Dell E2020H Manuale utente

Dell E1920H/E2020H/E2220H/

E2420H/E2420HS/E2720H/

E2720HS

Dell Display Manager

User’s Guide

Monitor model: E1920H/E2020H/E2220H/E2420H/E2420HS/E2720H/E2720HS

Regulatory model:

E1920Hf, E2020Hb,E2220Hf, E2220Ho, E2420Hf, E2420Ho, E2420HSf, E2720Hb, E2720HSb

2 │

NOTE: A NOTE indicates important information that helps you make

better use of your computer.

trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.

2020 - 01

Rev. A00

Contents │ 3

Overview ................................................................... 4

Using the Quick Settings Dialog ..................................5

Setting Basic Display Functions ...................................6

Assigning Preset Modes to Applications .......................7

Organizing Windows with Easy Arrange ........................8

Managing Multiple Video Inputs...................................10

Restoring Application Positions ..................................12

Applying Energy Conservation Features ......................14

Troubleshooting.........................................................15

Contents

4 │ Overview

Overview

Dell Display Manager is a Microsoft Windows application used to manage a monitor

or a group of monitors. It enables manual adjustment of the displayed image,

assignment of automatic settings, energy management, window organization, image

rotation, and other features on selected Dell monitors. After installation, Dell Display

Manager runs each time the system starts and places its icon in the notication

tray. Information about monitors connected to the system is available when

hovering over the notication tray icon.

NOTE: Dell Display Manager uses DDC/CI channel to communicate with

your monitor. Ensure that DDC/CI is enabled in the menu as below.

E1920H/E2020H/E2220H/E2420H/E2720H

E2420HS/E2720HS

Dell XX Monitor

Brightness / Contrast

Auto Adjust

Input Source

Color

Display Info

DDC/CI

LCD Conditioning

Service Tag

Reset Others

Factory Reset

Display

Personalize

Others

O

Dell 2X Monitor

Brightness / Contrast

Auto Adjust

Input Source

Color

Display

Audio

Personalize

Others

Display Info

DDC/CI

LCD Conditioning

Service Tag

Reset Others

Factory Reset

O

Using the Quick Settings Dialog │ 5

Using the Quick Settings Dialog

Click the Dell Display Manager’s notication tray icon to open the Quick Settings

dialog box. When more than one supported Dell model is connected to the

computer, a specic target monitor can be selected using the menu. The Quick

Settings dialog box enables convenient adjustment of the monitor’s brightness

and contrast levels. You can select Manual Mode or Auto Mode, and the screen

resolution can be changed.

The Quick Settings dialog box also provides access to Dell Display Manager's

advanced user interface that is used to adjust basic functions, congure auto mode

and access other features.

E1920H/E2020H/E2220H/E2420H/E2420HS/E2720H/E2720HS

6 │ Setting Basic Display Functions

Setting Basic Display Functions

You can select Manual Mode that enables you to manually select a preset mode

or select Auto Mode that applies a preset mode based on the active application.

An on-screen message displays the current preset mode whenever it changes. The

selected monitor's Brightness and Contrast can also be directly adjusted from the

Basic tab.

E1920H/E2020H/E2220H/E2420H/E2420HS/E2720H/E2720HS

NOTE: When multiple Dell monitors are connected, select “Enable display

matrix control” to apply brightness, contrast and color presets controls to

all monitors.

Assigning Preset Modes to Applications │ 7

E1920H/E2020H/E2220H/E2420H/E2420HS/E2720H/E2720HS

NOTE: Preset Mode assignments for batch les scripts, loaders, and non-

executable les such as zip archives or packed les, are not supported.

Assigning Preset Modes to Applications

The Auto Mode tab allows you to associate a specic Preset Mode with a specic

application, and apply it automatically. When Auto Mode is enabled, Dell Display

Manager automatically switches to the corresponding Preset Mode whenever

the associated application is activated. The Preset Mode assigned to a particular

application may be the same on each connected monitor, or it can vary from one

monitor to another.

Dell Display Manager is pre-congured for many popular applications. To add a new

application to the assignment list, simply drag the application from the desktop,

Windows Start Menu or elsewhere, and drop it onto the current list.

You can also congure the Game preset mode to be used whenever a Direct3D

application runs in full-screen mode. To prevent an application from using mode,

assign a dierent preset mode to it.

8 │ Organizing Windows with Easy Arrange

Organizing Windows with Easy Arrange

Easy Arrange helps you to eectively organize your application windows on the

desktop. You rst choose a pre-dened layout pattern which suits your work, then

you just need to drag the application windows into the dened zones. Press “>”

or use Page Up/Page Down key to nd more layouts. To create a custom layout,

arrange the open windows and then click Save.

For Windows 10, you can apply dierent window layouts for each of the virtual

desktops.

If you often use Windows snap feature, select the “Hold down the SHIFT key to

enable zone positioning”. This gives Windows snap priority over Easy Arrange.

You will then need to press the Shift key to use Easy Arrange positioning.

E1920H/E2020H/E2220H/E2420H/E2420HS/E2720H/E2720HS

Organizing Windows with Easy Arrange │ 9

If you are using multiple monitors in an array or matrix, Easy Arrange layout can

be applied across to all the monitors as one desktop. Select “Span multiple

monitors” to enable this feature. You need to align your monitors properly to use it

eectively.

E1920H/E2020H/E2220H/E2420H/E2420HS/E2720H/E2720HS

10 │ Managing Multiple Video Inputs

Managing Multiple Video Inputs

The Input Manager tab provides convenient ways for you to manage multiple

video inputs connected to your Dell monitor. It makes it easy to switch

between inputs while you work with multiple computers.

All video input ports available to your monitor are listed. You can give each input a

name as you like. Save your changes after editing.

You can dene a shortcut key to quickly switch to your favorite input and another

shortcut key to quickly switch between two inputs if you often work between them.

E1920H/E2020H/E2220H/E2420H/E2720H

E2420HS/E2720HS
