BASIC

User’s Guide

Dell B1160

Dell B1160w

BASIC

User’s Guide

This guide provides information concerning installation, basic operation and

troubleshooting on windows.

ADVANCED

This guide provides information about installation, advanced configuration, operation and

troubleshooting on various OS environments.

Some features may not be available depending on models or countries.

BASIC

1. Introduction

Key benefits 4

Features by models 6

Useful to know 7

About this user’s guide 8

Safety information 9

Machine overview 14

Control panel overview 16

Turning on the machine 17

Installing the driver locally 18

Reinstalling the driver 20

2. Learning the Basic Usage

Printing a test page 22

Media and tray 23

Basic printing 31

3. Maintenance

Ordering supplies and accessories 35

Available supplies 36

Storing the toner cartridge 37

Redistributing toner 39

Replacing the toner cartridge 40

Cleaning the machine 42

Tips for moving & storing your machine 46

4. Troubleshooting

Tips for avoiding paper jams 48

Out-of-paper error resolution 49

Clearing paper jams 50

Understanding the status LED 53

5. Appendix

Specifications 56

Dell technical support policy 64

Contacting Dell 65

Warranty and return policy 66

1. Introduction

This chapter provides information you need to know before using the machine.

•Keybenefits 4

• Features by models 6

• Useful to know 7

• About this user’s guide 8

• Safety information 9

• Machine overview 14

• Control panel overview 16

• Turning on the machine 17

• Installing the driver locally 18

• Reinstalling the driver 20

Key benefits

Environmentally friendly

• To save paper, you can print multiple pages on a single sheet of paper (see

"Using advanced print features" on page 110).

• To save paper, you can print on both sides of the paper (manual double-

sided printing) (see "Using advanced print features" on page 110).

• To save electricity, this machine automatically conserves electricity by

substantially reducing power consumption when not in use.

Print with excellent quality and speed

• You can print with a resolution of up to 1,200 x 1,200 dpi effective output.

• Fast, on-demand printing.

- For single-side printing, 20 ppm (A4) or 21 ppm (Letter).

Convenience

• Dell Printer Manager and Dell Printer Status are a program that monitors

and informs you of the machine’s status and allows you to customize the

machine’s settings (see "Using Dell Printer Manager" on page 125).

• You can access Dell Support at www.dell.com or support.dell.com. Select

your region on the WELCOME TO DELL SUPPORT page, and fill in the

requested details to access help tools and information.

Wide range of functionality and application support

• Supports various paper sizes (see "Print media specifications" on page 58).

• Print watermark: You can customize your documents with words, such as

“Confidential” (see "Using advanced print features" on page 110).

• Print posters: The text and pictures of each page of your document are

magnified and printed across the multiple sheets of paper and can then be

taped together to form a poster (see "Using advanced print features" on

page 110).

Key benefits

• You can print in various operating systems (see "System requirements" on

page 61).

• Your machine is equipped with a USB interface.

Supports various wireless network setting method

• Using the WPS (Wi-Fi Protected Setup™) button

- You can easily connect to a wireless network using the WPS button on

the machine and the access point (a wireless router).

•UsingtheUSBcable

- You can connect and set various wireless network settings using a USB

cable.

• Using the Wi-Fi Direct

- You can conveniently print from your mobile device using the Wi-Fi or

Wi-Fi Direct feature.

See "Introducing wireless set up methods" on page 84.

Features by models

Some features and optional goods may not be available depending on

model or country.

Operating System

(●: Included, Blank: Not available)

Software

(●: Included, Blank: Not available)

Variety feature

(●: Included, Blank: Not available)

Operating System B1160 B1160w

Windows ● ●

Macintosh ● ●

Linux ● ●

Software B1160 B1160w

SPL printer driver ● ●

XPS printer driver ● ●

Dell Printer Manager ● ●

Embedded Web Service ●

Dell Supplies Ordering Utility ● ●

Dell Printer Status ● ●

Firmware Update Utility ● ●

Features B1160 B1160w

Hi-Speed USB 2.0 ● ●

Network Interface 802.11b/g/n

wireless LAN

●

IPv6 ●

Wi-Fi Protected Setup™ (WPS) ●

Manual duplex (2-sided) printing ● ●

Useful to know

Where can I download the machine’s driver?

• Visit www.support.dell.com to download the latest

machine’s driver, and install it on your system.

Where can I purchase accessories or supplies?

• Inquire at a Dell distributor or your retailer.

• Visit www.support.dell.com. Select your country/region to

view product service information.

The status LED flashes or remains constantly on.

• Turn the product off and on again.

• Check the meanings of LED indications in this manual and

troubleshoot accordingly (see "Understanding the status LED"

on page 53).

A paper jam has occurred.

• Open and close the top cover (see "Front view" on page 15).

• Check the instructions on removing jammed paper in this

manual and troubleshoot accordingly (see "Clearing paper

jams" on page 50).

Printouts are blurry.

• The toner level might be low or uneven. Shake the toner

cartridge.

• Try a different print resolution setting.

• Replace the toner cartridge.

The machine does not print.

• Open the print queue list and remove the document from the

list (see "Canceling a print job" on page 32).

• Remove the driver and install it again (see "Installing the driver

locally" on page 18).

• Select your machine as your default machine in your Windows.

1. Introduction

About this user’s guide

This user's guide provides information for your basic understanding of the

machine as well as detailed steps to explain machine usage.

• Read the safety information before using the machine.

• If you have a problem using the machine, refer to the troubleshooting

chapter.

• Terms used in this user’s guide are explained in the glossary chapter.

• All illustrations in this user’s guide may differ from your machine depending

on its options or model you purchased.

• The screenshots in this user's guide may differ from your machine

depending on the machine’s firmware/driver version.

• The procedures in this user’s guide are mainly based on Windows 7.

Conventions

Some terms in this guide are used interchangeably, as below:

• Document is synonymous with original.

• Paper is synonymous with media, or print media.

• Machine refers to printer or MFP.

General icons

Icon Text Description

Caution Gives users information to protect the machine from

possible mechanical damage or malfunction.

Note Provides additional information or detailed

specification of the machine function and feature.

1. Introduction

Safety information

These warnings and precautions are included to prevent injury to you and

others, and to prevent any potial damage to your machine. Be sure to read and

understand all of these instructions before using the machine. After reading this

section, keep it in a safe place for future reference.

Important safety symbols

Explanation of all icons and signs used in this chapter

Operating environment

Warning

Warning Hazards or unsafe practices that may result in severe

personal injury or death.

Caution Hazards or unsafe practices that may result in minor

personal injury or property damage.

Do not attempt.

Do not use if the power cord is damaged or if the electrical outlet is

not grounded.

This could result in electric shock or fire.

Do not place anything on top of the machine (water, small metal or

heavy objects, candles, lit cigarettes, etc.).

This could result in electric shock or fire.

• If the machine gets overheated, it releases smoke, makes

strange noises, or generates an odd odor, immediately turn off

the power switch and unplug the machine.

• The user should be able to access the power outlet in case of

emergencies that might require the user to pull the plug out.

This could result in electric shock or fire.

Do not bend, or place heavy objects on the power cord.

Stepping on or allowing the power cord to be crushed by a heavy

object could result in electric shock or fire.

Do not remove the plug by pulling on the cord; do not handle the

plug with wet hands.

This could result in electric shock or fire.

Safety information

1. Introduction

Caution

Operating method

Caution

During an electrical storm or for a period of non-operation,

remove the power plug from the electrical outlet.

This could result in electric shock or fire.

Be careful, the paper output area is hot.

Burns could occur.

If the machine has been dropped, or if the cabinet appears

damaged, unplug the machine from all interface connections and

request assistance from qualified service personnel.

Otherwise, this could result in electric shock or fire.

If the machine does not operate properly after these instructions

have been followed, unplug the machine from all interface

connections and request assistance from qualified service

personnel.

Otherwise, this could result in electric shock or fire.

If the plug does not easily enter the electrical outlet, do not

attempt to force it in.

Call an electrician to change the electrical outlet, or this could

result in electric shock.

Do not allow pets to chew on the AC power, telephone or PC

interface cords.

This could result in electric shock or fire and/or injury to your pet.

Do not forcefully pull the paper out during printing.

It can cause damage to the machine.

Be careful not to put your hand between the machine and paper

tray.

You may get injured.

This machine's power reception device is the power cord.

To switch off the power supply, remove the power cord from the

electrical outlet.

Be care when replacing paper or removing jammed paper.

New paper has sharp edges and can cause painful cuts.

When printing large quantities, the bottom part of the paper

output area may get hot. Do not allow children to touch.

Burns can occur.

When removing jammed paper, do not use tweezers or sharp metal

objects.

It can damage the machine.

Altri manuali per B1160

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Dell Stampante

Dell

Dell B5460dn Mono Laser Printer Manuale utente

Dell

Dell PZ310 Manuale utente

Dell

Dell S3840cdn Manuale utente

Dell

Dell INSPIRON Inspiron 1100 Manuale utente

Dell

Dell 7330dn - Laser Printer B/W Manuale di istruzioni

Dell

Dell 1110 - Laser Printer B/W Manuale utente

Dell

Dell V505 - All-in-One Printer Color Inkjet Manuale utente

Dell

Dell 5110cn - Color Laser Printer Manuale utente

Dell

Dell C5765DN Manuale utente

Dell

Dell 1133 Mono Laser Specifiche tecniche

Dell

Dell 3130cn - Color Laser Printer Manuale utente

Dell

Dell B5465dnf Mono Laser Printer MFP Manuale utente

Dell

Dell 3000cn Color Laser Printer Manuale utente

Dell

Dell 725 Personal Inkjet Printer Manuale utente

Dell

Dell C2660dn Manuale utente

Dell

Dell P1500 Manuale utente

Dell

Dell 1710n - Laser Printer B/W Istruzioni per il montaggio

Dell

Dell 7130 Color Manuale operativo

Dell

Dell Inspiron 1110 Manuale utente

Dell

Dell 5130CDN Manuale utente

Dell

Dell B5460dn Mono Laser Printer Manuale utente

Dell

Dell 5230 Manuale utente

Dell

Dell 5330 Manuale utente

Dell

Dell Vostro 1710 Manuale utente

Manuali Stampante popolari di altre marche

Lexmark

Lexmark 1400 Series Manuale

Canon

Canon i70 Series Manuale utente

Evolis

Evolis Elypso Manuale utente

Kyocera

Kyocera FS-9530DN Manuale utente

Canon

Canon LASER SHOT LBP-1210 Manuale utente

Samsung

Samsung BIXOLON SRP-350plusF Manuale utente

Canon

Canon PIXMA PRO-1 Series Manuale utente

Canon

Canon PIXMA G3560 Guida all'installazione

Tektronix

Tektronix Phaser 840 Manuale utente

Epson

Epson ET-7750 Istruzioni operative

Canon

Canon CLBR 460ps Manuale utente

Eltron

Eltron P210 Guide Manuale utente

Ricoh

Ricoh MD-P1 Manuale utente

Epson

Epson SC-F7100 series Manuale utente

Epson

Epson Stylus C40UX Manuale utente

Canon

Canon imagePASS-A2 Manuale utente

Canon

Canon S820D Manuale utente

IRA3D

IRA3D POETRY4 Manuale utente
