DataCard CP40 Manuale utente

CP40 Printer Guide

553772-201 Rev. J

September 2005

Information resources for the CP40 Card Printer

Installation To install the printer:

To install one printer to a PC using a USB cable, see the

Installation Map, shipped at the top of the printer carton.

For detailed installation information or for special

situations (such as network installation), see Info Central.

Message Help If you see a message, click Help on the message box.

Really! Help topics are short and to the point.

Printer Guide This Printer Guide contains operating information for the

printer and driver.

Info Central For in-depth information about using the printer, install

Info Central on a Windows PC, then click the icon on the

desktop. (Insert the CP Driver CD-ROM and choose User

Information to install Info Central.)

Dealer

For help with questions not addressed by other CP Series printer information, contact your dealer.

Customer

Care

Contact the Datacard

Customer Care Center at 1.800.328.3996 (U.S. & Canada) or 1.952.988.2316

(worldwide)..

539251-201 Page iii

Contents

About the printer . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Loading cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Loading print ribbon. . . . . . . . . . . . . . . . . . . . . . . . . 7

Check the PC connection . . . . . . . . . . . . . . . . . . . . 9

Power on the printer . . . . . . . . . . . . . . . . . . . . . . . 10

Status light. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

The LCD panel . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Opening Properties or Printing Preferences . . . . . 15

Open the Printer Toolbox . . . . . . . . . . . . . . . . . . . 17

Cleaning the printer . . . . . . . . . . . . . . . . . . . . . . . . 19

Getting the most out of your printer . . . . . . . . . . . . 21

Printer supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Site requirements . . . . . . . . . . . . . . . . . . . . . . . . . 27

Legal Notices (FCC) . . . . . . . . . . . . . . . . . . . . . . . 28

Page 1

About the printer

The outside of the printer

Printer Cover.

Latch: Lift the latch to open the printer cover.

Input hopper: Lift the cover to load blank cards.

Output hopper: Remove completed cards.

Ready button: Push to pause or unpause the printer.

The status light helps you understand printer operation.

See "Status light" on page 11 for details.

Page 2

Ports are located on the left side of the printer.

Manual Advance Knob: Use to release a card in

the printer or to turn rollers.

Power Receptacle: Plug in the power supply to

power on the printer.

Cable Guides: Hold the data cable securely.

Optional Smart Card USB Port: See “Features and

options” on page 4.

Optional Smart Card Serial Port: See “Features

and options” on page 4.

USB Data Port: Connect the data cable to the

printer. All printers use this port.

Page 3

The inside of the printer

Cover Arm: Holds the cover and printhead cartridge in place.

Printhead Cartridge: Applies the image to the card.

Print Ribbon Cartridge (shown with color print ribbon).

Printer Label: Includes the serial number and model information

(located on the left side of the printer and not visible in this drawing).

Cleaning roller (not visible in this drawing): Removes dust and debris

from cards.

Tip: Lift the latch to open the printer and see inside.

Page 4

Features and options

Features and options are identified on the printer label.

• Printers with “U” printing can print one color

(monochrome). Printers with “C” printing can print in

full color or monochrome (with specific ribbons).

• All CP40 printers use a USB connection.

• A magnetic stripe module can be a three-track (IAT)

module. The optional magnetic stripe module is visible

inside the printer.

• An optional smart card module can be one of the

following:

— Combination smart card reader (SC347) with

contact and contactless reader. Visible inside the

printer; includes a USB port on the printer.

— Contact station (SC400): visible inside the printer;

includes a serial port.

Page 5

Loading cards

1Open the input hopper cover.

2Remove cards from the original package.

Tips: Handling cards

•Cards can stick together: Slide or fan cards to separate the edges.

•Do not touch the surface of cards before printing them. (Oils on

hands will reduce printing quality.)

•Handle cards by the edges or wear gloves.

•Orient all cards the same way.

Page 6

3Place the cards in the input hopper. The diagram

shows the typical locations for the magnetic stripe

and smart card chip.

4Push the input hopper cover closed until it

latches.

See Info Central for current information about cards

to use in the printer.

Magnetic stripe

Smart card chip

Page 7

Loading print ribbon

1Open the printer cover.

2Remove the ribbon cartridge.

3Remove both used ribbon spools from the

cartridge (if present).

Tips: Handling print ribbon

•Keep unused ribbon in the original

package.

•Don’t place ribbon on a dusty or dirty

surface–dirt could damage the printhead.

4Run a cleaning card and replace the

cleaning sleeve at the same time that you

load a new print ribbon. See "Cleaning the

printer" on page 19 for the steps to follow.
