D-Link DWL-AG132 Manuale utente
DWL-AG700AP Install Guide
D-Link Systems, Inc. 2
DWL-AG700AP Install Guide Contacting Technical Support
DWL-AG132 Install Guide System Requirements
System Requirements
Minimum System Requirements:
Computers with Windows XP/2000 operating system with
an available USB 2.0 port
Internet Explorer version 6.0 or Netscape Navigator
version 7.0 and above
Manual on CD
Cradle
D-Link AirPremier AG DWL-AG132
Wireless AG USB 2.0 Adapter
Package Contents
DWL-AG700AP Install Guide
Connecting to your networkDWL-AG132 Install Guide Installing the Drivers
D-Link Systems, Inc.
3
DWL-AG132 Install GuideInstalling the Drivers
Installing the Drivers
The step-by-step instructions that follow are shown in Windows XP. The
steps and screens are similar for the other Windows operating systems.
Turn on the computer and insert the D-Link AirPremier AG®
DWL-AG132 Driver CD in the CD-ROM drive. The installation Wizard will
automatically appear.
Do NOT install the DWL-AG132 Wireless AG USB Adapter into your
computer before installing the driver software from the D-Link CD!
Click Install Drivers
Click Next
Click Next
If the Installation Wizard does not
automatically start on your computer,
type “D:\Drivers\setup.exe.” If the
Wizard does start, proceed to the next
screen.
Installing the Drivers
4
DWL-AG700APUsing the Setup Wizard
D-Link Systems, Inc. 4
DWL-AG132 Install GuideInstalling the Drivers
Installing the Drivers (continued)
Click Next
Click Finish
Click ‘Yes, I want to restart
my computer now.’
You have completed the installation of the drivers!
DWL-AG132 Install GuideConnecting the DWL-AG132
D-Link Systems, Inc.5
Begin by pressing
down on the cover
with your thumb.
USB Port - used to
connect the DWL-
AG132 to your
computer.
Link/Power LED
Link - indicates that
the DWL-AG132 is
properly installed.
Activity - blinks
when data is being
transmitted through the
wireless connection.
Remove the protective covering from the DWL-AG132.
Pull the cover away from
the DWL-AG132.
Optional: If desired or needed, attach
the cradle between the DWL-AG132
and your computer.
Insert the DWL-AG132 into
an available USB port on
your computer.
Connecting the DWL-AG132
6
DWL-AG700APUsing the Setup Wizard
D-Link Systems, Inc. 6
DWL-AG132 Install GuideThe Found New Hardware Wizard
Click Continue Anyway.
The Found New Hardware Wizard
Click Next
Select Install the
software automatically
(Recommended).
After connecting the DWL-AG132, the Found New Hardware Wizard
(Windows XP) screen will appear:
DWL-AG132The Found New Hardware Wizard
D-Link Systems, Inc.
7
DWL-AG132 Install GuideThe Found New Hardware Wizard
Click Next
Select Install the
software automatically
(Recommended).
Click Continue Anyway.
Click Finish to complete
the installation.
D-Link AirPremier AG DWL-AG132 USB Adapter
DWL-AG132Your Installation is Complete!
D-Link Systems, Inc. 8
DWL-AG132 Install GuideYour Installation is Complete!
If the utility icon does not appear,
double-click the shortcut icon
that has appeared on your
desktop.
After completing the Found New Hardware Wizard, the D-Link AirPremier AG
DWL-AG132 Configuration Utility will automatically start and the utility icon
will appear in the bottom right hand corner of the desktop screen (system
tray). If this icon appears GREEN, then you have successfully installed
the DWL-AG132, are connected to a wireless network, and are ready
to communicate!
Your Installation is Complete!
Double-click the utility icon to
use the configuration utility.
DWL-AG132 Install Guide Appendix A
For Windows XP, if you wish to use the AirPremier AG utility, please do the
following:
D-Link Systems, Inc.
9
Using the Utility in Windows XP
Click the XP networking
icon to use the Zero
Configuration Wireless
Click Advanced.
Uncheck Use Windows
to configure my
wireless network
settings.
Click OK.
DWL-AG132 Install Guide Appendix B
D-Link Systems, Inc. 10
Using the AirPremier AG Utility
Status: Displays the MAC Address of the access point that is associated with
the DWL-AG132.
SSID: Displays the Service Set Indentifier assigned to the wireless
network.
Frequency: Displays the current frequency used by the adapter.
Wireless Mode: Displays the wireless mode. The default is Infrastructure.
Encryption: Displays whether Encryption is enabled or disabled.
Connection Info: Displays the adapter’s connectivity to the network.
Tx Rate: Displays the current data transmission rate.
