CyClone LES100-48 Manuale utente

Y and R Solar ( pty) Ltd

LES-Powerwall Battery

Pack User Manual

Please comply with all warnings and operating

instructions in this manual strictly. Save this manual

properly and read carefully the following instructions

before installing the unit. Do not operate this unit before

reading through all safety information and operating

instructions carefully.

1.SAFETY PRECAUTION.....................................................................................................................................................3

1.1 WHEN USING BATTERY....................................................................................................................................................3

1.2 WHILE CHARGING........................................................................................................................................................... 4

1.3 WHEN DISCHARGING THE BATTERY................................................................................................................................4

2.PARAMETERS OF BATTERY.......................................................................................................................................... 5

2.1 BASIC BLOCK DIAGRAM................................................................................................................................................. 5

2.2 BATTERY SPECIFICATIONS................................................................................................................................................6

2.3 PANEL VIEW.....................................................................................................................................................................8

2.4 LED INDICATORS.............................................................................................................................................................9

2.5 BUZZER OPERATION (OPTIONAL).................................................................................................................................. 10

2.6 DISPLAY FUNCTION INSTRUCTION................................................................................................................................. 11

2.6.1 Display rendering............................................................................................................................................................................ 11

2.6.2 Functional Specifications................................................................................................................................................................ 11

2.7 CONNECTORS.................................................................................................................................................................14

2.8 WAKE UP BUTTON......................................................................................................................................................... 14

3. SAFE HANDLING GUIDE.............................................................................................................................................. 14

3.1 SYSTEM DIAGRAM.........................................................................................................................................................14

3.2 TOOLS............................................................................................................................................................................ 15

3.3 SAFETY GEAR................................................................................................................................................................15

3.4 INSTALLATION................................................................................................................................................................15

3.4.1 Inventory of items........................................................................................................................................................................... 15

3.4.2 Installation Location........................................................................................................................................................................16

3.4.3 Wall-mounted.................................................................................................................................................................................. 16

4. OPERATING INTRUCTIONS........................................................................................................................................ 17

4.1 SOFTWARE INSTALLATION..............................................................................................................................................17

4.2 PRE-OPERATION STEP.....................................................................................................................................................17

4.3 COMMUNICATION FUNCTION......................................................................................................................................... 18

4.3.1 Communication port definition....................................................................................................................................................... 18

4.3.2 Battery communicate with PC/Software........................................................................................................................................ 19

4.3.3 Batteries communicated with inverter.............................................................................................................................................20

5. TROUBLESHOOTING.................................................................................................................................................... 22

6. STORAGE AND MAINTENANCE.................................................................................................................................23

6.1. STORAGE...................................................................................................................................................................... 23

6.2. MAINTENANCE............................................................................................................................................................. 23

7 PRODUCT RESPONSIBILITIES AND CONSULTING..............................................................................................24

1.Safety Precaution

1.1 When Using battery

Danger of High Voltage：

The high voltage power supply offer the equipment power, wet object contact high voltage power

supply directly or indirectly , can cause fatal danger.

Static‐free：

Static electricity would damage veneer on the electrostatic sensitive components, before touching the

plug‐in, circuit board or chips, be sure to use correct electrostatic prevention measures.

Dc short circuit dangerous：

Power system provides dc regulated power supply. Dc short circuit could cause fatal damage to the e

quipment.

Using a special tool :

Working in high voltage and ac power, be sure to use a special tool instead of individual tools.

Disconnect the power supply in operation:

When operate the power supply, you must first cut off power supply, power operation is prohibited.

1.2 While Charging

CAUTION

The temperature range over which the battery can be charged is 0°C to 45°C. Charging the battery

at temperatures outside of this range may cause the battery to become hot or to break. Charging the

battery outside of this temperature range may also harm the performance of the battery or reduce

the battery’s life expectancy.

1.3 When Discharging the Battery

DANGER

Do not discharge the battery using any device except for the specified device. When the battery is

used in devices aside from the specified device it may damage the performance of the battery or

reduce its life expectancy, and if the device causes an abnormal current to flow, it may cause the

battery to become hot and cause serious injury.

CAUTION

The temperature range over which the battery can be discharged is -20°C to 60°C. Use of the battery

outside of this temperature range may damage the performance of the battery or may reduce its life

expectancy.

2.Parameters of Battery

2.1 Basic Block Diagram

• There are Battery cells and BMS board inside, before connecting the terminal, please read the

diagram, and make sure the output is no short or other abnormal connection.

Fig1 Battery Block Diagram

2.2 Battery Specifications

Battery Specifications

Model NO. LES100-48 LES200-48

Nominal Parameters

Voltage 48V 48V

Capacity 100Ah 200Ah

Energy 4.8KWh 9.6KWh

Dimensions(L*W*H) 500*550*162 mm 480*650*275mm

Weight 48Kg 89Kg

Basic Parameters

Design life time(25℃) 20 years

Life cycles(80% DOD,25℃） 6000 Cycles

Storage tiome/temperature

5 moths @ 25℃;3 moths @ 35℃;1 moths @

45℃

Operation temperature -20℃ to 60℃ @ 60±25 Relative Humidity

Storage temperature 0℃ to 45℃ @ 60±25 Relative Humidity

Lithium battery standard IEC62619,UN38.3,ROHS,CE-EMC,UL 1642,MSDS

Enclosure protection rating IP21

Electrical Parameters

Operation voltage 48Vdc 48Vdc

Max. charging voltage 54Vdc 54Vdc

Cut-off discharge voltage 40.5Vdc 40.5Vdc

Max. charge and discharging

current 100A 100A

Battery Specifications

Model NO. LES100-51.2 LFP200-51.2

Nominal Parameters

Voltage 51.2V 51.2V

Capacity 100Ah 200Ah

Energy 5.12KWh 10.24KWh

Dimensions(L*W*H) 500*550*162 mm

Weight 50Kg 92Kg

Basic Parameters

Design life time(25℃) 20 years

Life cycles(80% DOD,25℃） 6000 Cycles

Storage tiome/temperature

5 moths @ 25℃;3 moths @ 35℃;1 moths @

45℃

Operation temperature -20℃ to 60℃ @ 60±25 Relative Humidity

Storage temperature 0℃ to 45℃ @ 60±25 Relative Humidity

Lithium battery standard

IEC62619,UN38.3,ROHS,CE-EMC,UL

1642,MSDS

Enclosure protection rating IP21

Electrical Parameters

Operation voltage 51.2Vdc 51.2Vdc

Max. charging voltage 57.6Vdc 57.6Vdc

Cut-off discharge voltage 43.2Vdc 43.2Vdc

Max. charge and discharging

current 100A 100A

480*650*275mm

2.3 Panel View

No. Description Functional Description

1LCD Display Screen

2Indicator LED Battery run/alarm, status

3Battery + Positive terminal

4Switch Active/start battery

5Battery - Negative terminal

6Ground bolt Safety

7 MCB Output ON/OFF

8Dipswitch Dial for communication

9DCT 2 Road Dry Contacts

10 RS485 Communication Port RS485 Communication Interface

10CAN Communication Port CAN Communication Interface

11RS485 Communication Port RS485 Communication Interface

12RS232 Communication Port RS232 Communication Interface

2.4 LED Indicators

LED Indicators:

There are 6 LEDs on upper panel to show the battery working status:

Pack

Status

Normal/Alar

m/Protection

RUN ALM SOC Indication LED

Remark

● ● ● ● ● ●

Power

Off Sleep OFF OFF OFF OFF OFF OFF All OFF

Standby Normal Flash 1 OFF

Indication by SOC

Standby

Alarm Flash 1 Flash 3 Battery undervoltage

Charge

Normal ON OFF

Indication by SOC

Alarm ON Flash 3 -

Over Charge

Protection ON OFF -ALM LED is off when

overcharge protection

Temperatuer/

Overcurrent

protection

OFF ON Stop charge

Discharg

Normal Flash 3 OFF

Indication by SOC

Alarm Flash 3 Flash 3 -

Over Discharge

Protection OFF OFF Stop discharge

Temperature/

Over current

/Short circuit

protection

OFF ON Stop discharge

Fault OFF ON OFF OFF OFF OFF Stop charge & discharge

NOTE: LED function can be set by monitor software, the default is on.
