Delta Electronics Exhaust Fan TFB Manuale utente

50 x 50 x 32 MM SERIES

DIMENSIONS DRAWING

(INCH)

UNIT:

P & Q CURVE (AT RATED VOLTAGE) MOUNTING PANEL CUTOUT

(INCH)

UNIT:

OUTLET SIDE INLET SIDE

*Bearing Type

*Lead Wires :

*Weight : 52g (1.83 OZ)

*Material

Ball Bearings

UL 1061 AWG #24 OR Equivalent

Red Wire Positive(+)

Black Wire Negative(-)

Impeller & Frame : Plastic(UL 94V-0)

Operating

Voltage

Range

MODEL Rated

Voltage

Maximum

Air Flow

Speed

Maximum

Air Pressure

Noise

TFB0512SHF -R00 / -F00 12 5.0 to 13.2 0.50 6.00 10000 0.842 29.76 22.32 0.879 51.5

* Function type is optional.

* The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.

* Noise is measured in anechoic chamber in free air, one meter from intake side.

* All readings are typical values at rated voltage.

* Specifications are subject to change without notice.

TFB

http://www.deltaww.com

PART NO. FUNCTION VDC VDC Amp Watt R.P.M. CFM mmH O IN H O dB-A

0.80

0.16

0.32

0.48

0.64

(IN H O)

Air Pressure

(mm H O)

Air Flow

27.0

4.0

0.48

18.09.0

0.24 0.72

12.0

8.0

20.0

16.0

(CFM)

(M /MIN)

36.0

0.96 1.20 3

0.96 TFB0512XF

24.0

Input

Power

Input

Current
