Danfoss VLT MCB 115 Manuale utente

Installation Guide

VLT® Programmable I/O MCB 115

VLT® HVAC Drive FC 102, VLT® Refrigeration

Drive FC 103, VLT® AutomationDrive FC 301/302

Contents

1 Introduction 4

1.1 Purpose of this Installation Guide 4

1.2 Trademarks 4

1.3 Document Version 4

1.4 Additional Resources 4

1.5 Product Overview 4

1.5.1 Intended Use 4

1.5.2 Foreseeable Misuse 5

1.5.3 Items Supplied 5

2 Safety 6

2.1 Safety Symbols 6

2.2 Qualified Personnel 6

2.3 Safety Precautions 7

3 Installation 8

3.1 Safety Instructions 8

3.2 Mounting the Option in Enclosure Sizes A2, A3, and B3 8

3.3 Mounting the Option in Enclosure Sizes A5, B1, B2, B4, C, D, E, and F 9

3.4 Electrical Installation 10

3.4.1 Specifications 10

3.4.1.1 Programmable Inputs 11

3.4.1.2 Programmable Outputs 12

3.4.1.3 Terminals 13

4 Appendix 14

4.1 Abbreviations 14

4.2 Conventions 14

ContentsInstallation Guide | VLT® Programmable I/O MCB 115

1 Introduction

1.1 Purpose of this Installation Guide

This manual provides information for safe installation of a VLT® Programmable I/O MCB 115 option used in the VLT® FC drive series.

The installation guide is intended for use by qualified personnel only. Personnel must be familiar with the VLT® FC drive series.

Read and follow the instructions before installation, and ensure that instructions for safe installation are observed. Always keep these

instructions available with the drive.

1.2 Trademarks

VLT® is a registered trademark for Danfoss A/S.

1.3 Document Version

This manual is regularly reviewed and updated. All suggestions for improvement are welcome. See document version and changes

applied in table 1.

The original language of this manual is English.

Table 1: Version and Changes Applied

Revision date Remarks

2019.10 Option now also applicable for VLT® HVAC Drive FC 102 and VLT® Refrigeration Drive FC 103.

1.4 Additional Resources

More information resources are available to understand advanced drive functions and programming.

• The VLT® FC Series Operating Guides provide information required to install and commission the drive for given applications.

• The VLT® FC Series Programming Guides provide greater detail on working with parameters.

• VLT® FC Series Design Guides provide detailed capabilities and functionality to design motor control systems for various

applications.

Technical documentation for other product options is available at www.danfoss.com.

1.5 Product Overview

1.5.1 Intended Use

The VLT® Programmable I/O MCB 115 is intended to:

Introduction

Installation Guide | VLT® Programmable I/O MCB 115

AN295938195323en-000101 / 130R0655

• Extend the I/O selection available on the control card, for example, for multi-zone control with 3 pressure transmitters.

• Turn the AC drive into a decentralized I/O block supporting building automation systems with inputs and outputs.

• Support the extended PI controllers with I/Os for setpoint inputs, transmitter/sensor inputs, and outputs for actuators.

• Provide a digital output used for:

- Driving a relay.

- Input to commonly used PLC I/O boards.

- Input to another AC drive in a sequentially controlled application.

The VLT® Programmable I/O MCB 115 is intended for use only with:

• VLT® HVAC Drive FC 102

• VLT® Refrigeration Drive FC 103

• VLT® AutomationDrive FC 301

• VLT® AutomationDrive FC 302

NOTICE

The VLT® Programmable I/O MCB 115 is only functional if it is built into the drive. The option cannot be used as a standalone.

1.5.2 Foreseeable Misuse

Any use not expressly approved by Danfoss constitutes misuse. This also applies to failure to comply with the specified operating

conditions and applications.

Danfoss assumes no liability of any sort for damage attributable to improper use.

1.5.3 Items Supplied

When the VLT® Programmable I/O MCB 115 is not factory mounted, the following items are supplied:

• VLT® Programmable I/O MCB 115 B-option with coated PCB, order number 130B1266.

• LCP cradle

• Front cover

• Stickers for front cover

• Installation Guide

Introduction

Installation Guide | VLT® Programmable I/O MCB 115

AN295938195323en-000101 / 130R0655| 5

2 Safety

2.1 Safety Symbols

The following symbols are used in this manual:

DANGER

Indicates a hazardous situation which, if not avoided, will result in death or serious injury.

WARNING

Indicates a hazardous situation which, if not avoided, could result in death or serious injury.

CAUTION

Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.

NOTICE

Indicates information considered important, but not hazard-related (for example messages relating to property damage).

2.2 Qualified Personnel

The products must only be assembled, installed, programmed, commissioned, maintained, and decommissioned by persons with

proven skills. Persons with proven skills:

• Are qualified electrical engineers, or persons who have received training from qualified electrical engineers and are suitably

experienced to operate devices, systems, plant, and machinery in accordance with the general standards and guidelines for safety

technology.

• Are familiar with the basic regulations concerning health and safety/accident prevention.

• Have read and understood the safety guidelines given in this manual and also the instructions given in the operating guide of the

drive.

• Have good knowledge of the generic and specialist standards applicable to the specific application.

Safety

Installation Guide | VLT® Programmable I/O MCB 115

AN295938195323en-000101 / 130R0655

2.3 Safety Precautions

WARNING

UNINTENDED START

When the drive is connected to the AC mains, DC supply, or load sharing, the motor may start at any time, causing risk of death,

serious injury, and equipment or property damage. The motor may start by activation of an external switch, a fieldbus

command, an input reference signal from the LCP or LOP, via remote operation using MCT 10 Set-up software, or after a cleared

fault condition.

-Press [Off] on the LCP before programming parameters.

-Disconnect the drive from the mains whenever personal safety considerations make it necessary to avoid unintended

motor start.

-Check that the drive, motor, and any driven equipment are in operational readiness.

WARNING

LACK OF SAFETY AWARENESS

This document gives important information on how to prevent injury and damage to the equipment or the system. Ignoring

them can lead to death, serious injury, or severe damage to the equipment.

-Make sure to fully understand the dangers and safety measures incurred in the application.

Safety

Installation Guide | VLT® Programmable I/O MCB 115

AN295938195323en-000101 / 130R0655| 7

3 Installation

3.1 Safety Instructions

WARNING

DISCHARGE TIME

The drive contains DC-link capacitors, which can remain charged even when the drive is not powered. High voltage can be

present even when the warning indicator lights are off.

Failure to wait the specified time after power has been removed before performing service or repair work could result in death

or serious injury.

-Stop the motor.

-Disconnect AC mains, permanent magnet type motors, and remote DC-link supplies, including battery back-ups, UPS, and

DC-link connections to other drives.

-Wait for the capacitors to discharge fully before performing any service or repair work. The discharge time is specified in the

drive operating guides.

-Use a measuring device to make sure that there is no voltage, before opening the drive or performing any work on the

cables.

WARNING

BEFORE INSTALLATION/REPAIR

The operator or electrical installer is responsible for compliance with all applicable national and local safety regulations. Not

following national and local regulations may lead to personal injury.

-Disconnect all electric power, including remote disconnects, and discharge all motor start/run capacitors before servicing.

-To ensure that the power cannot be inadvertently energized, follow proper lock-out/tag-out procedures.

For more safety information, see 2 Safety and the relevant drive operating guide. Also, always observe the instructions provided by the

motor manufacturer.

3.2 Mounting the Option in Enclosure Sizes A2, A3, and B3

Context:

The installation procedure depends on the enclosure size of the drive. This procedure is for installation in enclosure sizes A2, A3, and

B3.

Installation

Installation Guide | VLT® Programmable I/O MCB 115

AN295938195323en-000101 / 130R0655

Procedure

1. Remove the LCP, the terminal cover, and the LCP frame from the drive.

2. Fit the option into slot B.

3. Connect the control cables and relieve the cable. See 3.4.1 Specifications for wiring details.

4. Remove the knockouts in the extended LCP frame (supplied).

5. Fix the extended LCP frame and terminal cover on the drive.

6. Fit the LCP or blind cover in the extended LCP frame.

7. Connect power to the drive.

8. Set up the input/output functions in the corresponding parameters.

e30be183.11

1LCP

3Slot B

5LCP frame

2Terminal cover

4Option

Illustration 1: Installation in Enclosure Sizes A2, A3, and B3

3.3 Mounting the Option in Enclosure Sizes A5, B1, B2, B4, C, D, E, and F

Context:

The installation procedure depends on the enclosure size of the drive. This procedure is for installation in enclosure sizes A5, B1, B2, B4,

C, D, E, and F.

Installation

Installation Guide | VLT® Programmable I/O MCB 115

AN295938195323en-000101 / 130R0655| 9

Procedure

1. Remove the LCP and the LCP cradle.

2. Fit the option card into slot B.

3. Connect the control cables and relieve the cable. See 3.4.1 Specifications for wiring details.

4. Fit the cradle on the drive.

5. Fit the LCP in the cradle.

e30be184.11

Illustration 2: Installation in Enclosure Sizes A5, B1, B2, B4, C, D, E, and F

3.4 Electrical Installation

3.4.1 Specifications

The VLT® Programmable I/O MCB 115 has 3 programmable inputs/outputs, which extend the number of inputs and outputs for the

drive.

Installation

Installation Guide | VLT® Programmable I/O MCB 115

AN295938195323en-000101 / 130R0655
