D-Link DFE-690TXD Manuale utente
32-bit Cardbus Fast
Ethernet Adapter
DFE-690TXDDFE-690TXD
DFE-690TXDDFE-690TXD
DFE-690TXD
This product can be used with:This product can be used with:
This product can be used with:This product can be used with:
This product can be used with:
Windows XP, 2000, Me, 98se & 98Windows XP, 2000, Me, 98se & 98
Windows XP, 2000, Me, 98se & 98Windows XP, 2000, Me, 98se & 98
Windows XP, 2000, Me, 98se & 98
Macintosh OS v 8 & 9Macintosh OS v 8 & 9
Macintosh OS v 8 & 9Macintosh OS v 8 & 9
Macintosh OS v 8 & 9
CheckYourPackageContents
These are the items included with your purchase:
©2002D-LinkSystems,Inc.Allrightsreserved.Trademarksorregisteredtrademarksarethepropertyoftheir
respective holders. Software and specifications subject to change without notice. DFE-690TXD.06112002
If any of the above items are missing, please contact your reseller.
BeforeYouBegin
You must have at least the following:
•Windows XP/2000/Me/98se/98 or Macintosh OS v 8/9 with Carbus Support
•One Available Cardbus Slot
•CD-ROM Drive
• DFE-690TXD 32-Bit Cardbus Fast
Ethernet Adapter
• CD-ROM (containing Drivers,
PDF Installation Guide, PDF Manual
and Warranty)
For Windows XP/2000/Me/98: Run
the Install CD BEFORE installing
the DFE-690TXD into your laptop.
Macintosh users: Proceed to Section 2:
Pre-Installing the Macintosh OS 8/9 Driver
Pre-InstallingtheWindowsXP,2000,
Meand98se/98Driver
Macintosh users: Proceed to Section 2:
Pre-Installing the Macintosh OS 8/9 Driver
With your computer ON, insert the
Driver CD of the DFE-690TXD into
your CD-ROM Drive.
Click Install Drivers
Click OK
Note: Select "No", if you are prompted to restart your computer.
Shut-down the computer manually if the prompt does not occur.
(Go to Start > Shut down > Shut-down.)
Shut-DownShut-Down
Shut-DownShut-Down
Shut-Down your Computer
Proceed to Setion 2: Pre-Installing the Macintosh OS 8/9 Driver.
Windows Users
Proceed to Setion 3: Installing the DFE-690TXD into your
Computer
Macintosh Users
Pre-InstallingtheMacintoshOS8/9Driver
Insert the Driver CD into your
CD-ROM drive.
Double-click
Macintosh
Proceed to Section 3.
Drag & Drop to the Desktop
and then Double-click it.
Double-click
Installer
Click Install
Click OK
Restart your computer. Your installation is now complete.
Proceed to Appendix 2 to configure your adapter to automatically receive
an IP address from your DHCP server.
InstallingtheDFE-690TXDintoyour
Computer
This section refers to all users, regardless
of which operating system you use.
You must first install the drivers as explained in Section 1 (for
Windows users), or Section2 (for Macintosh users). If you
have not done this and you have inserted the DFE-690TXD
into the Cardbus slot, you will need to cancel the New Hardware
Wizard (for Windows users), and start over at the beginning of this
installation guide (for Windows or Macintosh).
•Connect an Ethernet Cable (CAT5) from a switch or hub to the
DFE-690TXD.
Insert the DFE-690TXD
into the Cardbus slot of
your laptop
Windows Users
Proceed to Setion 4: Finishing the Windows Installation.
Macintosh Users
Make sure that your
computer is turned Off.
Turn your computer On.
FinishingtheWindowsInstallation
To complete the installation of the DFE-690TXD:
•Make sure that the DFE-690TXD CD-ROM is inserted in the
CD-ROM drive
•The DFE-690TXD is inserted into your laptop
•The laptop is turned ON
•See the section below that corresponds to your Operating
System to complete the installation:
Windows XP
Windows XP completes the installation
of the DFE-690TXD automatically. A
"Found New Hardware" message will
appear in the task bar to indicate that
the installation is complete.
Windows 2000
Windows 2000 completes the installation of the DFE-690TXD
automatically. When the "hour glass" disappears, the installation is
complete.
Windows Me & 98se/98
•Windows Me & 98/98se installs the drivers automatically.
•If a "Version Conflict" screen appears, select "Yes" to use the newer
file and continue.
•A screen will appear asking you to restart your computer. Select "Yes"
to restart your computer and complete the installation.
Click Yes
You can find the most recent software and user documentation on
the D-Link website.
D-Link provides free technical support for customers within the
United States for the duration of the warranty period on this product.
U.S. customers can contact D-Link technical support through our
web site or by phone.
D-Link Technical Support over the Telephone:
(877) 45D-LINK
(877) 453-5465
24 hours a day, seven days a week
D-Link Technical Support over the Internet:
http://support.dlink.com
email: [email protected]
TechnicalSupport
