DANE-ELEC SO G-STREAM - Manuale utente
Download User Manual on www.danedigital.com
Quickstart Guide
Guide de prise en main
Multimedia Player
Lecteur Multimedia
PC
2Download User Manual on www.danedigital.com
1- So G-Stream 2- Remote Control 3- A/C Adapter 4- Audio/Video cable 5- Antenna
6- Quick Start Guide 7- CD-ROM
1- So G-Stream 2- Télécommande 3- Bloc d’alimentation 4- Cable Audio/Video 5- Antenne
6- Guide d’installation 7- CD-ROM
1- So G-Stream 2- Mandóa distancia 3- Adaptator de alimentació4- Cable Audio/Video
5- Antena 6- Quick Start Guide 7- CD-ROM
1- So G-Stream 2- Fembiedienung 3- Ernährungsadapte 4- Audio/Video Kabel
5- Antenne 6- Quick Start Guide 7- CD-ROM
1- So G-Stream 2- Afstandbediening 3- Voedingsadapter 4- Audio/Video kabel
5- Antenne 6- Quick Start Guide 7- CD-ROM
1- So G-Stream 2- Telecomando 3- Adattatore di alimentazione 4- Cavo Ausio/Video
5- Antenna 6- Quick Start Guide 7- CD-ROM
1- So G-Stream 2- Telecomando 3- Adaptador de alimentação 4- Cabo Audio/Video
5- Antena 6- Quick Start Guide 7- CD-ROM
1- So G-Stream 2- Fjernbetjening 3- Strømforsyning 4- Audio/Video kabel
5- Antenne 6- HDMI kabel 7- CD-ROM
Packaging Content*
Contenu de l’emballage
45 6 7
21* 3*
*Photos are given as guidelines and may change without notice.
3Download User Manual on www.danedigital.com
Front, Back and Side Panel
Vue de Face, Arrière et Coté
Power
Power LED
Power
input
USB
Host
LAN Wifi
Composite
video and
audio output
HDMI
output
Memory Card
Reader 3 in 1
SDHC
Optical USB
Host
Infra Red Receiver
4Download User Manual on www.danedigital.com
Remote control
Télécommande
BUTTON FUNCTION
POWER Turn on and off in the stand by mode
MUTE Turn on or shut audio output
TV SYSTEM Press to switch between NTSC (480p), PAL (576p),
480P, 576P, 720P 50HZ, 720P 60HZ, 1080I
50HZ and 1080I 60HZ
0-9 Press to input digital
GOTO Press to play the video at the chapter after setting
schedule
OPTION Press to select option bar. To rename or cancel
the file
FR Press to fast rewind from current play and again to
select the speed
FF Press to fast forward from current play and again
to select the speed
RETURN Return to the previous menu
SETUP Enter the menu
Press shortly to move cursor left
Press shortly to move cursor right
Press shortly to move cursor up
Press shortly to move cursor down
ENTER Press to confirm
PREW Press to return to previous file
NEXT Press to go to next file
VOL- Press to decrease the volume
VOL+ Press to increase the volume
PLAY Press to play file. Or play recording file under time
shift mode
STOP Press to stop play/recording
PAUSE/STEP Press to pause play/recording, and again for step
playing
REPEAT Press to set repeat option: chapter, Title or off
COPY Enter the copy mode
SELECT No role for the time being
5Download User Manual on www.danedigital.com
CONFIRM No role for the time being
DISPLAY Press to display time, title, information of chapter
when play video and photo
SUBTITLE Switch the subtitle if the file supported
SLOW Press to have slow motion: 3/4,1/2, 1/4, 1/8,
1/16X. Press PLAY to resume regular play mode.
AUDIO Switch audio track.
ZOOM Press to zoom when playing back photos or Video pro-
grams.
Photo zoom levels:2X,4X,8X,16X
Video zoom levels:2X,3X,4X,8X
ALL Presses this key, show all files
MUSIC Presses this key, show all audio files
PHOTO Presses this key, show all picture files
MOVIES Presses this key, show all video files
Change the language
Changez la langue
Select SETUP on the remote control1.
Select System on the screen2.
Select Menu Language3.
Select the language you want to choose :4.
ex : French
"Enter"5.
Select SETUP button on the remote control to save the new setting.6.
6Download User Manual on www.danedigital.com
6
Outupts / Sorties
Download User Manual on www.danedigital.com
Audio/Video :•
CVBS
AUDIO-L
AUDIO-R
Ye llow
White
Red
Connect the So G-STream•
The SO G-Stream detect automatically the video out connected.
Change Video Mode :
Mode by defaut AV
HDMI (cable not included):•
HDMI
Audio/Video
7Download User Manual on www.danedigital.com
7
Connect to the Network
Connecter au réseau
Download User Manual on www.danedigital.com
Wired : via• RJ45,
10/100 LAN
Wireless : via WIFI (1)•
Plug the LAN Cable.1.
Select SETUP on the remote control.2.
Select "NET" on the screen, then "ENTER".3.
The So G-Stream detect automatically the network.4.
Press "ENTER" to continue.5.
Select DHCP IP (Auto)
"ENTER"
YES, "ENTER"
YES, "ENTER"
"ENTER"
Select modify "ENTER"
Select "Ap", "ENTER"
Select "Auto", "ENTER"
8Download User Manual on www.danedigital.com
8Download User Manual on www.danedigital.com
Wireless : via WIFI (2)•
Select your Access Point in the list:
Ex : Dane-Elec Guest with the remote control
Then push "ENTER"
"Auto"
"ENTER"
Select Wireless Security : Ex : I WPA/WPA2 Key
"ENTER"
Enter your password then "OK", "ENTER",
Save setting, "ENTER"
"Testing Screen"
Now it’s OK
Push left arrow of the remote control to exit.
NB : Don’t choose wired or wireless network both in the same time
To see data’s from:
USB external HDD or USB Pendrive:
Connect your USB external HDD to So G-Stream.•
Select USB DEVICE on the screen, wait 10 sec.•
«ENTER»•
9Download User Manual on www.danedigital.com
9
To see data’s from:
Download User Manual on www.danedigital.com
Select the file you want to see, when you see the preview, select•
«ENTER» to see the movie in full screen.
Memory Flash Card:
Plug your Memory Flash Card to So G-Stream.•
Select CARD READER on the screen, wait 10 sec.•
«ENTER»•
Select the file you want to see, when you see the preview, select•
«ENTER» to see the movie in full screen.
Network:
Select NETWORK on the screen.•
«ENTER»•
Select WORKGROUP•
«ENTER»•
Select the machine you want to stream on:•
Select the file you want to see, when you see the preview, select•
«ENTER» to see the movie in full screen.
10 Download User Manual on www.danedigital.com
10 Download User Manual on www.danedigital.com
Warranty
