Dell Inspiron 3655 Manuale utente

Views

Specifications

NOTE: The images in this document may differ from your computer

depending on the configuration you ordered.

intellectual property laws. Dell™and the Dell logo are trademarks of Dell Inc. in the United States and/or other

jurisdictions. All other marks and names mentioned herein may be trademarks of their respective companies.

2015 ‑ 06 Rev. A00

Regulatory model: D20M | Type: D20M001

Computer model: Inspiron 3655

Inspiron 3655

1 Optical drive (optional)

Reads from and writes to

CDs and DVDs.

2 Power button

Press to turn on the computer if it

is turned off or in sleep state.

Press to put the computer in sleep

state if it is turned on.

Press and hold for 4 seconds to

force shut‑down the computer.

NOTE: You can customize

the power‑button behaviour

in Power Options. For

more information, see

Me and My Dell at

Dell.com/support.

3 Hard-drive activity light

Turns on when the computer

reads from or writes to the

harddrive.

4 Media-card reader

Reads from and writes to

media cards.

5 Headset port

Connect a headphone, a

microphone, or a headset

(headphone and microphone

combo).

6 USB 3.0 ports (2)

Connect peripherals such as

storage devices, printers, and so

on. Provides data transfer speeds

up to 5 Gbps.

Front

Views

Specifications

Front

Back

1 Line-in port

Connect devices such as external

audio players to record audio on

your computer.

2 Line-out port

Connect speakers.

3 Microphone port

Connect an external microphone.

4 VGA port

Connect an external display or a

projector.

5 HDMI port

Connect a TV or another HDMI‑in

enabled device. Provides video

and audio output.

6 USB 2.0 ports (4)

Connect peripherals such as

storage devices, printers, and so

on. Provides data transfer speeds

up to 480 Mbps.

7 Power-adapter port

Connect a power adapter to

provide power to your computer.

8 Expansion-card slot

Provides access to connectors on

PCI‑Express card.

9 Padlock rings

Attach a padlock to prevent

unauthorized access to the interior

of your computer.

10 Security-cable slot

Connect a security cable to

prevent unauthorized movement

of your computer.

11 Network port

Connect an Ethernet (RJ45) cable

from a router or a broadband

modem for network or internet

access.

The two lights next to the

connector indicate the

connectivity status and network

activity.

Views

Specifications

Front

Back

Specifications

Views

System

information Memory Ports and

connectors

Dimensions and

weight StorageCommunications Video Audio

Power adapter

Media‑card

reader

Computer

environment

Dimensions and weight

Height 352 mm (13.86 in)

Width 154 mm (6.06 in)

Depth 274 mm (10.79 in)

Weight (maximum) 6.05 kg (13.34 lb)

NOTE: The weight of your desktop varies depending on the configuration ordered

and manufacturing variability.

Specifications

Views

System

information Memory Ports and

connectors

Dimensions and

weight StorageCommunications Video Audio

Power adapter

Media‑card

reader

Computer

environment

System information

Computer model Inspiron 3655

Processor • AMD A4

• AMD A6

Chipset Integrated in processor

Specifications

Views

System

information Memory Ports and

connectors

Dimensions and

weight StorageCommunications Video Audio

Power adapter

Media‑card

reader

Computer

environment

Memory

Slot Two U‑DIMM slots

Type DDR3L

Speed 1600 MHz

Configurations supported 2 GB (Ubuntu only), 4 GB, 6 GB, 8 GB, 12 GB, and 16 GB

Specifications

Views

System

information Memory Ports and

connectors

Dimensions and

weight StorageCommunications Video Audio

Power adapter

Media‑card

reader

Computer

environment

Ports and connectors

External:

Network One RJ45 port

USB • Four USB 2.0 ports

• Two USB 3.0 ports

Audio/Video • One headset port

• One microphone port

• One line‑in port

• One line‑out port

• One VGA port

• One HDMI port

Internal:

M.2 card One M.2 card slot for Wi‑Fi and Bluetooth combo card

PCIe card One PCIe x1 card slot (half‑length, full height card)

Specifications

Views

System

information Memory Ports and

connectors

Dimensions and

weight StorageCommunications Video Audio

Power adapter

Media‑card

reader

Computer

environment

Communications

Ethernet 10/100/1000 Mbps Ethernet controller integrated on systemboard

Wireless • Wi‑Fi 802.11b/g/n

• Bluetooth 4.0

Specifications

Views

System

information Memory Ports and

connectors

Dimensions and

weight StorageCommunications Video Audio

Power adapter

Media‑card

reader

Computer

environment

Video

Controller:

Integrated • AMD Radeon R3 Graphics

• AMD Radeon R4 Graphics

Memory:

Integrated Shared system memory

Specifications

Views

System

information Memory Ports and

connectors

Dimensions and

weight StorageCommunications Video Audio

Power adapter

Media‑card

reader

Computer

environment

Audio

Controller Realtek High Definition Audio with Waves MaxxAudio Pro

Type Integrated 5.1 channel audio
