Crestron UC-2-Z Manuale utente

The Crestron® UC-2-Z(-I) is a tabletop conference device included in

select Crestron Flex conference systems.

For instructions on system connection and configuration, refer to the

system's Quick Start Guide listed below:

lUC-MM30-Z(-I) and UC-MM30-Z-L(-I)

lUC-MMX30-Z(-I) and UC-MMX30-Z-L(-I)

In the Box

1 UC-2-Z(-I), Crestron Flex Tabletop Conference Device for

Zoom Rooms™ Systems

Additional Items

1 PoE+ Injector (2055605)

2 Cable, CAT5e, RJ-45 - RJ-45, 11.8 ft (3.6 m) (2056204)

1 Cable, USB 2.0, A - Micro B, 5.8 ft (1.8 m) (2055579)

Buttons and Indicators

Tap one of the four mute buttons located at each corner of the device to

mute or unmute the integrated microphone.

A light bar is located above the screen. LEDs are located behind the

mute buttons and light bar and will respond to muting or unmuting the

microphone.

The four mute buttons and the light bar will display red or green to

indicate the following states:

lLighted green: The microphone is unmuted.

lLighted red: The microphone is muted.

lFlashing green: The device is powering on.

UC-2-Z(-I) QuickStart

Crestron Flex Tabletop Conference Device for Zoom Rooms™ Systems

Factory Reset the Device

A factory reset may be performed when troubleshooting the conference

device.

To perform a factory reset on the conference device:

1. Power cycle the device by disconnecting and reconnecting the CAT5e

cable from the conference device.

2. When the device powers on and the LEDs flash green, tap the button

below the Crestron® logo 10 times. A factory reset confirmation

screen appears.

3. Tap one of the mute buttons to move the selector on the factory

reset confirmation screen to Yes. Tap the button below the Crestron

logo to confirm the factory reset.

4. The device will reboot. Configure the device according to the Crestron

Flex system's Quick Start Guide.

Visit the Product Page

Scan the QR code to visit the Crestron Flex conference system's product

page.

UC-MM30-Z

www.crestron.com/model/6511341

UC-MM30-Z-I

www.crestron.com/model/6511342

UC-MM30-Z-L

www.crestron.com/model/6512206

UC-MM30-Z-L-I

www.crestron.com/model/6512307

UC-2-Z(-I) QuickStart

Crestron Flex Tabletop Conference Device for Zoom Rooms™ Systems

UC-MMX30-Z

www.crestron.com/model/6511631

UC-MMX30-Z-I

www.crestron.com/model/6511632

UC-MMX30-Z-L

www.crestron.com/model/6512190

UC-MMX30-Z-L-I

www.crestron.com/model/6512191

Additional Information

Original Instructions

The U.S. English version of this document is the original instructions.

All other languages are a translation of the original instructions.

Regulatory Model: M201928001

Crestron product development software is licensed to Crestron dealers and Crestron

Service Providers (CSPs) under a limited nonexclusive, nontransferable Software

Development Tools License Agreement. Crestron product operating system software is

licensed to Crestron dealers, CSPs, and end-users under a separate End-User License

Agreement. Both of these Agreements can be found on the Crestron website at

www.crestron.com/legal/software_license_agreement.

The product warranty can be found at www.crestron.com/warranty.

The specific patents that cover Crestron products are listed at

www.crestron.com/legal/patents.

Certain Crestron products contain open source software. For specific information, visit

www.crestron.com/opensource.

Crestron and the Crestron logo are either trademarks or registered trademarks of

Crestron Electronics, Inc. in the United States and/or other countries. Zoom Rooms is

either a trademark or registered trademark of Zoom Video Communications, Inc. in the

United States and/or other countries. Other trademarks, registered trademarks, and

trade names may be used in this document to refer to either the entities claiming the

marks and names or their products. Crestron disclaims any proprietary interest in the

marks and names of others. Crestron is not responsible for errors in typography or

photography.

Doc. 8783A

09/29/21

UC-2-Z(-I) QuickStart

Crestron Flex Tabletop Conference Device for Zoom Rooms™ Systems
