D-Link DFE-528TX Manuale utente

Check Your Package Contents

If any of the above items are missing, please contact your reseller.

The DFE-528TX supports drivers for the following operating systems:

Microsoft Windows 95/98/ME Macintosh 10.1.X

Microsoft Windows NT4.0 Netware Server

3.12/4.1X/5.00

Microsoft Windows 2000 Netware DOS ODI Client

Microsoft Windows 2003 DOS NDIS

Microsoft Windows XP Microsoft Network client 3.0

for DOS

Microsoft Windows Vista x86 Microsoft LAN Manager

Workstation/Server

Microsoft Windows Vista x64 SCO Unix 5.0

Linux 2.2 Packet Driver

DFE-528TX

10/100Mb Ethernet

PCI Adapter

• DFE-528TX 10/100Mb Ethernet PCI Adapter

• CD with Manual and Drivers

For Microsoft Windows

Installing the DFE-528TX Drivers

•Turn ON the computer.

•Insert the driver CD, which is included with the DFE-528TX, into the CD-

ROM drive.

The following window will appear.

Click on “Install Drivers”.

For Windows 2000, Windows XP, Windows 2003, Windows Vista x86 and Vista

x64 users, the following screen will appear.

Click OK

DO NOT insert the DGE-528Tinto the computer’s PCI

ltbf i tlli th di

DO NOT insert the DFE-528T

into the computer’s

PCI slot before installing the drivers.

For Windows 98SE and Windows ME users, this screen will be displayed.

Click Yes

Installing the DFE-528TX into the

computer’s PCI slot

•Turn off your computer and unplug the power cord.

•Remove the back cover of your computer. (Refer to your computer’s manual

if needed.)

•Locate an available PCI slot. PCI slots are usually white or cream colored.

•Remove the backplate (the small piece of metal that covers the opening for

the PCI card on the back cover that you just removed.)

•Insert the DFE-528TX carefully and firmly into the PCI slot.

•Secure the DFE-528TX with the screw from the backplate.

•Replace your computer’s cover.

Next, TURN OFF the computer and unplug

the power cord.

Caution: To avoid damage caused by static electricity, make sure to properly

ground yourself by first touching a metal part of your computer to discharge any

static electricity before working with the DFE-528TX Ethernet Adapter.

Finishing the Installation

TURN ON the computer.

For Windows 98SE and Windows ME users, the following screen will

appear.

Click Yes, to restart the computer.

Checking the Installation

Go to:

START>CONTROL PANEL>SYSTEM>HARDWARE>DEVICE MANAGER.

To check that the installation of the DFE-

528TX was successful, scroll down and

click on “Network Adapters.”

You have a successful installation when

“D-Link DFE-528TX” appears (with no

errors) as shown at left.

Technical Support

You can find software updates and user documentation on the

D-Link website.

Tech Support for customers within Australia:

D-Link Technical Support over the Telephone:

1300-766-868

Monday to Friday 8:00am to 8:00pm EST

Saturday 9:00am to 1:00pm EST

D-Link Technical Support over the Internet:

http://www.dlink.com.au

email:support@dlink.com.au

Tech Support for customers within New

Zealand:

D-Link Technical Support over the Telephone:

0800-900-900

Monday to Friday 8:30am to 8:30pm

Saturday 9:00am to 5:00pm

D-Link Technical Support over the Internet:

http://www.dlink.co.nz

email:[email protected]
