Crosley KAMELEON Manuale utente

SET UP

ABOUT YOUR KAMELEON 6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

BATTERIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

THE KEYPAD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 9

• “EL” Screen activation setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

(Activation by touching screen and remote simultaneously and/or by keypress)

• “EL” Screen brightness adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

• “EL” On time setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

• SETTING UP THE KAMELEON 6 . . . . . . . . . . . . . . . Page 10

(How to set up the KAMELEON 6 to control your devices)

• Search Method . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

SET-UP CODES

• Televisions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

• Video Recorders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

• Satellite Receivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

• Cable Converters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

• Video Accessory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

• CD/Mini Disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

• Phonograph Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

• Miscellaneous Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

• Home (accessory) Automation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

• Amplifiers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

• Amp/Tuners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

• Cassette Players . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

• Laser Disc (LD) Players . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

• Digital Audio Tape (DAT) Players . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

• DVD Players . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

CODE BLINK OUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

(To find out wich code is currently programmed)

QUICK CODE REFERENCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

LEARNING FEATURE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 - 15

(How to copy functions from your original working remote

onto the KAMELEON 6)

EXTRA FEATURES

• Mode re-assignment

(How to set up two of the same devices on the KAMELEON 6). . . . . . 16

• Colour & Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

• Channel +/- simulation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

• Volume Punch-Through . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

• Device Sleeptimer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

• KAMELEON 6 - Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

• KAMELEON 6 - Recall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

• Macros (sequence of commands) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 - 22

• Code upgrade technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

• Key Magic® (How to program missing functions) . . . . . . . . . . . . . . . . . 24

TROUBLE-SHOOTING

• Problem & Solution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

TABLE OF CONTENTS

English

WWW.ONEFORALL.COM 1

Kameleon_6_nieuw_2004_11x23 Eur 23-08-2004 11:12 Pagina 1

2WWW.ONEFORALL.COM

About Your KAMELEON 6

Easy to use unique “EL” display

By choosing the ONE FOR ALL KAMELEON 6 universal remote control you have

opted for easy use. Your KAMELEON 6 features a unique, user-friendly backlit

display, which ensures you have easy access to all the keys you need, whilst

hiding those you don’t. Made of the strictest quality, it will provide long-term

satisfaction. After replacing batteries, you will need to first press any key before

the screen will light up. From then on, the display will automatically illuminate

whenever the remote is picked up (touching screen and remote simultaneously).

It is also possible to change the activation-mode into activation by key press. To

set the ”EL” display to activation by key press, see page 3, section: ”EL” screen

activation setting. Also, this product comes with a build-in light sensor which

will increase the brightness in a bright environment and decrease the brightness

in a dark environment.

Controls up to 6 devices

Your KAMELEON 6 is designed to let you use one remote to operate your Video

and Audio equipment; any device designed to be operated by an infrared signal.

Your KAMELEON 6 comes with 2 IR (infra-red) wide range transmitters for

maximum range and is High Frequency capable up to 450 kHz. You can choose

any combination of six devices you would like to operate (see page 10 for more

information).

Learning feature

The KAMELEON 6 comes equipped with the unique “learning feature”, which

means that you can copy almost any function (max. ± 30) from your original

(working) remote control onto your new KAMELEON 6 (See “Learning Feature”

on page 13). This comes in handy, when after having setup your KAMELEON 6

you may find that some functions from your original remote are missing on your

KAMELEON 6 key pad.

Macros (sequence of commands)

Your KAMELEON 6 comes with an easy-to-use Macro feature, allowing you to

send several commands with the press of a single key (for example turning a few

devices on or off). You can use the custom keys (A, B, C) for this feature. Once

you programmed a macro on one of these keys, the sequence will be performed

in every mode.

Code upgrade technology

Your ONE FOR ALL KAMELEON 6 also offers a Code upgrade technology. This

technology gives you the possibility to add codes to the memory. If your

device uses a particular code which is not found in the KAMELEON 6 memory

(using the “Direct code set up” on page 10 or the “Search Method” on page

11) you may use the ”Code Upgrade Technology” (see page 23). Thanks to this

technology your KAMELEON 6 will never become obsolete.

Your KAMELEON 6 requires 2 AA/LR6 alkaline batteries.

1. Push the battery door upwards and lift it up to remove it.

2. Match the batteries to the (+) and (–) marks inside the battery case, then

insert the batteries.

3. Replace the battery cover by pushing downwards and allowing it to click

back into position.

-After re-installing the batteries, the entire ”EL” display will be lit for a

duration of 6 seconds upon the first key press after which it will default to

the TV mode.

Low Voltage Indicator

As soon as the batteries run out of power the KAMELEON 6 will indicate this.

The IR indicator will flash 5 times whenever you press a key.

Please make sure to replace them with 2 new AA/LR6 alkaline batteries.

Batteries

Kameleon_6_nieuw_2004_11x23 Eur 23-08-2004 11:12 Pagina 2

WWW.ONEFORALL.COM 3

“EL” Screen brightness adjustment

To increase or decrease the brightness of the KAMELEON 6 “EL” screen:

1. Press and hold the MAGIC key until the rabbit

comes out of the hat (the screen will change to

the setup screen).

2. Press BRIGHT.

3. -> To increase the brightness of the “EL” screen press

and hold CH+.

-> To decrease the brightness of the “EL” screen press

and hold CH-.

4. Press ESC to store the brightness setting and return to the

setup screen.

- Increasing the brightness of the KAMELEON “EL” panel can decrease the battery

life. Battery life varies from 3 - 12 months (depending on brightness setting and

usage).

This product features an “EL” panel (Electro Luminescence technology) which is

activated by touching screen and remote simultaneously and/or by keypress. In

order to save battery life, the “EL” screen will stay illuminated for 8 seconds

during normal use. If you want you can change the “EL” Screen activation

setting from activation by touching screen and remote simultaneously and/or

by keypress. If you want you can also change the “EL” On time setting. It is

also possible to adjust the “EL” Screen brightness-settings on the

KAMELEON 6 “EL” panel. One of the key features of the KAMELEON 6 is the

“EL” display, which changes to suit the device you are controlling. The overview

on page 4 and 5 will show you all the possible screens and the functions that

you will obtain.

“EL” Screen activation setting

The KAMELEON 6 features an “EL” panel which is activated by touching screen

and remote simultaneously or by keypress.

It is possible to lock the KAMELEON 6 to one activation setting:

1. Press and hold the MAGIC key until the rabbit

comes out of the hat (the screen will change to

the setup screen).

2. Press OTHER.

3. Now press 9 8 9. The IR Indicator will blink twice (or 4 times).

-> If the animated IR Indicator blinks twice the “EL” panel will be activated only

by touching screen and remote simultaneously.

-> If the animated IR Indicator blinks four times the “EL” panel will be activated

only by keypress.

Simply perform these steps to lock the KAMELEON 6 to the activation

setting that you prefer.

The Keypad

= MAGIC (hat) key

= The animated IR Indicator that will light up during

programming

Kameleon_6_nieuw_2004_11x23 Eur 23-08-2004 11:12 Pagina 3

4WWW.ONEFORALL.COM

The Keypad

TVVCR

WWW.ONEFORALL.COM 5

The Keypad

SAT

6WWW.ONEFORALL.COM

1. IR (infra-red) Indicator

The IR Indicator animates when IR is being “sent” or

“received”. The KAMELEON 6 animated IR Indicator will

show “outgoing IR” whenever a function key is pressed.

When using the “Learning Procedure” the animated IR

indicator will show “incoming IR”. The IR Indicator will

give feedback when keys are pressed both during normal

use and in programming mode (the bottom part of the IR

indicator will blink).

2. Device keys

The TV, VCR, SAT, DVD, CD and AUD keys select the device

to be controlled. For example pressing the TV key allows

the remote to control the functions of your Television,

after pressing VCR you can operate your Video Recorder,

after pressing the SAT key you can operate your Satellite

Receiver or Cable Converter etc. (see page 10 for more

details). After pressing a device (mode) key on your

KAMELEON 6 the applicable device icon will light up, to

show the currently activated mode. Pressing the device key

will allow you to return to the main screen (TV, VCR, SAT,

CD, AUD modes).

3. MAGIC (in ”shifted” or ”programming” mode)

The MAGIC key is used to set up your KAMELEON 6 and to

access special functions. If you press this key shortly, the

screen will go into ”shifted” mode (for 10 seconds) which

will give access to some secondary functions such as color,

brightness and sleeptimer.

Programming mode

If you press the MAGIC key longer (about 3 seconds),

the KAMELEON 6 will go into ”programming” mode.

The screen will change to the “setup screen” and the

rabbit appears.

You will obtain the following setup functions:

4. SCROLL

The SCROLL key gives you the possibility to move through

the different screens (if applicable) within a certain mode

during normal use and programming mode. This only

applies in TV, VCR, SAT, CD and AUD modes.

The Keypad

DEV SET

MODE

KEY MAGIC

MACRO

BRIGHT

IR LEARN

IR DELETE

VOLUME

OTHER

• Device Setup mode

• Search Method

• Mode re-assignment

• How to program missing functions

• How to setup a key (A, B or C) with a Sequence

of commands

• “EL” Screen brightness adjustment

• How to copy functions from your original working

remote onto the KAMELEON 6

• Deleting learned function

• Volume punch through feature

• Channel simulation

• Variable EL On time (4 sec, 8 sec, 12 sec, 16 sec, 20 sec)

• Operational Reset

• KAMELEON 6 - Timer

• EL screen activation setting

• Code Verification

• Modem Upgrade

WWW.ONEFORALL.COM 7

5. POWER (in shifted mode; Sleeptimer)

The POWER key controls the same function as on your

original remote. In shifted mode (accessed by pressing

MAGIC shortly and releasing it) the POWER key becomes

the Sleeptimer function (see page 19).

6. PP / RANDOM

In TV and SAT mode this key may feature the “Last

Channel”, “Previous Program” or “Recall” function

(depending on your original remote control). In CD, AUD

and DVD mode you will obtain the RANDOM (or shuffle)

function.

7. PVR / PRESET / EJECT

In SAT mode the “PVR” key will change the screen into

SAT PVR (Personal Video Recorder), which will bring up the

transport functions (REW, PLAY, FF etc.). If your digital

satellite receiver or cable converter has a built in recording

function, you can operate it with these keys.

In AUD mode, the PRESET key will change to the

PRESET/MENU screen allowing access to the PRESETS 1 - 9,

0 and +10 on the digits. If available on your original

remote you will obtain the EJECT function (in VCR, CD,

DVD modes).

8. 16:9 / PROG

In TV mode you will obtain the 16:9 (screen format) func-

tion. In VCR, DVD, AUD and CD mode you will obtain the

PROG (program) function.

9. TV/SAT / TV/VCR / TV/DVD

In SAT mode you will obtain the TV/SAT function. In VCR

mode you will obtain the TV/VCR function. In DVD mode

you will obtain the TV/DVD function.

10. INFO / TIMER / BACK

In SAT and DVD mode you can select the “info” function.

In VCR mode you will obtain the TIMER RECORD or TIMER

ON/OFF function. In SAT menu mode you may use the

“back” key to go to the previous menu screen.

11. FAV / SP/LP

In SAT mode you will obtain the FAV (favourite) function.

In VCR mode you will obtain the SP/LP (tape speed)

function.

12. AUDIO / TUNE -

In DVD, SAT and AUD mode you will obtain the “Audio”

function. In AUD mode you will obtain the “TUNE –“

function in the preset/Menu screen.

13. GUIDE / DSP

In SAT mode the “GUIDE” key will change the screen into

SAT-menu mode and give you the “Guide” function, if

available on your original remote. In DVD mode you will

obtain the “Guide” function, if available on your original

remote. In AUD mode you will obtain the “DSP” function.

14. SUBT. / TUNE +

In SAT, DVD and AUD main mode you will obtain the SUB-

TITLE function. In AUD mode you will obtain the “TUNE +”

function in the preset/Menu screen.

The Keypad

( )

Kameleon_6_nieuw_2004_11x23 Eur 23-08-2004 11:13 Pagina 7

8WWW.ONEFORALL.COM

15. MENU

Pressing this key will allow you to operate the Menu and

in TV, VCR, CD, AUD and SAT mode will also change the

screen to the menu mode. The MENU key operates the

same function it did on your original remote control.

16. EXIT

The EXIT key will operate the same as on your original

remote. To return to the main screen (TV, VCR, SAT, CD,

AUD mode) press the device key or use the SCROLL key.

17. MUTE

The Mute key operates the same function it did on your

original remote control.

18. CH +/- (in shifted mode; brightness +/-)

These keys operate just as those on your original remote.

In shifted TV mode (accessed by pressing MAGIC shortly

and releasing it) these keys may provide you the bright-

ness +/- function.

19. CENTRE / REAR

In AUD mode these keys will (if available on your original

remote) allow you to adjust the CENTRE and REAR levels

of your speaker(s).

20. SURROUND / OK

If available on your original remote this key will allow you

to access the surround mode of your device. In menu

mode this key will confirm your choice. On some

devices you can confirm your menu option simply by press-

ing MENU.

21. Directional keys

If available on your original remote control, these keys will

allow you to navigate through the menu. On some TV’s

you may have to press CH+/- and VOL+/- keys OR the color

keys (red, green, yellow, blue) to navigate through the

menu, depending on your model of TV.

22. VOL +/- (in shifted mode; colour +/-)

The volume keys operate just as those on your original

remote. In shifted TV mode (accessed by pressing MAGIC

shortly and releasing it) these keys may provide you the

colour +/- function.

23. Number keys / INPUT (in prog. Mode; setup features)

The number (1 – 9, 0) keys provide functions just like your

original remote. In AUD mode, the number (1 – 9, 0, +10)

keys may provide (if available on your original remote) an

INPUT function (TUNER, CD etc.). If your original remote

features an “function select” or “input select” function

you may find this under the SEL key. When in program-

ming mode the digit keys will display the various

setup features.

24. -/-- / +10

If your original remote uses one/two digit input switching

(-/-- symbol), this function can be obtained by pressing

the -/-- key. In DVD, CD or AUD mode you will obtain the

+10 function.

25. AV / SEL (input select)

The AV key operates the same function it did on your orig-

inal remote control. If your original remote uses a 20 key,

this function can be found by pressing the AV key. If your

original audio remote comes with a “function select” or

“input select” function, you can obtain this pressing the

SELECT key.

The Keypad

( )

Kameleon_6_nieuw_2004_11x23 Eur 23-08-2004 11:13 Pagina 8

WWW.ONEFORALL.COM 9

The Keypad

26. ESC

This key only appears in programming mode and is used to

return to the Setup screen or to exit programming mode.

27. Teletext Keys

These keys are used to operate the main teletext

functions. Of course, your Television must have teletext

capability. For a more detailed explanation of teletext and

fastext, please refer to the manual of your television.

Remember, different televisions control teletext and

fastext functions in different ways. Not all of the teletext

functions may be available on your particular model.

EXPAND: Shows the top half of the teletext page

in larger letters. By pressing again, you

can see the bottom half of the teletext

page enlarged. To return to regular

teletext viewing, press the EXPAND key

again, or press the TEXT ON key,

depending on your television.

TEXT ON: In TV mode: once in text mode, pressing

this key may switch to MIX or TURN OFF

text, depending on your television. This

function is also available in SAT mode.

HOLD/STOP: Stops changing pages.

MIX: Shows both text and TV picture.

TEXT OFF: In TV mode: switches the television back

to regular viewing mode. On some

televisions this may be done by pressing

the “TEXT ON” key several times. This

function is also available in SAT mode.

TEXT INDEX: This key will give you access to the index

function within the text mode.

28. Red / Green / Yellow / Blue

When accessing the text mode, the colour keys marked

red, green, yellow and blue, allow you to access the

fastext functions of your television. If on your original

remote control these keys are used for Menu navigation,

the KAMELEON 6 Fastext keys may operate the same.

29. Transport keys (PLAY, STOP etc.)

When in VCR, DVD, SAT (”PVR”), CD or AUD mode;

these keys operate the transport functions (PLAY, FF, REW

etc.) of your device. To prevent accidental recording, the

RECORD key must be pressed twice to start recording.

30. SKIP (+/-)

These keys operate just as those on your original remote.

In SAT (”PVR”), CD, AUD and/or DVD mode they will

function as SKIP (TRACK) +/- keys.

31. Custom keys (A, B, C)

The custom keys are spare keys that give you the

possibility to customize the KAMELEON 6 according to

your original remote control using the “Learning feature”

(see page 13) or ”Key Magic®” (see page 24). These keys

are also ideal for use as “Macro keys” (see page 21).

10 WWW.ONEFORALL.COM

Example: To set up the KAMELEON 6 for your television:

1. Make sure your television is switched ON (not on standby).

2. Find your device code in the Codelist (page 26 - 52). Codes are listed

by device mode and brand name. The most popular code for each brand is

listed first. If your brand is not listed at all in the code section, try the Search

Method on page 11.

3. Press and hold down the MAGIC key

(for about 3 seconds) until the rabbit comes

out of the hat (the screen will change to the setup screen).

4. Press the DEV SET key.

5. Press and release the TV key to select the device type you like

to setup.

6. Enter your four-digit code using

the number keys. The animated IR Indicator

will blink twice.

7. Now, aim your KAMELEON 6 at your television and try the

following keys to test if the KAMELEON 6 will work with your

device;

• CHANNEL +, CHANNEL-

• VOLUME +, VOLUME -

• MUTE

• POWER.

8. If your device is responding, press OK to save the code. If your

device does not respond, just enter the next code listed under

you brand. If none of the codes listed for your brand operate

your device, then try the Search Method described on page 11.

9. Press ESC twice to return to user mode (all keys are

displayed), OR press a device key to select the next

device you like to setup.

- Most TV’s do not switch back on pressing the POWER key, please try

pressing “CHANNEL+” key to switch your TV back on.

- Some codes are quite similar. If your device does not respond or is not

functioning properly with one of the codes, try another code listed under

your brand.

- To set up your other devices, follow the same instructions above, only press

the appropriate device key during step 5.

- Remember to press the correct device key before operating your device.

Only one device can be assigned to a device key.

Setting up the KAMELEON 6

(How to set up the KAMELEON 6 to control your devices)

To set up a second TV, VCR, SAT, CD, AUD or DVD (See page 16).

Television

Video Recorder / Cassette Player / DAT Player

Satellite Receiver

Cable Box

Video Accessory

CD Player / Mini Disc

Home Accessory

Phonograph Player

Amp/Tuner / Amplifier / Miscellaneous

DVD Player

Laser Disc

____

(x2)

Kameleon_6_nieuw_2004_11x23 Eur 23-08-2004 11:13 Pagina 10

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Crosley Telecomando

Crosley

Crosley SA40699 Manuale utente

Manuali Telecomando popolari di altre marche

Panasonic

Panasonic EUR7622KB0 Manuale utente

Bang & Olufsen

Bang & Olufsen Beo4 Manuale utente

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuale utente

Multiplex

Multiplex PROFI TX 9 Manuale utente

One Remote

One Remote RMB4 Manuale utente

FUTABA

FUTABA 9ZAP - PART2 Manuale utente

HR Matic

HR Matic HR MULTI 3 Manuale utente

Yamaha

Yamaha ACC-GNRST-30-20 Manuale utente

EisSound

EisSound KBSOUND Manuale utente

Marantz

Marantz RC101 Manuale utente

Conrad

Conrad FS20 TC6 Manuale utente

Anritsu

Anritsu MP1777A Manuale utente

Niles

Niles WVC100 Guida alla risoluzione dei problemi

RCA

RCA RCU1300 Manuale utente

Bang & Olufsen

Bang & Olufsen BEO6 Manuale utente

GE 94901 Manuale utente

Onbon

Onbon YQ1-75 Manuale utente

FUTABA

FUTABA R7108SB Istruzioni per l'installazione
