Daewoo RC-L381 Manuale utente

SPECIFICATION

Model RC-L381

Rating 220~240V/50Hz

Watts MAX 1800W

Weifhts(net) 4.7kg

Dimension (LxWxH) 383 X 269 X 265mm

Cord length 5m

VACUUM CLEANER

OWNER'S MANUAL

1 2

DESCRIPTION AND OPERATION

HOSE CONNECTION SUCTION CONTROL

•

The suction power control at

the hand grib enables you to

control suction power.

PIPE CONNECTION

•

To connect the nozzle, hold

the tubes and the handle:

insert the narrowed section

into the wide section.

WIDE SUCTION NOZZLE

•

Use this nozzle for cleaning both

carpeted and uncarpeted floors.

CORD REWIND BUTTON

•

Rewind the power cord by

pressing the cord rewind

button.

ON/OFF SWICH

POWER CONTROL SWITCH

• Turn the unit off(on) by

pressing the ON/OFF

switch button on the unit.

•

Adjust the suction power by

rotating the swich on the unit

DUST METER

•

When the color of the dust

meter is changed to RED for

long time, change the dust

bag.

DUST METER

STORAGE

• If you want to store the

cleaner, hitch the brush clip

onto the vacuum cleaner.

PRACTICAL PARKING

• Cleaning for a while, you

can place the brush clip

into the rest.

COMBI CREVICE NOZZLE

•

Connecting the hose : insert

the hose firmly into the hose

inlet ("Click")

•

Disconnecting the hose: press

the button and pull the hose

out of the vacuum cleanet.

Brush clip Rest

CLEANING THE FILTER PRECAUTIONS FOR SAFE USE

This vacuum cleaner should only be used for normal dry household dust and dirt.

The manufacturer cannot be responsible for any damage caused by use or operation of the cleaner

contrary to these instructions.

If the cleaner is wrongly operated for a purpose other than that for which it is intended. no liability can

be accepted for any possible damage.

CHANGING THE DUSTBAG

• Switch off.

• Press the clamp position of the

air outlet cover to discharge the

air outlet cover forclean up or a

new replacement.

•

Separate the filter from the

filter case and shake the

dust out of the filter.

•

Do not vacuum areas which contain moisture

or water and inflammable matter, needles,

pins, razor blades, matches, cigarette-ends,

etc., since they may damage the cleaner or

dust bag or cause a fire.

•

When rewinding the power cord, hold the

plug body before pressing the cord rewind

button to prevent whipping.

•

Do not pull the power cord beyond the

specified length.

•

Make sure a dust bag and a motor protection

filter are always inserted.

•

This product provided with a cable which, if

damaged must be replaced by a repair shop

authorized by the manufacturer since special

tools are required.

•

Switch off and open the

cover.

•

Take the dust bag holder

with dust bag out from the

dust compartment

• Shake the dust out of the

filter.

EXHAUST FILTER

MOTOR PROTECTION

FILTER

•

Switch off and open the

cover.

•

Take the dust bag holder

with dust bag out from the

dust compartment.

•

Insert the new dust bag into

the dust bag holder properly

as shown in picture.

Note:

If no dustbag has been

placed into the dustbag holder,

the cover cannot be closed.

BEFORE ASKING FOR SERVICE

■

Before Asking for Service, please check each item below if you have trouble with your cleaner.

Problem Check Point Measure

Suction power is weak. • Dust bag

• Pipe or hose

- If dust bag is dirty, replace it.

- If clogged or blocked, remove the object.

The cleaner does not

work. • Power cord

• on/off switch

- Check if power cord is plugged.

Check if the power switch is turned on.

Power cord does not

rewind. • Power cord

- Pull the power cord out a little and press

the cord rewind button.
