D-Link D DWL-G700AP DWL-G700AP Manuale utente

Manual

DWL-G700AP

2.4GHz

Building Networks for People

Wireless Access Point

D-Link AirPlus G

Contents

PackageContents ................................................................................3

Introduction............................................................................................4

Wireless Basics....................................................................................6

GettingStarted......................................................................................8

UsingtheConfigurationUtility................................................................9

NetworkingBasics ..............................................................................19

Troubleshooting...................................................................................32

TechnicalSpecifications ......................................................................37

ContactingTechnical Support ..............................................................39

WarrantyandRegistration ...................................................................40

Computer with Windows, Macintosh, or Linux-based

operating system with an installed Ethernet adapter

Contents of Package:

D-Link AirPlusTM G DWL-G700AP

2.4GHz Wireless Access Point

Power Supply - 5V DC, 2.0A

ManualonCD

QuickInstallationGuide

Ethernet Cable

Package Contents

If any of the above items are missing, please contact your reseller.

System Requirements:



Note:Usinga powersupply with adifferent voltageratingthan theone included

withthe DWL-G700APwill causedamage andvoidthewarrantyforthisproduct.

Internet Explorer or Netscape Navigator version 6.0 or above,

with JavaScript enabled

Introduction

Atup to five timesthe speed ofprevious wirelessdevices (up to54Mbps), youcan work

faster and more efficiently, increasing productivity. With the DWL-G700AP, bandwidth-

intensiveapplicationslike graphics or multimediawill benefit significantly becauselarge

files are able to move across the network quickly.

The D-Link AirPlusTM G DWL-G700AP Wireless Access Point is an 802.11g high-

performance,wireless device that isalso compatible with 802.11bdevices. Itis an ideal

wayto extend thereach andnumber of computersconnected toyour wirelessnetwork.

Capable of data transfer rates up to 54Mbps, when used with other D-Link AirPlus G

products,the DWL-G700APiscompatiblewith mostpopularoperatingsystems, including

Macintosh, Linux and Windows, and can be integrated into a large network.

Up to 5X Faster with AirPlus G Products - high-speed wireless datatransfer

rates up to 54Mbps. With increased data rate and capacity, the DWL-G700AP

deliversmedia rich contentsuch asdigital images,videos, andMP3 files much

fasterthan standard802.11b networks.

Fully 802.11b Compatible – Fully compatible with the IEEE 802.11b

standardand interoperablewith allexisting 802.11bcompliantdevices.

Network Security with up to 128-bit WEP Encryption – Supports 64/128-

bit WEP encryption for a level of security for your data and wireless

communication.

Built-in DHCP Server – If enabled, it will automatically assign IP addresses

to wireless clients on the local network.

Web-based interface for Managing and Configuring – Easy-to-use

interfaceindependent of the operatingsystem.



Features and Benefits

LEDS

LEDstands forLight-Emitting Diode.The DWL-G700AP Wireless Access Point has

3 LEDs as shown below:

WLAN: blinkinggreen light

indicates wireless activity;

solid green light indicates

connection

LAN: blinkinggreen light

indicates activity; solid green

light indicates connection

Power: solid green light

indicates connection to a

powersource

Wireless Basics

D-Link wireless products are based on industry standards to provide easy-to-use and

compatiblehigh-speed wireless connectivity within yourhome,businessorpublicaccess

wirelessnetworks. D-Link wirelessproducts willallow youaccess tothe datayou want,

whenandwhereyouwant it.Youwillbeabletoenjoythefreedomthatwireless networking

brings.

AWireless LocalAreaNetwork(WLAN)isa computernetworkthattransmitsand receives

datawithradio signals instead ofwires. WLANs areused increasingly in bothhome and

office environments, and public areas such as airports, coffee shops and universities.

Innovativeways to utilizeWLANtechnologyarehelping peopletoworkandcommunicate

more efficiently. Increased mobility and the absence of cabling and other fixed

infrastructurehave proven to be beneficialfor many users.

Wireless users can use the same applications they use on a wired network. Wireless

adapter cards used on laptop and desktop systems support the same protocols as

Ethernetadapter cards.

Peopleuse WLAN technologyfor many different purposes:

Mobility - Productivity increases when people have access to data in any location

within the operating range of the WLAN. Management decisions based on real-time

informationcan significantly improve workerefficiency.

Low Implementation Costs –WLANs are easy to set up, manage, change and

relocate. Networks that frequently change can benefit from WLANs ease of

implementation. WLANs can operate in locations where installation of wiring may be

impractical.

Installation and Network Expansion - Installing a WLAN system can be fast

andeasy and caneliminate theneedto pull cablethroughwalls and ceilings.Wireless

technologyallows the networkto gowhere wirescannot go- evenoutside thehome or

office.

Scalability – WLANs can be configured in a variety of ways to meet the needs of

specific applications and installations. Configurations are easily changed and range

frompeer-to-peer networks suitable fora small numberof usersto larger infrastructure

networksto accommodate hundredsor thousandsof users,depending onthe number

ofwireless devices deployed.

Inexpensive Solution - Wireless network devices are as competitively priced as

conventionalEthernetnetworkdevices.

Installation Considerations

Keepin mind, that the number,thickness and location ofwalls, ceilings,or otherobjects

that the wireless signals must pass through, may limit the range. Typical ranges vary

dependingon the typesof materialsand backgroundRF (radiofrequency) noisein your

home or business. The key to maximizing wireless range is to follow these basic

guidelines:

Wireless Basics (continued)

Keep the number of walls and ceilings between the DWL-G700AP and other

networkdevicestoaminimum-eachwallorceilingcanreduceyourDWL-G700AP’s

range from 3-90 feet (1-30 meters.) Position your devices so that the number of

walls or ceilings is minimized.

Beaware of the direct linebetween networkdevices.Awallthat is 1.5 feetthick

(.5meters),at a 45-degree angleappears to bealmost 3 feet (1meter) thick.At

a 2-degree angle it looks over 42 feet (14 meters) thick! Position devices so

thatthesignalwilltravelstraightthrough a wall or ceiling (instead of at an angle)

forbetterreception.

Buildingmaterialscanimpedethewirelesssignal-asolidmetaldoororaluminum

studsmayhaveanegativeeffectonrange.Trytopositionwirelessdevicesand

computerswith wireless adapters sothat thesignal passes throughdrywall or

opendoorways and notother materials.

Keepyourproductaway(atleast3-6feetor1-2meters)fromelectrical devices

orappliances that generateRF noise.

Pleaseremember that D-LinkAirPlus G wirelessdevices are pre-configured to

connect together, right out of the box, with their default settings.

You will need broadband Internet access (a Cable or DSL-subscriber line into

your home or office)

Consult with your Cable or DSL provider for proper installation of the modem

Connectthe Cable or DSLmodem to yourbroadband router(see the Quick

Installation Guide includedwith your router.)

If you are connecting a desktop computer in your network, you can install the

D-Link AirPlusG DWL-G510 wireless PCIadapter into anavailable PCIslot on

yourdesktopcomputer.

(Seethe Quick Installation Guide included with the DWL-G510.)

Installthe drivers for thewireless Cardbus adapter intoa laptop computer.

(e.g,the DWL-G630; See theQuick Installation Guide included with the

DWL-G630.)

Setting up a Wireless

Infrastructure Network

211

Getting Started

Connect the router to the D-Link AirPlus G DWL-G700AP.

(Seethe Quick Installation Guide includedwiththe DWL-G700AP.)

For a typical wireless setup at home (as shown above), please do the following:

DWL-G700AP

After you have completed the initial installation and the Setup Wizard (as illustrated in

the Quick Installation Guide that is included with the DWL-G700AP), you can access

the configuration menu, at any time, by opening the web-browser and typing in the IP

addressof the DWL-G700AP.TheDWL-G700AP’sdefault IP address is shownbelow:

Openthewebbrowser

Type in the IP address of the

DWL-G700AP.(192.168.0.50).

Type admin in the

User Name field

LeavethePassword

blank

ClickOK



admin



Using the Configuration Utility

If you wish to change the default settings or optimize the performance of the

DWL-G700AP,D-Linkhas included a configurationutility for thispurpose.

Note: If you have changed the default IP address assigned to the DWL-G700AP, make

sure to enter the correct IP address.

TheHome>Wizardscreen

willappear. Pleasereferto

theQuickInstallationGuide

formoreinformation

regardingtheSetupWizard.

Using the Configuration Utility (continued)

Home > Wireless

ASCII(American

StandardCodefor

Information

Interchange)isa

codefor

representing

English letters as

numbersfrom0-

127

Hexadecimal

digits consist of

thenumbers 0-9

and the lettersA-F

SSID: (Service Set Identifier)Default is the default setting. The SSID is a unique

name that identifies a network. All devices on a network must share the same SSID

name in order to communicate on the network. If you choose to change the SSID from

the default setting, input your new SSID name in this field.

Channel: Channel 6 is the defaultchannel. Input anewnumber if youwantto change

the default setting. All devices on the network must be set to the same channel to

communicate on the network.

Authentication:

WEP: Select Enabled or Disabled.

WEP Encryption: Select64-bit or 128-bit WEP encryption.

Key Type: Select Hexadecimal or ASCII key type

Keys 1-4: Inputup to fourencryption keys.Youwill select one ofthese tobe theactive key.

Apply: ClickApply to apply thechanges.

Select Open System to communicate the key across the network.

Select Shared Key to limit communication only to those devices

that share the same WEP settings.

Select WPA to select Wi-Fi Protected Access in conjunction with a

RADIUSserverinyour network

Select WPA-PSK to select Wi-Fi Protected Access without a

RADIUSserver.

Altri manuali per D DWL-G700AP DWL-G700AP

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali D-Link Punto di accesso wireless

D-Link

D-Link DWL-2600AP Manuale di servizio

D-Link

D-Link AirPro DWL-6000AP Manuale utente

D-Link

D-Link DAP-3520 - AirPremier N Dual Band Exterior PoE Access... Manuale utente

D-Link

D-Link Rangebooster N 650 Access Point DAP-1353 Manuale utente

D-Link

D-Link DAP-1360 Manuale utente

D-Link

D-Link DWL-8600AP Manuale utente

D-Link

D-Link DAP-3220 Manuale utente

D-Link

D-Link AirPremier N DAP-2690 Manuale utente

D-Link

D-Link DWL-3600AP Manuale utente

D-Link

D-Link DAP-2553 - Wireless N Dual Band Gigabit Access... Manuale utente

D-Link

D-Link AirPremier DAP-2565 Manuale utente

D-Link

D-Link DAP-2553 - Wireless N Dual Band Gigabit Access... Manuale utente

D-Link

D-Link DAP-1260L Manuale utente

D-Link

D-Link DAP-3860 Manuale utente

D-Link

D-Link AirPremier DWL-7700AP Manuale utente

D-Link

D-Link DAP-1155 Manuale utente

D-Link

D-Link DAP-1513 Manuale utente

D-Link

D-Link AirPro DWL-6000AP Manuale utente

D-Link

D-Link DWL-3200AP - AirPremier - Wireless Access... Manuale utente

D-Link

D-Link D DWL-8200AP DWL-8200AP Manuale utente

D-Link

D-Link DAP-2660 Manuale utente

D-Link

D-Link DWL-6600AP Manuale utente

D-Link

D-Link DWL-3200AP - AirPremier - Wireless Access... Manuale utente

D-Link

D-Link DWL-8220AP - AirPremier Wireless Switch Dualband Access... Manuale utente

Manuali Punto di accesso wireless popolari di altre marche

Ubiquiti

Ubiquiti NanoStation NSM2 Manuale utente

Cisco

Cisco Aironet 1550 Series Manuale utente

Aruba

Aruba IAP-335 Manuale utente

Advantek Networks

Advantek Networks AWN-AP-54MR Manuale utente

IP-COM

IP-COM AP355 Manuale utente

Buffalo

Buffalo AirStation WLA-L11G Manuale utente

EnGenius

EnGenius EnStationACv2 Manuale utente

xG Technology

xG Technology xMax CN1300 Manuale utente

Widelink

Widelink ezWave WAP-1100 Series Manuale utente

Edimax

Edimax CAP1200 Manuale utente

Ubiquiti

Ubiquiti LBE-5AC-Gen2 Manuale utente

Aruba

Aruba AP-203R Manuale utente

LuXout Shades

LuXout Shades LUXSHADE MOTION Manuale utente

CreatComm

CreatComm TB5F Manuale utente

SineDigital

SineDigital MW-1500AP(H) Manuale utente

TP-Link

TP-Link AP9650 V1 Manuale utente

Draytek

Draytek VIGORAP 902 Manuale utente

EnGenius

EnGenius EAP350 Manuale utente
