE QS.book Page 3 Friday, October 8, 2004 7:34 AM

2Insert battery

Use one AAA alkaline battery with your player.

When you turn on your player for the first time, the menu will be in English.

To change the language

1. Press the Scroller. The main menu appears.

2. Scroll Select the Settings option .

3. Scroll Select the Language option .

4. Scroll Select the language that you want.

Pager S CLE QS.book Page 4 Friday, October 8, 2004 7:34 AM

3Transfer music

1. Flip open the rubber cover of your player’s USB port.

2. Connect your player to your computer’s USB port using the supplied USB cable.

Do not press the buttons on your player while connecting it to your computer.

3. Start Windows Explorer on your computer.

You will notice that your player is recognized as a Removable Disk in Windows

Explorer.

Your computer’s

USB port may be

located on the front,

back or side panels.

Pager S CLE QS.book Page 5 Friday, October 8, 2004 7:34 AM

4. Transfer audio files (MP3 or WMA files) to your player using a drag-and-drop

operation.

You can also transfer data files using Windows Explorer. For more information about

using Windows Explorer, refer to its online Help.

5. For more advanced song management tasks, you can use Creative MuVo Media

Explorer or Creative MediaSource Player/Organizer. Creative MediaSource Player/

Organizer is your digital music center for playing, creating, organizing and transferring

digital music. To launch Creative MediaSource Player/Organizer, double-click the

Creative MediaSource Player/Organizer shortcut icon on your desktop.

For more information about using Creative MediaSource Player/Organizer, refer to its

online Help.

WMA files with Digital Rights Management (DRM) cannot be copied to your player using

Windows Explorer. You can only do so with applications that support this technology,

such as Creative MuVo Media Explorer, Creative MediaSource Player/Organizer, or

Windows Media Player.

Pager S CLE QS.book Page 6 Friday, October 8, 2004 7:34 AM

4Disconnect player

Before disconnecting your player from your computer, use the Windows Eject or Safely

Remove Hardware icon on the Taskbar to safely disconnect your player. If not, your

player may not be able to function normally. Follow these steps below to safely disconnect

your player.

To stop your player in Windows XP, Windows 2000 or Windows Me: Click the Safely

Remove Hardware icon on the Taskbar, click Safely remove USB Mass Storage

Device, and disconnect your player when you are prompted to do so.

To stop your player in Windows 98 SE: In Windows Explorer, right-click the

Removable Disk icon, click the Eject option, and disconnect your player when you are

prompted to do so.

Make sure that this status diagram appears on the LCD for at least

five seconds before disconnecting your player.

Pager S CLE QS.book Page 7 Friday, October 8, 2004 7:34 AM

5Play music

1. Press and hold the Play/Pause button until your player turns on.

The CREATIVE logo appears on the LCD, followed by the MuVo logo. Music stored in

your player starts playing automatically. Note that your player comes preloaded with

some music to get you started.

2. Press the Volume Increase and Volume Decrease buttons to adjust the volume.

3. After you have finished using your player, press and hold the Play/Pause button

until the Power off message disappears.

• Remember to set the volume at a moderate level. Listening to music at high volumes

can impair your hearing.

• For your safety and the safety of others, do not use headphones while driving, cycling

or any other activity that requires your full attention.

Pager S CLE QS.book Page 8 Friday, October 8, 2004 7:34 AM

Some Basic Functions

Playing music

1. Press the Scroller. The main menu appears.

2. Scroll Select the Music option .

3. Scroll to the audio track that you want to play and press the Play/Pause button .

Listening to FM radio

(FM radio is available on MuVo N200 players only.)

You can automatically scan for all available radio stations and save up to 32 radio presets.

1. Connect headphones to the Headphone jack.

2. Press the Scroller. The main menu appears.

3. Scroll Select the FM Radio option .

4. Press the Scroller and Scroll Select the Autoscan option . The player scans and

stores all radio stations that it can receive. At the end of the autoscan, it automatically

saves all stations as presets and tunes in to the first preset.

5. Turn the Scroller to select the preset station you want.

If you are using your player in Japan, you will need to change the FM region setting.

1. Press the Scroller. The main menu appears.

2. Scroll Select the Settings option .

3. Scroll Select the FM Region option and switch to the Japan setting.

Pager S CLE QS.book Page 9 Friday, October 8, 2004 7:34 AM

MP3 encoding

(Direct MP3 encoding is available on MuVo N200 players only.)

You can directly encode or "rip" music to your player, instead of ripping music on your

computer first and then transferring it to your player.

1. Connect the Line In jack on your player to the line output of an external stereo

source, such as a CD or MiniDisc player, using the supplied Stereo cable.

2. Press the Scroller. The main menu appears.

3. Scroll Select the MP3 Encoding option .

4. Press the Play/Pause button to start the encoding. An encoding progress bar

appears on the LCD and encoding starts.

5. On your external stereo source, start playing the song you want to encode.

6. Press the Play/Pause button to end the encoding.

The first encoded track is named EN001, the second encoded track is named EN002,

the third encoded track is named EN003, and so on.

Locking your player

Locking your player disables all buttons on your player except the Scroller. Lock your player

when you want to prevent buttons from being accidently pressed.

1. Press the Scroller. The main menu appears.

2. Scroll Select the Lock option .

appears at the top right corner of the LCD.

3. To unlock your player, press any button and Scroll Select the Unlock option .

For more information, read the User’s Guide in the Installation CD.

Go to d:\manual\<language>\manual.chm (replace d:\ with the drive letter of your CD-ROM/

DVD-ROM drive, and <language> with the language the document is in)

Pager S CLE QS.book Page 10 Friday, October 8, 2004 7:34 AM
