Dell 2135CN Manuale utente

Dell 2135cn

Service Manual

09 Oct 2009

Information in this document is subject to change without notice.

Reproduction in any manner whatsoever without the written permission of Dell Inc.is strictly forbidden.

Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc.

Other trademarks and trade names may be used in this document to refer to the entities claiming the marks and

names of their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other than

its own.

Version record

Refer to the portion indicated by change bar in each section.

Also refer to the reasons in table below.

Version Issu e date Note

1st February 01, 2008 1st issued

2nd

March 31, 2008

2nd version issued

Section 1, FIP

1. Rewrote contents and additional explanation

1.1 to 1.5 Rewrote contents

1.5.5 to 1.5.7 added

2.2 Rewrote contents

2.3 clerical error corrections etc.

3.1 additional flows and clerical error correction

etc.

Flows1 to 32/34 to 39/45 to 107/110 to 116

corrected

Flows 33/40 to 43/108/109 reference number

changed

Flows 44 reference number changed and

reference error code changed

Flow 117added

FIP-1.3 to 1.5/1.17 to 1.24/1.26 to 1.37/1.40

to47/1.50/1.53/1.57/1.58/1.60/1.64 to

1.69/1.90 to 91 corrected

FIP-1.38/1.39/1.62/1.63 reference number

changed

FIP-1.48/1.49/1.51/1.52/1.54 to 1.56 /1.59

added

4.4 additional flows etc.

FIP-1P1～1.P6/1.P8～1.P11 corrected

FIP-Copy Error added

Section 2, Operation of Diagnostic

3.1 illustration changed

3.7 menu corrected

4.1.4 menu corrected

4.2.4 menu corrected

Section 3, Removal and Replacement Procedures

(RRPs)

1. det ailed procedure correction

Removal 8/Removal 14/Removal 15/Removal

37/Removal 46/Removal 49/Removal

56/Removal 57/Removal 59/Replacement 2/

Replacement 4/Replacement 11/

Replacement 14/Removal 23/

Replacement 42/Replacement 45/

Replacement 46/Replacement 50/

Replacement 52/Replacement 60

Section 5 Parts List

PL10.2 illustration changed

Section 6 Principles of Operation

6. additional explanation

11. paragraph number changed（13.1.1/13.1.2）

Section 7, Wiring Diagrams and Signal

information

11. RXINCLK(+/-) signal explanation corrected

Section 8 Printer Specification

Specification change etc.

2.2/3.1/4.8/5.3/6.3/6.5/7.4/8.1/10.1～

10.4/11.1/ 11.2/12.1 corrected

3.3 illustration changed

11. paragraph number changed（4.9 to

4.11/12.2 to 12.4）

3rd

June 13, 2008

3rd version issued

Section 1, FIP

3.1 clerical error corrections etc.

Flows 7 / 8 / 10 to 17 / 20 / 21 / 25 / 36 / 37 / 48 /

49 / 51 / 55 / 56 / 62 / 64 / 70 / 72 / 73 / 77 / 83 to

87 / 93 / 98 / 99 / 106 / 110 / 112 corrected

Section 2, Operation of Diagnostic

4.2.4 illustration changed

Section 3, Removal and Replacement Procedures

(RRPs)

1. Addition of an ADF ASSY simple substance.

etc.

Removal Flows/Replacement Flows/Removal

2/Removal 11/Removal 35/Removal

47/Removal 59/Removal 60/Removal

61/Replacement 1/Replacement

2/Replacement 32/Replacement 47/Removal

49/Replacement 58/Replacement 61/

Section 5 Parts List

“Customer Replaceable Parts Illustration”

illustration changed

PL10.1 illustration & Parts List changed/

PL10.3 illustration & Parts List changed/

PL10.5 illustration changed/

PL10.6 illustration & Parts List changed/

PL10.9 illustration & Parts List changed/

PL10.10 illustration & Parts List changed

4th

December 22, 2008

4th version issued

Section 1, FIP

3.1 NOTE addition etc.

Flows 39 / 62 / 64 / 68 / 72 / 73 NOTE was added.

Flows 93 / 94 / 96 Name change.

FIP-1. P1 / P2 / P4 Name change.

4.1th

April 08, 2009

4.1th version issued

Section 1, FIP

Flows18-1and Flows118 are added.

(Change by error code (016-340).)

4.1.1th

April 15, 2009

4.1.1th version issued

Section 1, FIP

Flows119 are added.

4.2th

August 25, 2009

4.2th version issued

Section 1, FIP

Flows18/FIP1.18:

The download procedure of FW by the downlo ad

mode was added. (Only 016-317 )

Flows18-1:

The download procedure of FW by th e download

mode was added. (016-340 )

Flows20/FIP1.20:

The download procedure of FW by th e download

mode was added. (016-370 )

4.3th

October 09, 2009

4.3th version issued

Section 1, FIP

Flows23/FIP1.23: Memory Full 016-700

The content of flow was reviewed.

Version 1 2008.02.01

Cautions

Operation contents of this document may be subject to modification without notice.

Dell Inc. will not assume responsibility for accidental or incidental damages resulting from technical

or editorial errors or omissions in this manual, the issue of this manual, the execution of descriptions

in this manual, or the use of this manual.

This document is protected by copyright. Do not photocopy or duplicate any part of this document in

any form without written permission from Dell Inc.

Version 1 2008.02.01

1. About this manual

This manual is a standard service manual of 'HOO,QF containing informationUHTXLUHGIRUPDLQWHQDQFH

of this laser printer (standard specifications).

2. Marks giving caution

Maintenance operations requiring special cautions or additional information regarding descriptions in

this manual are presented as "Warning," "Caution," or "Note," depending on their nature.

If instructions are not observed, death or serious injury may result.

If instructions are not observed, injuries to workers or physical damage to assets

(including this laser printer) may result.

Essentials for procedures, steps, rules, and others.

Reference Incidental information to descriptions.

3. Related documents

-Instruction manuals (standard manuals)

Describe the operation and handling of this laser printer.

-Performance specifications

Describe in detail various specifications of this laser printer.

(In the event of a discrepancy between this manual and the performance specifications, the

performance specifications take precedence.)

-Spare parts list

Information on maintenance parts (spare parts) for this laser printer.

iii

Version 1 2008.02.01

4. Safety

To prevent possible accidents during maintenance operation, you should observe strictly the "Warning"

and "Caution" information in this manual.

Avoid dangerous operations and operations out of the scope of this manual.

Various processes not covered by this manual may be required in actual operations, and should be

performed carefully, always giving attention to safety.

4.1 Power source

Keep the power plug disconnected during the maintenance operation to prevent electric shock, burns

and other damages.

If the power supply should be kept connected to measure voltage or for other similar reasons, take

sufficient care to prevent electric shock, by following the procedures in this manual.

While the printer is on, never touch live parts if not required.

Power is supplied to the power switch / inlet even while the printer is off. Never

touch its live components.

Do not touch live parts unless otherwise specified.

Mnt00002KA

Version 1 2008.02.01

4.2 Driving units

When servicing gears or other driving units, be sure to turn off the power switch and unplug the power

cord. Drive them manually when required.

Do not do the print work removing the cover of the printer to confirm the operation

of driving part.

4.3 High-temperature units

When servicing high-temperature units (securing unit, etc.), be sure to turn them off to prevent burns,

injuries and other troubles. Remove the power plug and start service processes after they have cooled

down sufficiently.

Because high-temperature units are still hot after they complete an operation, wait

at least 40 minutes before starting maintenance service.

Version 1 2008.02.01

4.4 Battery

Lithium Battery is used in the following component.

- PWBA HYUI

There is a danger of a new battery exploding if it is incorrectly installed.

Replace the battery only with the same or equivalent type recommended by the

manufacturer.

Dispose the battery according to the manufacturer’s instruction.

Mnt00003KA

PWBA CONT AIO
