Dell™ V305 Printer User's Guide

Finding Information

What are you looking for? Find it here

How to set up my printer Setting Up Your Printer poster

How to load printable media into my printer

How to print

How to care for and maintain my printer

How to contact Dell™

Owner's Manual

Safety information for preparing to operate

my printer

Regulatory information

Warranty information

Product Information Guide

Supported paper type and sizes

How to select and store print media

How to load printable media into my printer

How to configure printer settings

How to view and print documents and

photos from memory cards and USB keys

How to set up and use printer software

User's Guide

What are you looking for? Find it here

How to care for and maintain my printer

How to troubleshoot and solve problems NOTE: Your User's Guide is located on the Drivers and

Utilities CD or on the Web at support.dell.com.

Software and Drivers—Certified drivers for

your printer and installers for Dell printer

software

Readme files—Last minute technical

changes, or advanced technical reference

material for experienced users or technicians

Drivers and Utilities CD

NOTE: If you purchased your Dell computer and printer

at the same time, documentation and drivers for your

printer are already installed on your computer.

How to identify your printer when you use

support.dell.com or contact support

How to find the Express Service Code to

direct your call when contacting support

Service Tag and Express Code Stickers

These labels are located on your printer. For more

information about their location, see Understanding the

Printer Parts.

Solutions—Troubleshooting hints and tips,

frequently asked questions, documentation,

driver downloads, and product upgrades

Upgrades—Upgrade information for

components, such as memory, the network

cards, and optional equipment

Customer Care—Contact information, service

call and order status, warranty, and repair

information

Dell Support Website—support.dell.com

NOTE: Select your region or business segment to view

the appropriate support site.

Supplies for my printer

Accessories for my printer

Replacement ink and parts for my printer

Dell Printer Supplies Website—www.dell.com/supplies

You can purchase printer supplies online, by phone, or

in select retail stores.

AboutYourPrinter

UnderstandingthePrinterParts

Number:

Part: Description:

1 Paper support Part that supports loaded paper.

2 Paper guide Guide that helps the paper feed into the printer properly.

3 Foreign object guard Part that prevents small foreign objects from falling into the

paper path.

4 Top cover Top of printer that holds your document or photo flat while you

scan it.

5 Paper exit tray Tray that holds the paper as it exits the printer.

6 Scanner base unit Unit you lift to gain access to the ink cartridges.

7 Ink cartridge carrier Carrier that holds two ink cartridges, one color and the other

black or photo. For more information, see Replacing Ink

Cartridges.

8 Supplies Reorder Label To order ink cartridges or paper, visit www.dell.com/supplies.

9 Memory card slots Slots into which you insert a memory card containing digital

photos.

10 Express Service Code

and Service Tag

number

Identify your printer when you use support.dell.com or contact

technical support.

Enter the Express Service Code to direct your call when

contacting technical support.

NOTE: The Express Service Code is not available in all countries.

11 MAC address label Identify the media access control (MAC) address of the printer.

NOTE: Your printer model may not have wireless capability and

may not have this label.

Number:

Part: Description:

12 Dell Internal

Network Adapter A networking device to set up your printer on a wireless network.

NOTE: Your printer model may not have wireless capability and may

not have this device.

13 Power connector Slot into which you plug the power cable.

CAUTION: Insert the power cable into the printer before

connecting the power cable into the wall outlet.

14 USB connector Slot into which you plug the USB cable (sold separately). The other

end of the USB cable plugs into your computer.

Number:

Part: Description:

15 PictBridge

port The port into which you attach the connector of a PictBridge-enabled digital

camera, Bluetooth™ adapter, or a USB key.

16 Operator

panel Panel on the printer you use to control copying, scanning, and printing. For

more information, see Understanding the Operator Panel.

17 Scanner Surface on which you place your document or photo face down to copy or

Number:

Part: Description:

glass scan it.

UnderstandingtheOperatorPanel

Number

Use the: To:

1 Display

View scanning, copying, and printing options as well as status and error

messages.

2 Arrow

buttons

Scroll through modes, menus, and menu items.

Increase or decrease a numeric value option.

Scroll through photos and Microsoft®Office files on a memory card or

digital camera.

3 Back

button

Return to the previous menu.

4 Select

button

Access the currently displayed menu.

Select a menu option.

Initiate a paper feed or paper eject by holding the button for three

seconds.

5 Power

button

Turn your printer on or off.

NOTE: Pressing the power button does not turn off your printer if a

PictBridge camera with an active session is inserted into the PictBridge

port.

Number

Use the: To:

6 Cancel

button

Cancel a scan, print, or copy job in progress.

Exit a menu without saving changes to the menu settings.

7 Start

button

Initiate a copy or scan.

8 Error LED

Check if there is an error.

9 Wi-Fi LED

Check if Wi-Fi is activated:

Off indicates that the printer is not turned on.

Orange indicates that the printer is ready for wireless connection, but

not connected.

Orange blinking indicates that the printer is configured but unable to

communicate with the wireless network.

Blue indicates that the printer is connected to a wireless network.



UnderstandingtheOperatorPanelMenus

CopyMode

Main Menu Mode Main Menu

Copy Copy Color

Copies

Quality

Dark

Paper Setup

Zoom

Repeat Image

Collate

N-Up

Original Size

Original Type

ID Card Copy

To view or change the Copy Mode menu settings:

1. From the main menu, use the left and right Arrow buttons to scroll to COPY.

2. Press the Select button .

3. Use the left and right Arrow buttons until the heading you want appears on the display,

and then press the Select button .

4. Use the left and right Arrow buttons to scroll through the available menu items.

5. When the setting you want appears on the display, press the Select button to save the

setting.

Copy menu

item Settings

Copy Color *Color

Black

Copies 1–99

Quality *Automatic

Copy menu

item Settings

Draft

Normal


Dark Press the Select button , and then use the left and right Arrow buttons to

adjust the brightness setting.

Paper Setup Paper Size

Paper Type

Zoom 50%

*100%

150%

200%

Custom %

Fit to Page

2 x 2 Poster

3 x 3 Poster

4 x 4 Poster

Repeat Image *1 Per Page

4 Per Page

9 Per Page

16 Per Page

Collate *Off

N-Up *1 Up

2 Up

4 Up

Original Size *Automatic

8.5 x 11 in.

2.25 x 3.25

3 x 5 in.

3.5 x 5 in.

4 x 6 in.

4 x 8 in.

5 x 7 in.

8 x 10 in.

Hagaki

60x80 mm

Copy menu

item Settings

9x13 cm

10x15 cm

10x20 cm

13x18 cm

20x25 cm

Original Type *Text/Graphics

Text Only


ID Card Copy Place ID card on the top left scanner, and press the Arrow button to continue.

NOTE: ID Card Copy is only valid with Letter or A4 Paper.

* Default factory setting

ScanMode

The Scan Mode menu is only available if the printer is connected to a computer or a network adapter.

Main Menu Mode Main Menu

Scan Scan Color

Scan To Computer

Scan To Network

Scan To Memory Device

Quality

Original Size

To view or change the Scan Mode menu settings:

1. From the main menu, use the left and right Arrow buttons to scroll to SCAN.

2. Press the Select button .

3. Use the left and right Arrow buttons until the heading you want appears on the display,

and then press the Select button .

4. Use the left and right Arrow buttons to scroll through the available menu items.

5. When the setting you want appears on the display, press the Select button to save the

setting.

Scan menu item Settings

Scan Color *Color

Black

Scan To Computer App List

Scan To Network PC Name

Scan To Memory Device Place document on scanner, and press the right Arrow button .

Quality *Automatic

75 dpi

150 dpi

300 dpi

600 dpi

1200 dpi

Original Size *Automatic

8.5 x 11 in.

2.25 x 3.25

3 x 5 in.

3.5 x 5 in.

4 x 6 in.

4 x 8 in.

5 x 7 in.

8 x 10 in.

Hagaki

60x80 mm

9x13 cm

10x15 cm

10x20 cm

13x18 cm

20x25 cm

*Default factory setting
