Culina IND60KC Manuale utente
Operation / Installation Manual
Induction Hob
MODEL: IND60KC / INDTC60
Ceramic Hob
MODEL: CER60TC / CER60DTC / CER60MZ
Congratulations on the purchase of your new hob.
We recommend that you spend some time to read this Instruction / Installation
Manual in order to fully understand how to install correctly and operate it.
For installation, please read the installation section.
Read all the safety instructions carefully before use and keep this Instruction /
Installation Manual for future reference.
2
SAFETY WARNINGS
Please read this user manual thoroughly before attempt-
ing to use this appliance for the first time. This manual
contains important information on safe installation, use
and care of the appliance. Keep these instructions for
reference and pass them on to future user.
Installation
Electrical Shock Hazard
• Disconnect the appliance from the mains electricity
supply before carrying out any work or maintenance
on it.
• Connection to a good earth wiring system is essential
and mandatory.
• Alterations to the domestic wiring system must only be
made by a qualified electrician.
• Failure to follow this advice may result in electrical
shock or death.
Cut Hazard
• Take care - panel edges are sharp.
• Failure to use caution could result in injury or cuts.
Important safety instructions
• Read these instructions carefully before installing or
using this appliance.
• No combustible material or products should be placed
on this appliance at any time.
• Please make this information available to the person
responsible for installing the appliance as it could re-
duce your installation costs.
3
• In order to avoid a hazard, this appliance must be in-
stalled according to these instructions for installation.
• This appliance is to be properly installed and earthed
only by a suitably qualified person.
• This appliance should be connected to a circuit which
incorporates an isolating switch providing full discon-
nection from the power supply.
• Failure to install the appliance correctly could invalidate
any warranty or liability claims.
Operation and maintenance
Electrical Shock Hazard
• Do not cook on a broken or cracked hob. If the hob
surface is break or crack, switch the appliance off im-
mediately at the mains power supply (wall switch) and
contact a qualified technician.
• Switch the hob off at the wall before cleaning or mainte-
nance.
• Failure to follow this advice may result in electrical
shock or death.
Health Hazard
• This appliance complies with electromagnetic safety
standards.
Hot Surface Hazard
• During use, accessible parts of this appliance will be-
come hot enough to cause burns.
• Do not let your body, clothing or any item other than
suitable cookware contact the ceramic glass until the
surface is cool.
4
• Metallic objects such as knives, forks, spoons and lids
should not be placed on the hob surface since they
can get hot
• Keep children away.
• Handles of saucepans may be hot to touch. Check
saucepan handles do not overhang other cooking
zones that are on. Keep handles out of reach of chil-
dren.
• Failure to follow this advice could result in burns and
scalds.
Cut Hazard
• The razor-sharp blade of a hob scraper is exposed
when the safety cover is retracted. Use with extreme
care and always store safely and out of reach of chil-
dren.
• Failure to use caution could result in injury or cuts.
Important safety instructions
• Never leave the appliance unattended when in use.
Boilover causes smoking and greasy spillovers that
may ignite.
• Never use your appliance as a work or storage surface.
• Never leave any objects or utensils on the appliance.
• Never use your appliance for warming or heating the
room.
• After use, always turn off the cooking zones and the
hob as described in this manual (i.e. by using the
touch controls).
• Do not allow children to play with the appliance or sit,
stand, or climb on it.
5
• Do not store items of interest to children in cabinets
above the appliance. Children climbing on the hob
could be seriously injured.
• Do not leave children alone or unattended in the area
where the appliance is in use.
• Children or persons with a disability which limits their
ability to use the appliance should have a responsible
and competent person to instruct them in its use. The
instructor should be satisfied that they can use the ap-
pliance without danger to themselves or their sur-
roundings.
• Do not repair or replace any part of the appliance un-
less specifically recommended in the manual. All other
servicing should be done by a qualified technician.
• Do not use a steam cleaner to clean your hob.
• Do not place or drop heavy objects on your hob.
• Do not stand on your hob.
• Do not use pans with jagged edges or drag pans
across the glass surface as this can scratch the
glass.
• Do not use scourers or any other harsh abrasive clean-
ing agents to clean your hob, as these can scratch the
ceramic glass.
• If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly quali-
fied persons in order to avoid a hazard.
• This appliance is intended to be used in a domestic
household environment only! Commercial use of any
kind is not covered under the manufacturer's warranty!
• WARNING: The appliance and its accessible parts be-
come hot during use.
6
• Care should be taken to avoid touching heating ele-
ments. Children less than 8 years of age shall be kept
away unless continuously supervised.
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
• Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children
without supervision.
• WARNING: Unattended cooking on a hob with fat or
oil can be dangerous and may result in fire. NEVER
try to extinguish a fire with water, but switch off the
appliance and then cover flame e.g. with a lid or a fire
blanket.
• WARNING: Danger of fire: do not store items on the
cooking surfaces.
• WARNING: If the surface is cracked, switch off the ap-
pliance to avoid the possibility of electric shock, for
hob surfaces of glass-ceramic or similar material
which protect live parts
• A steam cleaner is not to be used.
• The appliance is not intended to be operated by means
of an external timer or separate remote-control system.
7
GUIDE TO THE APPLIANCE
CER60TC / CER60DTC
CER60MZ
CONTROL PANEL
1. max. 1000/2200 W zone
2. max. 1200 W zone
3. max. 1100/2000 W zone
4. max. 1200 W zone
5. Glass plate
6. Control panel
1. Main switch
2. Zone selection
3. Power level setting
4. Child lock
5. Timer
6. Dual zone
1. max. 1800 W zone
2. max. 1200 W zone
3. max.1800 W zone
4. max.1200 W zone
5. Control panel
1. max. 1800/2200 W zone
2. max. 1200 W zone
3. max.1100/2000 W zone
4. max.1200 W zone
5. Control panel
1
2
3
4
5
6
8
INDTC60
CONTROL PANEL
IND60KC
CONTROL PANEL
1. max. 1800/2200 W zone
2. max. 1200 W zone
3. max.1800 W zone
4. max.1200 W zone
5. Control panel
1. max. 1800 W zone
2. max. 1200 W zone
3. max.1800 W zone
4. max.1200 W zone
5. Control panel
1
3
5
4
2
1. Main switch
2. Zone selection
3. Power level setting
4. Child lock
5. Timer
6. Boost
7. Pause
1. Main switch
2. Knob control
1
2
6
7
9
A Word on Induction Cooking (for Induction hob only)
Induction cooking is a safe, advanced and efficient cooking technology. It works
by electromagnetic vibrations generating heat directly in the pan, rather than in-
directly through heating the glass surface. The glass becomes hot only because
the pan eventually warms it up.
Before using your New Hob
• Read this guide, taking special note of the ‘Safety Warnings’ section.
• Remove any protective film that may still be on your hob.
• Remove any protective film that may still be on your hob.
Using the Touch Controls
• The controls respond to touch, so you don’t need to apply any pressure.
• Use the ball of your finger, not its tip.
• You will hear a beep each time a touch is registered.
• Make sure the control panel is always clean, dry, and that there is no object (e.g., a
utensil or a cloth) covering them. Even a thin film of water may make the controls difficult
to operate.
Choosing the right Cookware (for Induction hob)
• Only ferromagnetic cookwares are suitable for induction cooking.
Look for the induction symbol on the packaging or on the bottom of
the pan.
• You can check whether your cookware is suitable by carrying out a
magnet test. Move a magnet towards the base of the pan. If it is
attracted, the pan is suitable for induction.
iron pot
magnetic circuit
ceramic glass plate
induction coil
induced currents
10
• If you do not have a magnet:
1. Put some water in the pan you want to check.
2. Follow the steps under ‘To start cooking’.
3. If does not flash in the display and the water is heating, the pan is suitable.
• Cookware made by the following materials is not suitable: pure stainless steel,
aluminum or copper without a magnetic base, glass, wood, porcelain, ceramic,
and earthenware.
Size of hob(mm)
The minimum hob(diameter /mm)
160
120
180
140
210
160
280
220
Do not use cookware with jagged edges or a curved base.
Make sure that the base of your pan is smooth, sits flat against the glass, and is
the same size as the cooking zone. Always centre your pan on the cooking zone.
Always lift pans off the hob – do not slide, or they may scratch the glass.
To Start Cooking
Switching the hob on and off
Switch the hob on and off by using the main swtich.
1. Touch the main switch key . All the indicators show “- “.
2. Place a suitable pan on the cooking zone that you wish to use.
• Make sure the bottom of the pan and the surface of the glass are clean
and dry.
3. Touching the zone selecting key, an indicator next to the key will flash.
4. Select power level by touching the or control. / Turn the knobs for
IND60KC.
