D-Link DWA140 - RANGE BOOSTER N USB ADAPTOR Manuale utente
HIGH PERFORMANCE
Upgrade to the latest draft 802.11n
technology while staying compatible
with 802.11b & 802.11g
TOTAL CONNECTION
Get reception throughout your
home and office by connecting to a
RangeBooster N router
WIRELESS PROTECTION
Connect to secure wireless networks using WEP,
WPA and WPA2
HIGH-PERFORMANCE WIRELESS NETWORKING
RANGEBOOSTER N USB ADAPTER
ULTIMATE PERFORMANCE
The DWA-140 RangeBooster N USB adapter is a draft 802.11n client device that delivers unrivaled wireless performance for the PC. Users can easily upgrade
to the next generation of wireless technology by adding this RangeBooster N adapter to access network high-speed Internet connection while sharing
photos, files, music, video, printers, and storage. Enhance Internet experience with a faster wireless connection and enjoy smooth digital phone calls, gaming,
downloading, and video streaming.
GET CONNECTED, STAY CONNECTED
Powered by RangeBooster N technology, this adapter provides very high wireless performance. This high performance wireless adapter is designed for use
in bigger homes and for users that demand higher networking performance. Maximize wireless performance by connecting this adapter to a RangeBooster
N router and stay connected from virtually anywhere in your home. It can also be used with 802.11g and 802.11b wireless networks to enable significantly
improved reception. This adapter supports WPA/WPA2 security and WEP data encryption to help prevent outside intrusion and protect your personal
information from being exposed.
EASY TO SETUP, EASY TO USE
D-Link’s Quick Setup Wizard provides you with an easy way to setup your USB adapter. The Wireless Manager included with this product helps keep track of
all your most frequently accessed networks. The addition of the Wi-Fi Protected Setup (WPS) function provides advanced security features that remain simple
enough for the average user to configure correctly. This function allows for devices to undergo an easy one-time click-button configuration for establishing
connection with an access point or wireless router without the need of manually setting up complex encryption codes. With unmatched wireless performance,
reception, and security, this adapter is the best choice for easily adding or upgrading wireless connectivity to your computer.
DWA-140
Wireless
WHAT THIS PRODUCT DOES
Upgrade your desktop computer’s wireless
connectivity with the RangeBooster N network
adapters and routers for a much faster wireless
connection and superior reception. Once
connected, you can access your network’s high
speed Internet while also getting secure access
to shared photos, files, music, video, printers and
storage.
GET CONNECTED, STAY
CONNECTED
Based on the latest 802.11n (draft) specifications,
RangeBooster N technology provides high
wireless performance. This allows wireless
network connection to perform smoothly for
bandwidth-demanding applications such as
multimedia and Internet phone.
SYSTEM REQUIREMENTS
Windows XP SP2, 2000 SP4, or Vista
CD-ROM drive
20MB hard disk space
Available USB port
STANDARDS
IEEE 802.11n (draft)
IEEE 802.11g
IEEE 802.11b
USB 2.0
FREQUENCY RANGE
2.4GHz to 2.4835GHz
EMISSION SCHEMES
DSSS, OFDM
DATA MODULATION SCHEMES
DBPSK, DQPSK, CCK and OFDM
(BPSK/QPSK/16-QAM/64-QAM)
DATA RATES
1
802.11g: 6/9/12/18/24/36/48/54Mbps
802.11b: 1/2/5.5/11Mbps
802.11n: 30/60/90/120/180/240/270/300
Mbps
TRANSMIT OUTPUT POWER (TYPICAL)
18dbm (802.11 b)
14dbm (802.11 g/n)
ANTENNAS
Two integrated antennas
SECURITY
64/128-bit WEP data encryption
Wi-Fi Protected Access (WPA, WPA2)
WiFi Protection Setup
- Push Button
OPERATING VOLTAGE
5VDC +/- 10%
POWER CONSUMPTION (802.11N)
TX: 247mA
RX: 268mA
DIAGNOSTIC LEDS
Link/Activity
DIMENSIONS
87 x 28 x 12 mm
OPERATING TEMPERATURE
0º to 40º C
STORAGE TEMPERATURE
-20º to 65º C
OPERATING HUMIDITY
10% to 90% non-condensing
STORAGE HUMIDITY
5% to 95% non-condensing
CERTIFICATIONS
FCC Class B
CE
C-Tick
IC
Wi-Fi
WPS Certified
DWA-140
ACN 052 202 838
TECHNICAL SPECIFICATIONS
HIGH-PERFORMANCE WIRELESS NETWORKING
D-Link Corporation
No. 289 Xinhu 3rd Road, Neihu, Taipei 114, Taiwan
Specifications are subject to change without notice.
D-Link is a registered trademark of D-Link Corporation and its overseas subsidiaries.
All other trademarks belong to their respective owners.
©2009 D-Link Corporation. All rights reserved.
Release 01 (May 2009)
