24 Summer 2008

indoorrefrigerator

The new DCS by Fisher & Paykel built-in refrigerator delivers ample space

and convenience in a beautiful package. The fridge offers 29.52 cu. ft. of

space with multiple drawers to keep everything from fruits and vegetables to

raw meat and dairy. Plus, in-the-door ice and water.

ADDITIONAL FEATURES:

• 18.65 cu. ft. refrigerator space

• 10.87 cu. ft. freezer space

• Sealed glass shelves

• Water filter conveniently placed in top grill

• Dual compressors

Refrigerator

RF48SS

magalog summer 2008.2.qxd 4/29/08 5:19 PM Page 24

Summer 2008 25

48" Frame-to-Frame

Depth Including

Handles 26-7/8"

47"

Case Width

25-3/8" Case Depth

81-3/4"

at Rear

84" From

Floor to

Top Frame

Refrigerator Dimensions:

Cutout Dimensions:

Electrical

Area

84 1/2" max

83 1/2" min

Finished

Opening

74"

From Floor

to Bottom

of Electrical

24"

5" 5" 3 1/2"

Water Supply

3 1/2"

3"

7"

5"

47-1/2"

130°Door Swing 90°Door Swing

B

A

23-7/8"

Behind

Frame

C

D

D

Models A B C D

48" 13-7/16" 18-9/16" 28" 4"

*

*

*

*Four inch (4”) minimum clearance is required when door swing is

adjusted to 900.If the 900door stop position is used, drawer

access is maintained, but drawer removal is restricted.

24"

*84"

*3" to 4"

1-1/2"

Side Panels:

Side panels (not

supplied) must be used

whenever the sides of

the refrigerator will be

exposed.

*Depending on

installation height

magalog summer 2008.2.qxd 4/29/08 5:22 PM Page 25
