Take out the whole packed monitor and then remove the EPE bags which packed monitor and stand base, and then put the monitor face down on the table with protective cushion.S3 Open the pizza carton with a proper tool, then put down the pizza carton, and open the carton. 1. Disassembly Procedures:S1 Lift up the stand , then use a Philips-head screwdriver to remove 2pcs screws for unlocking the whole unit including stand and base, then remove the stand and base. Use a Philips-head screwdriver to remove 2pcs screws for release the hinge cover.(No.1~2 screw size=M3x11, Torque=7.5±0.5kgfxcm; No.3~4 screw size=M2x0.4x3.2, Torque=2~3kgfxcm)S4 Take out the QSG from the catron, and then take out the Paper-Top with other accessories including user’s manual, HDMI cable, power cable, power adapter and other packing materials from the carton.(Note: It depends on whether users returning the accessories)S2 Use a proper tool insert the gap of the rear cover top side (marked 1) as the following picture to release the rear cover, then wedge your fingers between the rear cover and the panel to release the rear cover, then use one hand to press the panel module, the other hand to pull up carefully the rear cover in order of arrow preference 1~3 for unlocking mechanisms of rear cover, and then remove the rear cover carefully.S51

DELL S2719DM12QSG132343

S72Tear off 2pcs double-faced tapes on the left and right side of the middle bezel, then tear off 2pcs aluminum foil to release the panel lamp cable and LVDS connector. S6DELL S2719DMUse a Philips-head screwdriver to remove 2pcs screws for unlocking the front bezel with the panel module, and then use a proper tool to disconnect the panel lamp cable, LVDS cable and function key board from the connector of the main board.(No.1~2 screw size=M1.6x2.2, Torque=0.5±0.1kgfxcm)2Use a Philips-head screwdriver to remove 4pcs screws for unlocking bracket, move away the bracket and then remove 1pcs screw for unlocking the front bezel from the panel module, and then remove the front bezel carefully.(No.1~5 screw size=M3x4, Torque=3±0.5kgfxcm)Use a Philips-head screwdriver to remove 3pcs screws for unlocking bracket with panel module.(No.1~3 screw size=M3x2.8, Torque=3±0.5kgfxcm)132S8S9Put the front bezel with function key board into a fixture, tear off the mylar, then use a Philips-head screwdriver to remove 3pcs screws for unlocking the function key board with front bezel.(No.1~3 screw size=M0.2x2.4, Torque=1±0.2kgfxcm)S10321152341

Turn over the bracket chassis module. Use a Philips-head screwdriver to remove 5pcs screws for unlocking the main board. (No.1~3 screw size=M3x7.5, Torque=7.5±0.5kgfxcm)S13DELL S2719DMPut the bracket chassis on a protector cushion, then use a Philips-head screwdriver to remove 4pcs screws for unlocking the hinge.(No.1~4 screw size=M3x5.3, Torque=7.5±0.5kgfxcm)Disconnect the panel lamp cable from the connector os the panel module, then remove bracket and put it on a protect cushion for later disassembling. Unplug the LVDS cable and panel lamp cable from the connectors of panel module. Tear off the mylar tape which is sticked on the specific position of the back of panel, and then use a Philips-head screwdriver to remove 3pcs screws for unlocking the panel module.(No.1~3 screw size=M3x2.7, Torque=3~4kgfxcm)S11312S121342Remove the main board from the disconnect all of the cables.bracket chassis module by taking out the panel lamp cable from the hole of the bracket carefully, and then S1424135

The following substances, preparations, or components should be disposed of or

recovered separately from other WEEE in compliance with Article 4 of EU Council

Directive 75/442/EEC.

Capacitors / condensers (containing

PCB/PCT)

No used

Mercury containing components

No used

Batteries

No used

Printed circuit boards (with a surface

greater than 10 square cm)

Product has printed circuit boards (with a

surface greater than 10 square cm)

Component contain toner, ink and

liquids

No used

Plastic containing BFR

No used

Component and waste contain

asbestos

No used

CRT

No used

Component contain CFC, HCFC, HFC

and HC

No used

Gas discharge lamps

No used

LCD display > 100 cm2

Product has an LCD greater than 100 cm2

External electric cable

Product has external cables

Component contain refractory

ceramic fibers

No used

Component contain radio-active

substances

No used

Electrolyte capacitors (height

> 25mm, diameter > 25mm)

Product has electrolyte capacitors (height >

25mm, diameter > 25mm)

3. Tools Required

List the type and size of the tools that would typically can be used to disassemble the

product to a point where components and materials requiring selective treatment

can be removed.

Tool Description:

- Screwdriver (Phillip head) #1

- Screwdriver (Phillip head) #2

- Penknife

- Soldering iron and absorber

2. Product material information

4DELL S2719DM
