Creative WebCam NX Pro Manuale utente

1. Overview

Front view Side view

Figure 1: Understanding your Creative WebCam NX Pro

USB

connector

Front

LED

Lights up

when the

camera is

connected

to the

computer

Focus ring

Adjusts the

view focus

Hinged lever

Fold this in when

placing camera

on flat surfaces

LCD

monitor

Hinged lever

Snapshot button

Press this to capture images

Figure 2: Connecting Creative WebCam NX Pro

USB port

For more details

on using your

camera, read the

User’s Guide PDF:

D:\manual\English\

manual.pdf

CD-sized.fm Page 1 Thursday, May 1, 2003 11:44 AM

2. Installing Software and Hardware

Installing Software

Do not connect the camera to your

computer yet!

1. Insert the Installation CD into your CD-

ROM drive. Do not connect your

camera to your computer yet.

2. Click the names of the drivers and

applications you want to install in your

computer.

3. Follow the instructions on screen to

complete the installation. When asked if

you want to restart your computer,

select No until all selected drivers and

applications are installed.

Installing Hardware

1. Position your camera on a firm surface,

using the hinged lever for support if

necessary.

2. Connect your camera to an available

USB port on your computer. Windows

automatically detects the device.

•In Windows 2000 only:

When Digital Signature Not

Found dialog boxes appear, click the

Ye s button.

•In Windows XP only:

If the Found New Hardware

Wizard dialog box appears, select

the Install the software

automatically (Recommended)

option and click the Next button.

Verifying the installation

1. Right-click the My Computer icon on

your desktop.

2. In the menu that appears, click the

Properties option.

•In Windows 98/98 SE/Me only:

In the System Properties dialog

box, click the Device Manager tab.

•In Windows 2000 and XP only:

In the System Properties dialog

box, click the Hardware tab. Click

the Device Manager button.

3. Click the plus(+) sign next to the

Imaging Device icon. Two entries for

your camera should appear. If not,

repeat the installation steps.

•In Windows 2000 and XP only:

Click the plus(+) sign next to the

Universal Serial Bus controllers

icon. An entry for your camera

should appear. If not, repeat the

installation steps.

CD-sized.fm Page 2 Thursday, May 1, 2003 11:44 AM

3. Basic Usage

As a Web Camera

Be sure that your camera is connected to

your computer and operating properly.

1. Start PC-CAM Center by pressing the

Snapshot button on the camera.

2. In the PC-CAM Center window, click

the Live Video button. The current

camera view is displayed in the Viewing

window.

3. In the Video size box, select a suitable

resolution.

4. In the Save video in box, select the

destination album for your video.

5. To start recording a video, click the

Capture video button. The button

starts blinking to indicate that recording

is now in progress.

6. To stop the recording, click the button

again. The button stops blinking. By

default, the video is saved automatically

and added to the destination album.

To p r e v i e w a V i d e o

1. Click the Save automatically check

box to clear it, if you want to preview

each video before deciding whether to

save it to the destination album.

2. Click the Capture video button to

start recording.

3. After you stop recording, click the Play

button on the bottom-left corner of the

Live Video window to preview the

video.

4. If you wish to store it in the destination

album, click the Save button after

previewing the video.

At the time of this product's release, Microsoft

strongly encouraged companies to submit their

hardware solutions for certification. If a hardware

device driver is not submitted, or does not qualify, for

Microsoft certification, a warning message similar to

the one shown here, appears. You may see the

message when installing this driver. If you do, you may

choose to click the Continue Anyway button.

Creative has tested this driver on Windows XP, and

it does not impair or destablize your computer.

For Windows®XP®users

CD-sized.fm Page 3 Thursday, May 1, 2003 11:44 AM

As a Still-Image Camera

Be sure that your camera is connected to

your computer and operating properly.

1. Start PC-CAM Center by pressing the

Snapshot button on the camera.

2. In the PC-CAM Center window, click

the Live Video button. The current

camera view is displayed in the Viewing

window.

3. To capture the image shown in the

viewing window, click the Snap an

image button at the bottom of the

window. By default, the photo is saved

automatically and added to the

destination album.

To p r e v i e w a P h o t o

1. Click the Save automatically check

box to clear it, if you want to preview

each photo before deciding whether to

save it to the destination album.

2. Click the Snap an image button to

take a photo. A preview of the photo is

shown at the bottom-left corner of the

Live Video window.

3. Click the Save button if you wish to

store it in the destination album.

For more details on using your camera, read

the User’s Guide PDF:

D:\manual\English\manual.pdf

Enjoy a host of benefits by registering your

product during installation, or at

http://www.creative.com/register.

Benefits include:

•Service andproductsupport fromCreative

•Exclusive updates on promotions and

events.

Technical Support and Warranty

For Technical Support information, go to

D:/Support/Language/Support.pdf (where D:

represents your CD-ROM drive and

<Language> represents the language that

your document is in).

For Warranty information, go to

D:/Warranty/Region/Language/Warranty.pdf

(where D: represents your CD-ROM drive,

<Region> represents the region that you are

in, and <Language> represents the language

that your document is in).

Please keep your Proof of Purchase for

the duration of the warranty period.

registeredtrademarks of MicrosoftCorporation.All other brand and product names are trademarks

or registered trademarks of their respective holders and are hereby recognized as such.

CD-sized.fm Page 4 Thursday, May 1, 2003 11:44 AM
