Datalogic PowerScan M8300 Manuale utente

PowerScan™ M8300 Readers

Industrial Handheld Laser Bar Code Reader

with Datalogic’s STAR Cordless System™

Quick Reference Guide

Datalogic ADC, Inc.

959 Terry Street

Eugene, OR 97402

USA

Telephone: (541) 683-5700

Fax: (541) 345-7140

mentation or the procedures described therein may be reproduced or transmitted

in any form or by any means without prior written permission of Datalogic ADC,

Inc. or its subsidiaries or affiliates ("Datalogic" or "Datalogic ADC"). Owners of Data-

logic products are hereby granted a non-exclusive, revocable license to reproduce

and transmit this documentation for the purchaser's own internal business pur-

poses. Purchaser shall not remove or alter any proprietary notices, including copy-

right notices, contained in this documentation and shall ensure that all notices

appear on any reproductions of the documentation.

Should future revisions of this manual be published, you can acquire printed ver-

sions by contacting your Datalogic representative. Electronic versions may either

be downloadable from the Datalogic website (www.datalogic.com) or provided on

appropriate media. If you visit our website and would like to make comments or

suggestions about this or other Datalogic publications, please let us know via the

"Contact Datalogic" page.

Disclaimer

Datalogic has taken reasonable measures to provide information in this manual

that is complete and accurate, however, Datalogic reserves the right to change any

specification at any time without prior notice.

Datalogic and the Datalogic logo are registered trademarks of Datalogic S.p.A. in

many countries, including the U.S.A. and the E.U. All other brand and product

names may be trademarks of their respective owners.

Patents

This product may be covered by one or more of the following patents:

Design Pat. AU 310201; AU 310202; CN 693980; CN735959; HK 0602013.5M001; HK

0602013.5M002; JP 1305693; KR 30-0460940; US D570,843 S; USD588,596 S.

US Pat. 5,992,740; 6,305,606 B1; 6,517,003; 6,808,114 B1; 6,997,385 B2; 7,387,246 B2;

5,367,151; 5,449,893; 5,545,889; 6,098,877; 6,220,514 B1; 6,412,698 B2; 6,607,132 B1;

6,817,529 B2; 6,834,805 B2; 7,948,214 B2.

European Pat. 789,315 B1; 895,175 B1; 1,128,314 B1; 1,128,315 B1; 1,396,811 B1;

1,413,971 B1; 1,816,585 B1; 1,942,442 B1.

Additional patents pending.

Table of Contents

Updates and Language Availability .............................................................. 1

Using PowerScan™ M8300 ............................................................................. 2

Scan Line Position .................................................................................. 2

Reading Angle ......................................................................................... 2

Aiming System ........................................................................................ 3

Charging the Batteries ................................................................................... 4

Battery Safety ......................................................................................... 5

Setup ........................................................................................................ 7

PowerScan™ M8300 Configuration ............................................................... 8

PowerScan™ M8300/BC-80X0 Point-to-Point Setup ......................... 8

PowerScan™ M8300/BC-80X0 Stand Alone Setup ............................. 9

Using Multiple Readers with Same Cradle ......................................... 11

PowerScan™ M8300/STAR-MODEM™ Stand Alone Setup ............... 11

PowerScan™ M8300/STAR-SYSTEM™ Setup ..................................... 12

PowerScan™ M8300 Default Configuration ................................................ 14

Technical Features ........................................................................................ 15

Reading Tables .............................................................................................. 16

Datalogic ADC Limited Factory Warranty ................................................... 17

Warranty Coverage ............................................................................... 17

Warranty Claims Process ..................................................................... 17

Warranty Exclusions ............................................................................. 18

No Assignment ..................................................................................... 18

Risk of Loss ........................................................................................... 18

Service and Support ...................................................................................... 19

Compliance .................................................................................................... 20

FCC Compliance ..................................................................................... 20

Radio Compliance ................................................................................. 20

Laser Safety Compliance ...................................................................... 20

LED CLASS ............................................................................................. 21

IC (Industry Canada) .............................................................................. 21

Power Supply ......................................................................................... 21

Brazilian Certification Statements ...................................................... 24

WEEE Compliance ................................................................................. 25

Numeric Table ............................................................................................... 26

NOTES

Quick Reference Guide 1

UPDATES AND LANGUAGE AVAILABILITY

UK/US

The latest drivers and documentation updates for this product are available on the

Datalogic website at www.datalogic.com.

Su Internet sono disponibili le versioni aggiornate di driver e documentazione di

questo prodotto. Collegarsi a : www.datalogic.com

Les versions mises à jour de drivers et documentation de ce produit sont disponibles

sur Internet. Cliquez sur : www.datalogic.com

Im Internet finden Sie die aktuellsten Versionen der Treiber und Dokumentation von

diesem Produkt. Adresse : www.datalogic.com

En Internet están disponibles las versiones actualizadas de los drivers y

documentación de este producto. Dirección Internet : www.datalogic.com

Using PowerScan™ M8300

2PowerScan™M8300

USING POWERSCAN™M8300

The PowerScan™M8300 series readers can be used with either an BC-80X0 cradle or

Stargate™ radio base station to build a Cordless Reading System for the collection,

decoding and transmission of barcoded data.

PowerScan™M8300 laser readers automatically scan barcodes at a distance. Simply

aim and pull the trigger.

SCAN LINE POSITION

Code scanning is performed along the scan line emitted from the reading window.

This line must cross the entire code. The best reading angles are indicated in the

figure below:

READING ANGLE

Successful scanning is obtained by tilting the reader with respect to the barcode to

avoid direct reflections that impair the reading performance, see the figure below.

Using PowerScan™ M8300

Quick Reference Guide 3

AIMING SYSTEM

PowerScan™M8300 provides an aiming system. If enabled, a partial trigger press

produces a red spot, which should be aimed over the code center to get the best

reading performance, see figure (1) above. By completely pressing the trigger the

scan line appears to start the code scanning (2).

After setting up the reader, you can enable or disable the aiming system by reading

the codes below:

Disable Aiming System (Default)

Ì$+Bj0$-"Î

Enable Aiming System

Ì$+Bj1$-'Î

Charging the Batteries

4PowerScan™M8300

CHARGING THE BATTERIES

Once the BC-80X0/C-8000 is powered, you can charge the reader's batteries.

Place the PowerScan™M8300 into the BC-80X0 cradle or the C-8000 battery charger.

The "Reader" LED on the cradle/battery charger turns red.

The battery is completely charged when the "Reader" LED on the cradle/battery

charger turns green.

To change the batteries, unscrew the retaining screw and extract the battery pack

from the reader handle. Then, insert the new battery pack into the reader handle and

tighten the screw. (See the following figures).

Figure 1 – Changing the Batteries

Before using the Battery, read “Battery Safety” in the following section.

Datalogic recommends annual replacement of rechargeable battery packs

to ensure maximum performance.

Charging the Batteries

Quick Reference Guide 5

BATTERY SAFETY

To install, charge and/or perform any other action on the battery, follow the

instructions in this manual.

WARNING

Do not discharge the battery using any device except for the scanner.

When the battery is used in devices other than the designated product, it

may damage the battery or reduce its life expectancy. If the device causes

an abnormal current to flow, it may cause the battery to become hot,

explode or ignite and cause serious injury.

Lithium-ion battery packs may get hot, explode or ignite and cause seri-

ous injury if exposed to abusive conditions. Be sure to follow the safety

warnings listed on this and the following page.

• Do not place the battery pack in fire or heat.

• Do not connect the positive terminal and negative terminal of the bat-

tery pack to each other with any metal object (such as wire).

• Do not carry or store the battery pack together with metal objects.

• Do not pierce the battery pack with nails, strike it with a hammer, step

on it or otherwise subject it to strong impacts or shocks.

• Do not solder directly onto the battery pack.

• Do not expose the battery pack to liquids, or allow the battery to get

wet.

• Do not apply voltages to the battery pack contacts.

WARNING

In the event the battery pack leaks and the fluid gets into your eye, do not

rub the eye. Rinse well with water and immediately seek medical care. If

left untreated, the battery fluid could cause damage to the eye.

CAUTION

Always charge the battery at 32° – 104°F (0° - 40°C) temperature range.

Use only the authorized power supplies, battery pack, chargers, and

docks supplied by your Datalogic reseller. The use of any other power sup-

plies can damage the device and void your warranty.

Do not disassemble or modify the battery. The battery contains safety and

protection devices, which, if damaged, may cause the battery to generate

heat, explode or ignite.

CAUTION

Do not place the battery in or near fire, on stoves or other high tempera-

ture locations.

Do not place the battery in direct sunlight, or use or store the battery

inside cars in hot weather. Doing so may cause the battery to generate

heat, explode or ignite. Using the battery in this manner may also result in

a loss of performance and a shortened life expectancy.

Charging the Batteries

6PowerScan™M8300

As with other battery types, Lithium-Ion (LI) batteries will lose capacity over time.

Capacity deterioration is noticeable after one year of service whether the battery is in

use or not. It is difficult to precisely predict the finite life of a LI battery, but cell

manufacturers rate them at 500 charge cycles. In other words, the batteries should be

expected to take 500 full discharge/charge cycles before needing replacement. This

number is higher if partial discharging/recharging is adhered to rather than full/deep

discharging,

The typical manufacturer advertised useful life of LI batteries is one-three years,

depending on usage and number of charges, etc., after which they should be

removed from service, especially in mission critical applications. Do not continue to

use a battery that is showing excessive loss of capacity, it should be properly recycled

/ disposed of and replaced. For most applications, batteries should be replaced after

one year of service to maintain customer satisfaction and minimize safety concerns.

Collect and recycle waste batteries separately from the device to comply with

European Directive 2006/66/EC, 2011/65/EU, 2002/96/EC and 2012/19/EU,and

subsequent modifications, US and China regulatory and other laws and regulations

about the environment.

CAUTION

Do not place the battery in microwave ovens, high-pressure containers or

on induction cookware.

Immediately discontinue use of the battery if, while using, charging or

storing the battery, the battery emits an unusual smell, feels hot, changes

color or shape, or appears abnormal in any other way.

Do not replace the battery pack when the device is turned on.

Do not remove or damage the battery pack’s label.

Do not use the battery pack if it is damaged in any part.

Battery pack usage by children should be supervised.

Altri manuali per PowerScan M8300

Indice

Altri manuali Datalogic Lettore di codici a barre

Datalogic

Datalogic QuickScan QS2500 Manuale utente

Datalogic

Datalogic PowerScan PD7100 Corded Manuale di installazione e funzionamento

Datalogic

Datalogic GRYPHON D Series Manuale utente

Datalogic

Datalogic QuickScan QS2500 Manuale di installazione e funzionamento

Datalogic

Datalogic PowerScan D8530 Manuale utente

Datalogic

Datalogic PowerScan PD8530 Manuale utente

Datalogic

Datalogic PowerScan Retail PM9501-RT Manuale utente

Datalogic

Datalogic POWERSCAN 7000 2D Imager Manuale di installazione e funzionamento

Datalogic

Datalogic Heron D130 Manuale utente

Datalogic

Datalogic Magellan 800i Manuale utente

Datalogic

Datalogic PowerScan D8330 Manuale utente

Datalogic

Datalogic DS6500 Series Manuale utente

Datalogic

Datalogic GRYPHON Manuale utente

Datalogic

Datalogic CBX800 Manuale utente

Datalogic

Datalogic Gryphon I GD441 Series Manuale utente

Datalogic

Datalogic FireScan D111 Series Manuale utente

Datalogic

Datalogic MAGELLAN 8300 Manuale di installazione e funzionamento

Datalogic

Datalogic POWERSCAN PBT7100 guide Manuale di installazione e funzionamento

Datalogic

Datalogic PowerScan PM9500 Manuale utente

Datalogic

Datalogic PowerScan PD9530 Manuale di installazione e funzionamento

Datalogic

Datalogic QuickScan I QD24 Series Manuale di installazione e funzionamento

Datalogic

Datalogic Magellan 1100i Manuale utente

Datalogic

Datalogic QuickScan i QD2100 Manuale di installazione e funzionamento

Datalogic

Datalogic Gryphon D130 Manuale utente

Manuali Lettore di codici a barre popolari di altre marche

POSMicro

POSMicro Datalogic PowerScan D7100 Manuale utente

Marson

Marson MT780 Guida rapida alla configurazione

NCR

NCR RealPOS Manuale utente

Motorola

Motorola SE3300 Guida rapida alla configurazione

Element

Element P130BT Manuale utente

Motorola

Motorola Symbol LS3008 Manuale di installazione e funzionamento

Meec tools

Meec tools OBD-II / VAG Manuale utente

SICK

SICK CLP 100 Manuale utente

Royal Tag SA

Royal Tag SA I-Read Manuale utente

Welch Allyn

Welch Allyn IMAGETEAM 3800 Manuale utente

Meteor

Meteor 8310 Manuale utente

Denso

Denso BHT-500B Manuale utente

Motorola

Motorola MP6000 Istruzioni di montaggio

Newland

Newland NLS-HR15-BT Manuale utente

ARTDEV

ARTDEV AS-1310 Manuale utente

Aopos

Aopos AS290 Manuale utente

ENS

ENS 367-5455 Manuale utente

Atid

Atid AT188N Plus Manuale utente
