Dell Vostro V130

Specifications

Technical Specifications

NOTE: Offerings may vary by region. The following specifications are only those

required by law to ship with your computer. For more information regarding the

configuration of your computer, click Start → Help and Support and select the

option to view information about your computer.

System Information

Chipset Mobile Intel 5 Express Chipset HM57

DRAM bus width 64-bit

Flash EPROM SPI 32 Mbits

PCIe Gen1 bus 100 MHz

Processor

Types Intel Core i3-380UM

Intel Core i5-470UM

Intel Celeron Dual-Core U3400

Memory

Memory connector one SODIMM slot

Memory capacity 1 GB, 2 GB, or 4 GB

Memory type DDR3 SDRAM (800 MHz)

Minimum memory 1 GB (entry bundle with Ubuntu only)

Maximum memory 4 GB

Audio

Type two-channel high definition audio

Controller IDT 92HD79

Stereo Conversion 24-bit (analog-to-digital and digital-to-analog)

Interface:

Internal high definition audio

Audio

External microphone-in connector, stereo

headphones/external speakers connector

Speakers 1.5 W mono

Internal speaker amplifier 1.5 W mono

Volume controls keyboard function keys, program menus

Video

Type integrated on system board

Controller Intel Graphics Media Accelerator HD (Intel

GMA HD)

Output 15-pin video connector

19-pin HDMI connector

Communications

Network adapter 10/100/1000 Mbps Ethernet LAN

Wireless internal wireless local area network (WLAN),

wireless wide area network (WWAN), and

Bluetooth wireless support

Ports and Connectors

Audio microphone connector, stereo headphone/

speakers connector

Video 15-pin VGA connector

Network adapter RJ-45 connector

USB two 4-pin USB 2.0-compliant connectors, one

eSATA/USB 2.0-compliant connector

Memory card reader 5-in-1 memory card reader

Display

Type white Light Emitting Diode (WLED) display

Display

Size 13.3 inch high definition (HD)

Active area (X/Y) 293.4 mm x 165.0 mm

Dimensions:

Height 188.80 mm (7.43 inches)

Width 314.10 mm (12.37 inches)

Diagonal 337.80 mm (13.30 inches)

Maximum resolution 1366 x 768 at 262 K colors

Maximum Brightness 200 nits

Operating angle 0° (closed) to 135°

Refresh rate 60 Hz

Minimum Viewing angles:

Horizontal 40/40

Vertical 15/30

Pixel pitch 0.2148 mm

Keyboard

Number of keys United States: 86 keys, United Kingdom: 87

keys, Brazil: 87 keys, and Japan: 90 keys

Layout QWERTY/AZERTY/Kanji

Touchpad

Active Area

X-axis 80.00 mm

Y-axis 40.7 mm

Battery

Type 6-cell "smart" Lithium ion (30 WHr)

Dimensions:

Battery

Depth 155.20 mm (6.11 inches)

Height 5.35 mm (0.21 inch)

Width 177.60 mm (6.99 inches)

Weight 265 +/– 6 grams (0.58 +/– 0.01 lb)

Voltage 11.10 VDC

Temperature range:

Operating 0 °C to 35 °C (32 °F to 95 °F)

Non-Operating –40 °C to 65 °C (–40 °F to 149 °F)

Coin-cell battery 3 V CR2032 lithium coin cell

AC Adapter

Type 65 W

Input voltage 100 VAC to 240 VAC

Input current (maximum) 1.5 A/ 1.6 A/ 1.7 A

Input frequency 50 Hz to 60 Hz

Output power 65 W

Output current 3.34 A (continuous)

Rated output voltage 19.5 +/– 1.0 VDC

Temperature range:

Operating 0 °C to 40 °C (32 °F to 104 °F)

Non-Operating –40 °C to 70 °C (–40 °F to 158 °F)

Physical

Height 16.50 mm to 19.70 mm (0.65 inch to 0.78 inch)

Width 330 mm (12.99 inches)

Depth 230 mm (9.05 inches)

Weight <1.6 kg (<3.53 lb)

Physical

NOTE: The weight may vary depending on

the configuration of your computer.

Environmental

Temperature:

Operating 0 °C to 35 °C (32 °F to 95 °F)

Storage –40 °C to 65 °C (–40 °F to 149 °F)

Relative humidity (maximum):

Operating 10 % to 90 % (noncondensing)

Storage 5 % to 95 % (noncondensing)

Altitude (maximum):

Operating –15.2 m to 3048 m (–50 ft to 10,000 ft)

Non-Operating –15.2 m to 10,668 m (–50 ft to 35,000 ft)

Airborne contaminant level G2 or lower as defined by ISA-S71.04–1985
