D-Link Powerline HD DHP-300 Manuale utente

2D-Link DHP-300 Quick Install Guide

• Windows®XP SP2 or 2000 SP4

• 233MHz processor and at least 64MB of RAM

• An available Ethernet Adapter (100MBit/s)

CAT5 Ethernet Cable

Package Contents

DHP-300

Powerline HD Ethernet Adapter

System Requirements

If any of the above items are missing, please contact your reseller.

CD-ROM with Manual and

Installation Wizard

3 D-Link DHP-300 Quick Install Guide

Hardware Overview

Power LED

A solid light indicates that the

device is receiving power.

Powerline LED

A solid light indicates that the device

has detected another Powerline

device on the network.

Ethernet LED

A solid light indicates a connection

on the Ethernet port. The LED blinks

during data transmission.

Hardware Overview

D-Link DHP-300 Quick Install Guide 4

Ethernet

Connect CAT5 Ethernet cable to the DHP-300

Ethernet port.

5 D-Link DHP-300 Quick Install Guide

Hardware Installation

Connect the Ethernet Cable

Connect the included Ethernet cable to the network cable connector

located on the DHP-300 and attach the other end of the Ethernet cable

to the network or PC.

Note: Network Connectivity is conﬁrmed when the green Powerline

LED indicator on the DHP-300 is illuminated.

Power

Plug the DHP-300 into an AC wall outlet or power strip.

Note: Power source is conﬁrmed when the green LED Power Indicator

on the DHP-300 is illuminated.

Software Installation

D-Link DHP-300 Quick Install Guide 6

Software Installation

Click on Install Utility

Follow the simple steps below to run the Setup Wizard to guide you

quickly through the installation process.

Insert the D-Link DHP-300 Powerline HD Ethernet Adapter CD into

your CD-ROM drive. If the CD Autorun function does not automatically

start on your computer, click Windows® Start > Run.

In the Run command box type “D:\DHP300.exe”, where D: represents

the drive letter of your CD-ROM. If it does start, proceed to the next

screen.

7 D-Link DHP-300 Quick Install Guide

Software Installation

Click Next

The InstallShield Wizard will

begin the DHP-300 software

Setup will install to the default

location: C:\Program Files\D-Link

DHP-300\DHP-300 PLC Utility,

where C: represents the drive

letter of your hard drive. To install

to a different location click Browse

and specify the location.

Click Next

Software Installation

D-Link DHP-300 Quick Install Guide 8

The WinPcap 3.1 installation

is necessary to run the D-Link

DHP-300 Utility, click Next to

continue with the installation.

Click Next

Click I Agree

9 D-Link DHP-300 Quick Install Guide

Software Installation

The WinPcap 3.1 Installation is

complete. Click Finish to close

the wizard.

The installation wizard is now

complete click Finish.

Click Finish

Conﬁguration

D-Link DHP-300 Quick Install Guide 10

Conﬁguration

After you have completed the D-Link DHP-300 Utility installation

wizard, double-click the D-Link DHP-300 PLC Utility icon on your

desktop to start the conguration of the DHP-300.

The utility provides you with the

option of setting your own unique

Network ID and the ability to

prioritize trafc passing through

the network.

Double-click the D-Link

DHP-300 PLC Utility

Click Next
