CUSTOM TRUCK LOAD KING 10000 Guida
REVISION A
2
REVISION A
3
Table of Contents
1.0 Specicaons......................................................................................................................................9
1.1 General Specicaons .........................................................................................................................9
1.2 Load Chart.........................................................................................................................................11
1.3 Dimensions....................................................................................................................................... 14
1.4 Hydraulic Requirements ....................................................................................................................14
1.5 Minimum Chassis Requirements........................................................................................................14
1.6 Detailed Crane Funcons Described...................................................................................................14
2.0 Safety and Operaons.......................................................................................................................15
2.1 Safety................................................................................................................................................15
2.2 Responsibilies of Owners, Users and Operators...............................................................................17
2.3 Features of the Load King 10000 Crane ..............................................................................................17
3.0 Service ..............................................................................................................................................20
3.1 Inspecon .........................................................................................................................................20
3.2 Maintenance.....................................................................................................................................21
Turret Assembly......................................................................................................................................28
Winch.....................................................................................................................................................38
Winch Brake ...........................................................................................................................................42
Valve Cover ............................................................................................................................................44
Control valve ..........................................................................................................................................46
Boom Assembly 10022............................................................................................................................48
Boom Assembly 10022............................................................................................................................50
Boom Assembly 10022............................................................................................................................52
Boom Assembly (Cont.)...........................................................................................................................54
Extension Cylinder ..................................................................................................................................62
Snatch Block ...........................................................................................................................................64
Load King 10000 Service Crane Labels .....................................................................................................66
Warranty................................................................................................................................................70
REVISION A
5
REVISION DATE DESCRIPTION LOCATION
A12/2019 INITIAL RELEASE
REVISION CONTENT
Load King
7701 Independence Ave, Kansas City, MO 64125
Toll Free: (605) 356-3301
INTRODUCTION
7
Company
Load King has been producing quality trailers since 1956. We are located in Elk Point, South Dakota.
Although the trailer industry is an ever-changing environment and we’ve seen many changes over the years,
we have remained commied to the simple philosophy that we will make a reasonable prot through the
designing, manufacturing, and markeng of top quality products that we can always be proud to call Load
King. We have not, and will not, compromise in this area.
Quality shows in all facets of an operaon, from the moment you make your rst phone call for a product
inquiry to the me you sell your used equipment and realize you’ve received top dollar on your sale. We
connue to strive for excellence in every area and never quit trying to improve. We have earned our
reputaon believing that quality is value and value sells products.
Through our shared Engineering, Markeng and Sales teams, Load King and Custom Truck One Source bring
that tradion of quality and value to another market with the Load King 10000 Service Crane.
About Custom Truck One Source
Beginning in February of 2015, three family-owned and operated companies (Custom Truck & Equipment,
Ulity Fleet Sales and Forestry Equipment of VA) joined together to form what is now Custom Truck One
Source. Shortly aer its incepon, UCO Equipment became a part of the CTOS family along with TNT
Equipment six months later. In December 2015, CTOS welcomed its sixth company under its brand, Load King,
a leading manufacturer of high-quality and customizable trailers.
The announcement of the partnership represented the plaorm’s collecve commitment to the connued
growth and dominance of each legacy company’s individual oerings, now compounded to leverage the
experse of the team and, ulmately, beer serve loyal CTOS customers all over the world. CTOS will build
upon the market posions of each legacy company, while serving as a single source supplier of specialty
equipment and services for the ulity and heavy equipment industries. The ulity and heavy equipment
plaorm collecvely oers sales, rentals, parts and aer market services, remanufacturing, customized
equipment and transportaon.
REVISION A
8
DEFINITIONS USED IN THIS MANUAL
The following table describes text and symbols used to highlight important informaon.
Table—1
Signal Word Symbol Explanation
DANGER
Danger is used to alert readers about an immediate and serious hazard that will likely be
fatal.
WARNING
Warning is used to alert readers about the potenal for serious injury or death or serious
damage to equipment.
CAUTION
Cauon is used to alert readers about the potenal for anything from moderate injury to
serious equipment damage or destrucon.
READ
Read is used to alert readers of informaon to be read on machinery
NOTE
Note is used for a p or suggeson to help readers carry out a procedure successfully.
REVISION A
9
1.0 Specicaons
Descripon The Load King 10000 Service Crane is hydraulically powered with proporonal control
for all funcons. The crane is provided with remote control which ulizes a Canbus controller.
Maximum reach is 30 feet and boom elevaon varies from -15 to +80 degrees. Loads can be
controlled at angles below level as well as above level. Rotaon is 380 degrees total. With boom p
lighng the unit also serves as a mobile work light.
1.1 General Specicaons
1.0 Specicaons
Descripon The Load King 10000 Service Crane is hydraulically powered with proporonal control
for all funcons. The crane is provided with remote control which ulizes a Canbus controller.
Maximum reach is 30 feet and boom elevaon varies from -15 to +80 degrees. Loads can be
controlled at angles below level as well as above level. Rotaon is 380 degrees total. With boom p
lighng the unit also serves as a mobile work light.
1.1 General Specicaons
10030 Crane Specicaons
Crane Rang 72500 FT-# (10.81 ton-m)
*FT-# is the horizontal distance from the center of rotaon to the load line x the weight of the load
Horizontal Reach 30'-0" (9.84 m)
Hydraulic Extend 204" (5.58 m)
Crane Weight 2450# (1110kg)
Center of Gravity 39.5” (1 m) Forward of Centerline
Load Line 7/16” IWRC x 1230 FT (11.1 mm X 39.4 M)
Storage Height 40 3/4” (1.04M)
Storage Length 16’ -1/4” (5.25 m)
Mounng Plate 1 1/4" Thick (31.8mm)
Bolt Paern 14.75” x 18.75” (375 mm x 476 mm)
REVISION A
