Dell Inspiron One 2020

Owner’s Manual

Computer model: Inspiron One 2020

Regulatory model: W06B

Regulatory type: W06B001

book.book Page 1 Monday, April 16, 2012 3:04 PM

Notes, Cautions, and Warnings

NOTE: A NOTE indicates important information that helps you make

better use of your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss

of data if instructions are not followed.

WARNING: A WARNING indicates a potential for property damage,

personal injury, or death.

____________________

Information in this document is subject to change without notice.

Reproduction of these materials in any manner whatsoever without the written permission

of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell™, the DELL logo, and Inspiron™ are trademarks of

Dell Inc.; Microsoft®, Windows®, and the Windows start button logo

are either

trademarks or registered trademarks of Microsoft corporation in the United States and/or

other countries; Intel®and Intel SpeedStep®are registered trademarks of Intel

Corporation in the U.S. and other countries; Bluetooth®is a registered trademark owned

by Bluetooth SIG, Inc. and is used by Dell under license.

Other trademarks and trade names may be used in this document to refer to either the

entities claiming the marks and names or their products. Dell Inc. disclaims any proprietary

interest in trademarks and trade names other than its own.

2012 - 04 Rev. A00

book.book Page 2 Monday, April 16, 2012 3:04 PM

Contents | 3

Contents

1 Technical Overview . . . . . . . . . . . . . . . . . . . . . . 7

Inside View of Your Computer . . . . . . . . . . . . . . . . 7

System Board Components. . . . . . . . . . . . . . . . . . 8

2 Before You Begin . . . . . . . . . . . . . . . . . . . . . . . 11

Turn Off Your Computer and

Connected Devices . . . . . . . . . . . . . . . . . . . . . . 11

Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . 11

Recommended Tools . . . . . . . . . . . . . . . . . . . . . 12

3 After Working Inside Your Computer . . . . . . . 13

4 Stand Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Removing the Stand Cover . . . . . . . . . . . . . . . . . 15

Replacing the Stand Cover . . . . . . . . . . . . . . . . . 16

5Stand. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Removing the Stand . . . . . . . . . . . . . . . . . . . . . . 17

Replacing the Stand . . . . . . . . . . . . . . . . . . . . . . 18

6 Back Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Removing the Back Cover. . . . . . . . . . . . . . . . . . 19

Replacing the Back Cover . . . . . . . . . . . . . . . . . . 20

7 Hard Drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Removing the Hard Drive . . . . . . . . . . . . . . . . . . 21

Replacing the Hard Drive . . . . . . . . . . . . . . . . . . 23

8 Optical Drive. . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Removing the Optical Drive. . . . . . . . . . . . . . . . . 25

Replacing the Optical Drive . . . . . . . . . . . . . . . . . 26

9 B-CAS Card (Japan Only). . . . . . . . . . . . . . . . . 27

Removing the B-CAS Card . . . . . . . . . . . . . . . . . 27

Replacing the B-CAS Card. . . . . . . . . . . . . . . . . . 28

book.book Page 3 Monday, April 16, 2012 3:04 PM

4| Contents

10 Converter Board. . . . . . . . . . . . . . . . . . . . . . . . 29

Removing the Converter Board . . . . . . . . . . . . . . 29

Replacing the Converter Board . . . . . . . . . . . . . . 30

11 Memory Module(s) . . . . . . . . . . . . . . . . . . . . . . 31

Removing the Memory Module(s). . . . . . . . . . . . . 31

Replacing the Memory Module(s) . . . . . . . . . . . . . 33

12 System-Board Shield . . . . . . . . . . . . . . . . . . . . 35

Removing the System-Board Shield . . . . . . . . . . . 35

Replacing the System-Board Shield . . . . . . . . . . . 36

13 Antenna-In Connector . . . . . . . . . . . . . . . . . . 37

Removing the Antenna-In Connector . . . . . . . . . . 37

Replacing the Antenna-In Connector . . . . . . . . . . 38

14 Antenna Modules . . . . . . . . . . . . . . . . . . . . . . . 39

Removing the Antenna Modules. . . . . . . . . . . . . . 39

Replacing the Antenna Modules . . . . . . . . . . . . . . 40

15 TV-Tuner Card (Optional) . . . . . . . . . . . . . . . . 41

Removing the TV-Tuner Card. . . . . . . . . . . . . . . . 41

Replacing the TV-Tuner Card . . . . . . . . . . . . . . . . 43

16 Wireless Mini-Card (Optional). . . . . . . . . . . . . 45

Removing the Wireless Mini-Card. . . . . . . . . . . . . 45

Replacing the Wireless Mini-Card . . . . . . . . . . . . . 47

17 Coin-Cell Battery . . . . . . . . . . . . . . . . . . . . . . . 49

Removing the Coin-Cell Battery. . . . . . . . . . . . . . 49

Replacing the Coin-Cell Battery . . . . . . . . . . . . . . 50

18 Speakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Removing the Speakers . . . . . . . . . . . . . . . . . . . 51

Replacing the Speakers. . . . . . . . . . . . . . . . . . . . 53

19 Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Removing the Fan . . . . . . . . . . . . . . . . . . . . . . . 55

Replacing the Fan . . . . . . . . . . . . . . . . . . . . . . . 56

book.book Page 4 Monday, April 16, 2012 3:04 PM

Contents | 5

20 Power-Button Assembly . . . . . . . . . . . . . . . . . 57

Removing the Power-Button Assembly . . . . . . . . . 57

Replacing the Power-Button Assembly . . . . . . . . . 59

21 Processor Heat-Sink . . . . . . . . . . . . . . . . . . . . 61

Removing the Processor Heat-Sink. . . . . . . . . . . . 61

Replacing the Processor Heat-Sink . . . . . . . . . . . . 63

22 Processor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Removing the Processor . . . . . . . . . . . . . . . . . . . 65

Replacing the Processor . . . . . . . . . . . . . . . . . . . 67

23 System Board . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Removing the System Board . . . . . . . . . . . . . . . . 69

Replacing the System Board . . . . . . . . . . . . . . . . 71

Entering the Service Tag in the BIOS . . . . . . . . . . . 71

24 Display Panel . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Removing the Display Panel . . . . . . . . . . . . . . . . 73

Replacing the Display Panel. . . . . . . . . . . . . . . . . 77

25 Infrared (IR) Receiver . . . . . . . . . . . . . . . . . . . . 79

Removing the Infrared Receiver . . . . . . . . . . . . . . 79

Replacing the Infrared Receiver . . . . . . . . . . . . . . 82

26 Middle Frame . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Removing the Middle Frame . . . . . . . . . . . . . . . . 83

Replacing the Middle Frame . . . . . . . . . . . . . . . . 85

27 Camera Module . . . . . . . . . . . . . . . . . . . . . . . . 87

Removing the Camera Module. . . . . . . . . . . . . . . 87

Replacing the Camera Module . . . . . . . . . . . . . . . 89

28 Display Bezel . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Removing the Display Bezel . . . . . . . . . . . . . . . . 91

Replacing the Display Bezel. . . . . . . . . . . . . . . . . 93

book.book Page 5 Monday, April 16, 2012 3:04 PM

6| Contents

29 System Setup . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Clearing Forgotten Passwords . . . . . . . . . . . . . . 106

Clearing CMOS Settings . . . . . . . . . . . . . . . . . . 107

30 Flashing the BIOS . . . . . . . . . . . . . . . . . . . . . . 109

book.book Page 6 Monday, April 16, 2012 3:04 PM

Technical Overview | 7

1Technical Overview

WARNING:

Before working inside your computer, read the safety information that

shipped with your computer and follow the steps in "Before You Begin" on page 11.

For additional safety best practices information, see the Regulatory Compliance

Homepage at dell.com/regulatory_compliance.

Inside View of Your Computer

1 power-button board 2 chassis

3 optical-drive assembly 4 converter board

5 fan 6 processor heat-sink

7 memory module(s) 8 coin-cell battery

9 system board 10 TV-tuner card (optional)

11 wireless Mini-Card 12 B-CAS card (Japan only)

13 hard-drive assembly 14 speakers (2)

book.book Page 7 Monday, April 16, 2012 3:04 PM

8| Technical Overview

System Board Components

10 11 12 13

book.book Page 8 Monday, April 16, 2012 3:04 PM

Technical Overview | 9

1 processor socket 2 fan cable connector (FANC1)

3 camera cable connector (WEBCAM) 4 converter-board cable connector

(CONVERTER)

5 hard-drive and optical-drive

power cable connector (SATAP1)

6 optical-drive cable connector

(SATA_ODD)

7 hard-drive cable connector

(SATA_HDD)

8 power-button and hard-drive activity

light cable connector (PWRCN1)

9 IR-cable connector (IR_IN) 10 display-cable connector

11 wireless Mini-Card connector

(MINICARD WIFI)

12 TV-tuner card connector

(MINICARD TV)

13 speakers cable connector (SPEAKER) 14 password jumper (PWCLR1)

15 battery socket (BT1) 16 CMOS jumper (CMOCL1)

17 memory-module connector

(DIMMB1)

18 memory-module connector

(DIMMA1)

book.book Page 9 Monday, April 16, 2012 3:04 PM

10 | Technical Overview

book.book Page 10 Monday, April 16, 2012 3:04 PM
