Dell M5200 Manuale utente

Dell™ Workgroup Laser Printer M5200 User's

Guide

Click the links to the left for information on the features, options, and operation of your printer. For

information on other documentation included with your printer, see Finding information.

Printer

Multipurpose feeder

Standard 500-sheet tray

Optional envelope feeder

Optional duplex unit

Optional 250-sheet drawer with tray

Optional 500-sheet drawer with tray

To order replacement toner cartridges or supplies from Dell:

Double-click the icon on your desktop.1.

Visit Dell's website, or order Dell printer supplies by phone.2.

www.dell.com/supplies

For best service, have your Dell printer Service Tag available.

For help locating your Service Tag number, see Express Service Code and Service Tag number.

Notes, Notices, and Cautions

NOTE: A NOTE indicates important information that helps you make better use of your printer.

NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you how

to avoid the problem.

CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.

____________________

Information in this document is subject to change without notice.

Reproduction in any manner whatsoever without the written permission of Dell Computer Corporation is

strictly forbidden.

Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Computer Corporation;

Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation; ENERGY STAR is a

registered trademark of the U.S. Environmental Protection Agency. As an ENERGY STAR Partner, Dell

Computer Corporation has determined that this product meets the ENERGY STAR guidelines for energy

efficiency.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the

marks and names or their products. Dell Computer Corporation disclaims any proprietary interest in

trademarks and trade names other than its own.

UNITED STATES GOVERNMENT RESTRICTED RIGHTS

This software and documentation are provided with RESTRICTED RIGHTS. Use, duplication or disclosure by

the Government is subject to restrictions as set forth in subparagraph (c)(1)(ii) of the Rights in Technical

Data and Computer Software clause at DFARS 252.227-7013 and in applicable FAR provisions: Dell

Computer Corporation, One Dell Way, Round Rock, Texas, 78682, USA.

FCC emissions information

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to

Part 15 of the FCC rules.

Refer to the Drivers and Utilities CD for details.

March 2003 Rev. A01

Finding information

Software overview

Fonts

What are you looking for?

Find it here

Drivers for my printer

My User's Guide

Drivers and Utilities CD

Documentation and drivers are already installed on your printer when

shipped from Dell. You can use the CD to uninstall/reinstall drivers or

access your documentation.

Readme files may be included on your CD to provide last-minute updates

about technical changes to your printer or advanced technical reference

material for experienced users or technicians.

Safety information

How to use my printer

Warranty information

Owner's Manual

CAUTION: Read and follow all safety instructions in your

Owner's Manual prior to setting up and operating your

printer.

How to set up my printer

Setup diagram

Express Service Code and

Service Tag number

Express Service Code and Service Tag number.

The Express Service Code and Service Tag numbers are located inside

the front door of your printer.

Latest drivers for my

printer

Answers to technical

service and support

questions

Documentation for my

printer

Dell Support Website

The Dell Support Website provides several online tools, including:

Solutions - Troubleshooting hints and tips, articles from

technicians, and online courses

Upgrades - Upgrade information for components, such as memory

Customer Care - Contact information, order status, warranty, and

repair information

Downloads - Drivers

Reference - Printer documentation and product specifications

You can access Dell Support at support.dell.com. Select your region on

the WELCOME TO DELL SUPPORT page, and fill in the requested details to

access help tools and information.

Software overview

Use the Drivers and Utilities CD that came with your printer to install a combination of software applications,

depending on your operating system.

Operating System

Status

Monitor

Status

Monitor

Center

Dell Toner

Reorder

Window

Dell Printer

Software

Uninstall

Driver

Profiler

Windows 2000,

Windows XP

Windows NT

Windows 95, Windows

98, Windows Me

NOTE: If you purchased your printer and computer separately, you must use the Drivers and Utilities

CD to install these software applications.

Status Monitor

The Status Monitor alerts you when an error or warning occurs; for example, when the top cover is open or

toner is running low.

The Status Monitor launches when you send a print job to the printer and only appears on the computer

screen when an error or warning occurs.

Status Monitor Center

Use the Status Monitor Center to manage multiple Status Monitors.

Select a printer from the drop-down list and then select Run to open a Status Monitor for a particular

printer.

Select Update to change the appearance of the list of printers.

Select Help to read the online help.

Dell Toner Reorder window

The Order Toner Cartridges dialog can be launched from the Printing Status window, the Programs window,

or the desktop icon.

You can order toner by phone or from the Web.

Click Start Programs Dell Printers Dell Laser Printer M5200 Dell Printer

Supplies–Laser.

The Order Toner Cartridges window appears.

If ordering from the Web:

Choose your printer model from the drop-down list on the screen.a.

Enter your Dell printer Service Tag number in the field provided.b.

Your Service Tag number is located inside the front door of your printer.

Click Visit Dell's cartridge ordering website.c.

If ordering by phone, call the number that appears under the By Telephone heading.3.

Print Server TCP/IP Setup

Refer to your Owner's Manual for information on establishing a printer IP address.

Dell Printer Software Uninstall

Use the Uninstall software utility to remove any currently installed printer software or printer objects. You

can access the Uninstall software utility two ways:

Click Start Settings Printers.

Select the printer object to uninstall, and then right-click the mouse.a.

Select Dell Software Uninstall.b.

Select the components to uninstall, and then click Next.c.

Click Uninstall Now.d.

Click OK when the uninstall is complete.e.

Click Start Programs Dell Printers Dell Laser Printer M5200 Dell Printer Software

Uninstall.

Select the components to uninstall, and then click Next.a.

Click Uninstall Now.b.

Click OK when the uninstall is complete.c.

Driver Profiler

The Driver Profiler program and printer drivers located on the Drivers and Utilities CD are used to create

driver profiles that contain custom driver settings. A driver profile can contain a group of saved printer driver

settings and other data for things such as:

Print orientation and N-Up (document settings)

Installation status of an output tray (printer options)

User-defined paper sizes (custom papers)

Simple text and watermarks

Overlay references

Font references

Form associations

Profiles are stored in Driver Configuration Files (DCF). The individual profiles inside the DCF are identified by

a short description. During installation, the user can point to the DCF that contains the profiles to use when

creating a customized printer object.

A DCF can contain profiles for any number of printer models and any number of different drivers (PostScript

or PCL, Windows 95, Windows 98, Windows Me, Windows 2000, Windows NT® 4.0, or Windows XP). Profiles

can be added to an existing DCF by specifying an existing configuration file in the Driver Profiler when

creating a profile. New profiles are always appended to an existing configuration file. No two profiles in the

same DCF can have the same short description.

Fonts

Screen Fonts are fonts you install in Windows to match your printer scalable resident fonts. Selecting

resident printer fonts improves printing performance. The screen fonts allow the documents displayed on the

computer screen to match the output from your printer. When you install the screen fonts, you will have

access to the full set of resident printer fonts by Windows programs for PCL emulation. Choose your printer

model when prompted, and the program automatically installs the TrueType® screen fonts for your printer

in Windows.

Your printer also has five bar code fonts:

OCR-A

OCR-B

C39 Narrow (3 of 9)

C39 Regular (3 of 9)

C39 Wide (3 of 9)

Dell Printer Configuration Web Tool

Have you ever sent a print job to the network printer down the hall, only to find it didn't print because of a

paper jam or an empty paper tray? One of the features of the Dell Printer Configuration Web Tool is the

Email Alert Setup, which sends you, or the key operator, an email when the printer needs supplies or

intervention.

If you fill out printer inventory reports requiring the asset tag number of all of the printers in your area, the

Dell Printer Configuration Web Tool has a Printer Information feature that makes it easy. Just type the IP

address of each printer on the network to display the asset tag number.

The Dell Printer Configuration Web Tool feature also lets you change printer settings and keep track of

printing trends. If you are a network administrator, you can easily copy the printer's settings to one or all

printers on the network – right from your Web browser.

To launch the Dell Printer Configuration Web Tool, just type your network printer's IP address in your Web

browser.

If you do not know what your printer's IP address is, print a network setup page, which lists the IP address:

Press Menu until you see Utilities Menu, and then press Select.1.

Press Menu until you see Print Net Setup, and then press Select to print a network setup page.2.

If the IP address shows 0.0.0.0. (the factory default), an IP address has not been assigned. To assign one for

your printer, see Assign an IP address.

Use the Dell Printer Configuration Web Tool for:

Printer status

Get immediate feedback on printer supply status. When toner is running low, click the toner supplies link on

the first screen to order additional toner cartridges.

Printer settings

Change printer settings, view the operator panel remotely, and update the print server firmware.

Copy printer settings

Quickly clone the printer's settings to another printer or printers on the network just by typing each printer's

IP address.

NOTE: You must be a network administrator to use this feature.

Printing statistics

Keep track of printing trends, such as paper usage and types of jobs being printed.

Printer information

Get the information you need for service calls, inventory reports, or the status of current memory and engine

code levels.

Email alert setup

Receive an email when the printer needs supplies or intervention. Type your name or the key operator's

name in the email list box to be notified.

Set password

Lock the operator panel with a password so that other users don't inadvertently change the printer settings

you selected.

NOTE: You must be a network administrator to use this feature.

Online Help

Click Help to visit the Dell website for printer troubleshooting.
