Denon PMA-30 Manuale utente

Quick Start Guide

Start Here

Starten Sie hier

Commencez ici

Iniziare qui

Iniciar aquí

Begin hier

Starta här

Начните здесь

Zacznij tutaj

INTEGRATED AMPLIFIER

PMA-30

PMA-30 Remote control unit

(built-in battery)

Caps (Silver)

Coaxial digital cable Bluetooth device

Before you begin

What’s in the box

Required for setup

Optional

Speaker systems

CD player

Speaker cables

• For more information, visit www.denon.com

• Refer to the Online Manual for other functions

information and operation procedure details.

manuals.denon.com/PMA30/EU/EN/

Français NederlandsDeutsch EspañolItaliano Svenska Pусский Polski

English

1. Orientation

Remove the feet

Unscrew the feet from the

current bottom of the unit.

Insert foot caps

Snap the silver foot caps

into the holes.

Remove black caps

From the new bottom

of the unit.

Reinstall the feet

Screw the feet into the new

bottom holes.

After attaching the feet, adjust the

height of the feet as necessary so that

the set is stable when installed.

Please keep the removed caps in a

place where you will no lose it.

1 2 3 4

NOTENOTE

Horizontal

Vertical

The feet are initially attached

to the unit for horizontal installation.

PMA-30

Connect PMA-30 to the left and right speakers.1

2. Connection

10 mm

DCD-50

(sold separately)

PMA-30

Connect the coaxial audio cable from the PMA-30 to your CD player.2

Connect the power cord from

the PMA-30 to a power outlet.

Pull out the sheet.

DIGITAL AUDIO

COAXIAL

Français NederlandsDeutsch EspañolItaliano Svenska Pусский Polski

English

Power on. Pless to change the input source

to “COAXIAL”.

Press the Play button to start playback.1 2 3

3. How to play music

Playing music from connected CD Player

Français NederlandsDeutsch EspañolItaliano Svenska Pусский Polski

English

Press for 3 seconds or longer.

・

“Pairing” will appear on the display of PMA-30.

Activate Bluetooth on your

mobile device.

Play music using any app

on your device.

Select “Denon PMA-30”

from the Bluetooth device

list on your mobile device.

・

At the end of the pairing,

the device name appears

on the display of this unit.

Playing music using Bluetooth

Bluetooth ON

PMA-30

Bluetooth

denon.com Printed in Vietnam.

5411 11546 00AD
