D-Link DP-101P - Pocket Ethernet Print Server Manuale utente

DP-101P+

Multi-protocol Ethernet

Pocket Size Print Server

User’s Manual

Rev. 01 (June, 2001)

Made In Taiwan

RECYCLABLE

DP-101P+ Print Server User’s Manual

2About this Guide

TABLE OF CONTENTS

0ABOUT THIS GUIDE ...............................................................................3

1INTRODUCTION......................................................................................4

SERVICE FEATURES.......................................................................................4

EXTERNAL FEATURES ...................................................................................6

Front End..................................................................................................6

Rear End...................................................................................................7

2UNPACKING AND INSTALLATION.....................................................9

UNPACKING AND INSPECTING .......................................................................9

INSTALLING THE DP-101P+........................................................................10

POWER-UP AND SELF-TEST.........................................................................11

LED Test Series.......................................................................................11

Component Test Series............................................................................11

Operational Test .....................................................................................12

3PRODUCT SPECIFICATIONS..............................................................13

4PORT PINOUTS......................................................................................15

DP-101P+ Print Server User’s Manual

About this Guide 3

0 ABOUT THIS GUIDE

This manual describes the D-Link DP-101P+ Multiprotocol

Ethernet Print Server, including full descriptions of its features,

detailed installation procedures, and troubleshooting information.

Your DP-101P+ package includes important software components,

and additional user manuals. The software components, and

procedures for installation and setup of the software, are covered

in the PS Admin User’s Guide.

DP-101P+ Print Server User’s Manual

4Introduction

1 INTRODUCTION

The DP-101P+ Print Server is a compact pocket-sized print server

which connects your Ethernet network directly to your printer,

wherever it is. It manages the flow of print files from your

workstations or file servers to its connected printers, delivering

print jobs to high-performance printers much faster than a file

server or a PC acting as a print server can.

Service Features

DP-101P+ print servers improve network printing services in three

ways:

♦The DP-101P+ picks up the workload of managing print file

traffic to its connected printers. This provides workload relief to

your file servers, and allows the file servers' full capacity to be

used for file access or other direct services to network users. On

peer-to-peer networks, workstations can print directly to the

DP-101P+ without increasing the load of another workstation or

server.

♦The DP-101P+'s IEEE 1284 compliant high-speed bi-directional

parallel printer port can transmit to high-speed laser printers

much faster than a PC's parallel printer port. A high-speed

laser printer can be driven at its full capacity.

DP-101P+ Print Server User’s Manual

Introduction 5

♦Because the DP-101P+ is very portable (pocket-sized) and

inexpensive compared to a PC-based print server, and because

the DP-101P+ connects to your file servers through the

network, the printer can be stationed at the location of

maximum convenience to users.

The DP-101P+ offers extraordinary flexibility, operating with all

major network operating systems and protocols:

♦TCP/IP

UNIX lpr/lpd (HP-UX, SunOS, Solaris, SCO, UnixWare, IBM

AIX)

Windows NT/2000

NetWare 5.x NDPS LPR remote printing

♦NetBEUI

Windows NT/2000, Windows 95/98/Me, Windows for

Workgroups, Microsoft LAN Manager, IBM LAN Server

♦AppleTalk

MacOS EtherTalk

Your D-Link DP-101P+ package includes PS Admin, a Windows-

based setup and administration program, which makes

configuration and management of your D-Link print servers quick

and easy in a Windows environment. The DP-101P+ also has a

Telnet interface for management communications. If Windows is

not available on the station you choose for print server

administration, then all configuration and management commands

may be issued to the DP-101P+, and all console messages and

management report information will be returned, via Telnet.

DP-101P+ Print Server User’s Manual

6Introduction

External Features

This section describes the external features of the DP-101P+ print

server.

Front End

The network port, power input socket, and LED indicators are all

located at the front.

Led Indicators

Network Port

DC Power

Input

DP-101P+ Front End

Network Port

The network port (RJ-45 receptacle) provides for connection to the

network through 10Base-T Ethernet cabling.

DC Power Input

The DC power input socket uses a 7.5V power supply.

The power supply included in your DP-101P+ package is correct for

the DP-101P+. Substitution of other equipment may void warranty.

DP-101P+ Print Server User’s Manual

Introduction 7

LED Indicators

The front of the DP-101P+ includes three LED indicators. See

"Power-up and Self-Test," Chapter 2, for LED indications upon

starting up the DP-101P+. During operations following a normal

startup, the LED indicators provide the following status signals:

♦Pw/Tx

Steady or flashing green confirms power on.

This indicator blinks (briefly dark) when the DP-101P+ is

transmitting to the network.

♦Lk/Rx

Steady or flashing green confirms that the DP-101P+ has a good

connection to the Ethernet network.

This indicator blinks (briefly dark) when the DP-101P+ is

receiving from the network.

♦LPT

This indicator shows steady green while the DP-101P+ is

transferring print data through its printer port.

Rear End

The DP-101P+ printer port is located at the rear.

DP-101P+ Rear End

DP-101P+ Print Server User’s Manual

8Introduction

Printer Port

The printer port, is configurable by commands in the PS Admin

program, or by commands issued to the DP-101P+ via Telnet. See

the PS Admin User’s Guide for configuration procedures.

The print server also supports web configuration permitting users

to configure settings through the web browser. DP-101P+ default

IP address as follows:

♦Default IP address –192.168.0.1

♦Subnet Mask –255.255.255.0

Note:-

The PC’s IP address must correspond with the print server’s IP

address in the same segment for the two devices to communicate.

2 UNPACKING AND

INSTALLATION

This chapter explains how to install your DP-101P+ print server

and connect it to the network. It also describes the automatic

power-on self test.

Unpacking and Inspecting

Carefully remove all items from the package. In addition to this

Hardware Guide, be certain that you have:

♦One DP-101P+ print server

♦One AC Power adapter suitable for your electric power service

♦One Installation CD-ROM

♦One Multi-language Quick Installation Guide

If any item is missing, or if you find any damage or mismatch,

promptly contact your dealer for assistance.

DP-101P+ Print Server User’s Manual

10 Unpacking and Installation

Installing the DP-101P+

Follow these steps for a trouble-free start of print-server operations

with your DP-101P+. Please take particular notice of the warning

in step 4: the network connection should be made before supplying

power to the DP-101P+.

1. Confirm proper operation of the printer to be connected to the

DP-101P+.

2. When you have confirmed proper operation of the printer,

switch its power off.

3. Confirm that your network is operating normally.

4. Connect the DP-101P+ to the network (through the RJ-45

receptacle on the print server’s rear end).

WARNING:Configuration problems may result if the DP-101P+

is powered up without first establishing its network

connection. Follow this procedure to avoid

complications at the configuration stage.

5. While the printer is power off, connect the DP-101P+ print

server directly to the printer parallel port.

6. Switch printer power on.

7. Plug the AC Power adapter’s output plug into the DC power

input socket on the rear end of the DP-101P+.

8. Plug the AC Power adapter into an electric service outlet. This

will supply power to the DP-101P+. (The DP-101P+ has no

power switch.) The DP-101P+’s self-test routines will proceed

automatically.
