AVR-S500BT
AV SURROUND RECEIVER
Quick Start Guide
Read Me First....
Please do not return this unit to
the store – call for assistance.
If you need help… :
If you need additional help in solving problems,
contact Denon customer service in your area.
1-855-MY.Denon
1-855-693-3666
Call for Assistance:
Monday – Friday 10:00AM to 10:00PM E.S.T
Saturday 12:00PM to 8:00PM E.S.T
For frequently asked questions please visit
www.usa.denon.com/FAQ
For US and Canada only
PORTUGUÊS
1.AVR-S500BTE3_QSG_ENG_Suggestion_140410_Final.indd 1 2014/04/10 21:03:45
1
Thank you for choosing a Denon AV receiver. This guide
provides step-by-step instructions for setting up your AV
receiver.
Welcome Before You Begin
Required for Setup
TV HDMI cable
Speaker systems Speaker cables
1.AVR-S500BTE3_QSG_ENG_Suggestion_140410_Final.indd 1 2014/04/10 21:03:45
2
What’s In the Box
Quick Start Guide
FM indoor antenna
Safety Instructions AM loop antenna
Notes on radio Remote control
unit
Warranty
(for North America
model only)
R03/AAA batteries
Receiver Sound calibration
microphone
The supplied Sound calibration microphone stand is
convenient for use when performing Speaker Calibration.
Using your own tripod or the supplied Sound calibration
microphone stand enables settings to be automatically
configured to the optimum listening environment, providing
exceptionally high performance.
•When connecting this unit to a device that is compatible
with the Deep Color and 4K, use a “High Speed HDMI
cable with Ethernet” that comes with the HDMI logo.
•These drawings are for illustrative purposes only and may
not represent the actual product(s).
1.AVR-S500BTE3_QSG_ENG_Suggestion_140410_Final.indd 2 2014/04/10 21:03:46
3
1Installing batteries in the
remote control unit
R03/AAA batteries
There are three steps to the setup
process.
1Install batteries in the remote control unit
2Connecting the receiver
3Follow the On-Screen Setup Assistant
Setup
1.AVR-S500BTE3_QSG_ENG_Suggestion_140410_Final.indd 3 2014/04/10 21:03:47
4
2Connecting the receiver
nPlace the receiver near your TV and
connect the power cable.
TV
Receiver
Power cord
Connect to household
power outlet
(AC 120 V, 60 Hz)
1.AVR-S500BTE3_QSG_ENG_Suggestion_140410_Final.indd 4 2014/04/10 21:03:47
5
nTurn on the TV.
TV remote control unit
nSelect the appropriate HDMI input
on your TV.
HDMI TV/
VIDEO
INPUT or
TV remote control unit
nConnect the receiver to your TV with
an HDMI cable.
CLASS 2 WIRING
IMPEDANCE : 6～16Ω
SPEAKERS
CENTERFRONT SURROUND
ANTENNA
1 CBL/SAT 4 Blu-ray 5 GAME
MEDIA
PLAYER
3
DVD/
Blu-ray
2
(4K)(4K)
AUDIO
IN
AUDIO
IN
PRE OUT
CBL/SAT MEDIA
PLAYER
1
2
VIDEO
IN
VIDEO
OUT
MONITOR
SUBWOOFER
HDMI
IN
75Ω
FMAM
MONITOR
HDMI
OUT
(ASSIGNABLE)
CBL/SAT
COAXIAL
TV AUDIO
MEDIA
PLAYER
OPTICAL
1 2
DIGITAL AUDIO
IN
HDMI IN
HDMI OUT
MONITOR
MONITOR
HDMI cable
Receiver (Rear panel)
1.AVR-S500BTE3_QSG_ENG_Suggestion_140410_Final.indd 5 2014/04/10 21:03:47
6
nTurn on the receiver.
•Press Xto turn on the receiver.
nVerify the connection.
•Verify that you can see this screen on your TV.
Setup Assistant
Please select a language...
English
Français
Español
PORTUGUÊS
When this screen is not displayed, please read operation
from the beginning.
1.AVR-S500BTE3_QSG_ENG_Suggestion_140410_Final.indd 6 2014/04/10 21:03:48
7
3Follow the On-Screen Setup Assistant
The Setup Assistant will walk you through connecting and
configuring your speakers and components to your Denon
receiver. Please use the remote control and follow the
on-screen instructions.
Setup Assistant
Please select a language...
English
Français
Español
ENTER
1.AVR-S500BTE3_QSG_ENG_Suggestion_140410_Final.indd 7 2014/04/10 21:03:48
8
Owner’s Manual
•For more information, visit www.denon.com.
•Refer to the Web Manual for other
functions information and operation
procedure details.
manuals.denon.com/AVRS500BT/NA/
EN/
Introductions
Connections
Playback
Settings
Tips
Appendix
PDF Download
AV SURROUND RECEIVER
AV SURROUND RECEIVER
WEB Manual
Copyright 2014 D&M Holdings Inc. All Rights Reserved.
c
PDF
Contents
AV SURROUND RECEIVER
Web Manual
1.AVR-S500BTE3_QSG_ENG_Suggestion_140410_Final.indd 8 2014/04/10 21:03:48
www.denon.com
D&M Holdings Inc.
Printed in China 5411 11181 04AD
