Denon CEOL carino Manuale utente

CEOL carino

Computer Audio System N-2

Owner’s Manual

You can print more than one page of a PDF onto a single sheet of

paper.

Contents Connections Playback

Setting procedure

Tips Appendix

Front panel Display

Rear panel

Remote Index

Accessories 4

Before using the remote control unit 5

Operating range of the remote control unit 6

Features 7

Part names and functions 8

Front panel 8

Display 10

Rear panel 11

Remote control unit 12

Connections

Installing this unit 13

Installing horizontally 13

Installing vertically 14

Speaker installation 15

Connecting the speaker cables 16

Storing speaker cables in the speaker base 17

Connecting devices 18

Connecting the power cord 19

Playback

Basic operation 21

Turning the power on 21

Selecting the input source 22

Adjusting the master volume 22

Playing a device 23

Playing music on a computer (USB-DAC) 23

Listening to music via a analog connection (ANALOG IN) 25

Listening to music on a Bluetooth device 26

Convenient function menu 32

Wide Sound function 32

Auto Volume Adjust function 32

Setting procedure

Setting the auto standby mode 33

Turning the auto standby mode off 33

Turning the auto standby mode on 33

Turning the display on/off 33

Turning the display off 33

Turning the display on 33

Contents Connections Playback

Setting procedure

Tips Appendix

Contents

Front panel Display

Rear panel

Remote Index

Tips

Tips 35

Troubleshooting 36

Resetting to factory settings 41

Appendix

Types of playable digital audio input signals 42

Audio signals that can be input to USB-DAC 42

Playing back Bluetooth devices 42

Bluetooth communications 42

Explanation of terms 43

Trademark information 44

Specifications 45

Index 48

Contents Connections Playback

Setting procedure

Tips Appendix

Front panel Display

Rear panel

Remote Index

Thank you for purchasing this Denon product. To ensure proper operation, please read this owner’s manual carefully before using the product.

After reading this manual, be sure to keep it for future reference.

Accessories

Check that the following parts are supplied with the product.

Quick Start Guide CD-ROM (Owner’s Manual) Safety Instructions Notes on radio

Power cord USB cable

(cable length: 1.2 m)

Remote control unit (RC-1195)

(built-in battery)

CEOL carino base

Speakers (x2)

(cable length: 1.5 m)

Speaker bases (x2) Cable winders (x2)

0Stored under the speaker bases at

the time of shipment.

Contents Connections Playback

Setting procedure

Tips Appendix

Front panel Display

Rear panel

Remote Index

Before using the remote control unit

The remote control unit has a built-in lithium battery.

Pull out the insulation sheet before use.

oReplacing the battery

1. Pull out the battery case while pressing the tab.

Battery case

Ta b

2. Insert the lithium battery correctly into the battery compartment as

indicated.

3. Replace the battery case in the original position.

NOTE

0When inserting the lithium battery, be sure to do so in the proper direction,

following the F and G marks in the battery compartment.

0If the battery should have a leakage, immediately replace and dispose of the

battery. In this case, there is a risk of burn when the liquid comes in contact with

skins or clothes, so a great care should be taken. If the liquid accidentally comes in

contact, wash with tap water and consult a doctor.

0Remove the battery from the remote control unit if it will not be in use for long

periods.

Contents Connections Playback

Setting procedure

Tips Appendix

Front panel Display

Rear panel

Remote Index

Operating range of the remote control

unit

Point the remote control unit at the remote sensor when operating it.

Approx. 7 m

30°

Contents Connections Playback

Setting procedure

Tips Appendix

Front panel Display

Rear panel

Remote Index

Features

0Powerful sound with a compact body (25W + 25W high power)

You can enjoy music and games with more powerful sound on a

computer, smartphone, or tablet. Realistic sound is achieved in spite of

the compact size by combining passive radiator full range speakers that

reproduce rich bass with our unique audio processing technology and a

full digital amplifier.

0Installation possible even in a small space (v p. 13)

This unit can be placed either horizontally or vertically. Do not worry

about the installation place. You can place this unit even in a desk with

a limited space. Furthermore, convenient speaker bases are supplied

with this unit for altering the speaker angle. Adjust to your desired angle

for listening.

0Equipped with a USB-B port for upgrading audio on a computer

You can just connect a computer with this unit to enjoy content stored

on the computer and streaming content with high quality audio.

0Wireless connection with Bluetooth enabled devices (v p. 26)

You can connect Bluetooth enabled devices such as smartphones and

tablets with this unit to listen to music while browsing email and Web

sites in the Internet away from this unit. In addition, this unit supports

high quality audio codecs, aptX and AAC, to enjoy music and games

with a powerful sound.

0NFC function included that enables one touch

connection (v p. 30)

You can just touch this unit with an NFC enabled smartphone or tablet

to turn on power to this unit and establish the Bluetooth connection.

Contents Connections Playback

Setting procedure

Tips Appendix

Front panel Display

Rear panel

Remote Index

Part names and functions

Front panel

oy Q0r t i Q1

APower button/display (X)

This turns the power on/to standby. (v p. 21)

The power status is indicated as follows.

0Power on: Lit

0Standby: Off

BInput source switching key (W)

This switches input sources. (v p. 22)

CWide Sound key (S)

This switches the Wide Sound function on/off. (v p. 32)

DBluetooth key (V)

This switches the input to Bluetooth. This is also touched during the

paring operation. (v p. 27)

Contents Connections Playback

Setting procedure

Tips Appendix

Front panel Display

Rear panel

Remote Index

o Q0 Q1y

EHeadphones jack (R)

Used to connect headphones.

When the headphones are plugged into this jack, audio will no longer

be output from the speaker terminals.

NOTE

To prevent hearing loss, do not raise the volume level excessively when using

headphones.

FAuto Volume Adjust key (U)

This switches the Auto Volume Adjust function on/off. (v p. 32)

GDisplay

This displays various pieces of information.

HRemote control sensor

This receives signals from the remote control unit. (v p. 6)

IVolume adjustment wheel

This adjusts the volume level. (v p. 22)

The wheel is lit when touched.

The volume level appears on the display.

JMute button (:)

This mutes the output audio. (v p. 22)

This button flashes when muting is on.

KN mark (Q)

Touch this mark with a Bluetooth device that includes the NFC function

when paring (registering) with it. (v p. 30)

Contents Connections Playback

Setting procedure

Tips Appendix

Front panel Display

Rear panel

Remote Index

Display

AInput source indicator

The following is displayed depending on the selected input source.

USB-DAC ANALOG IN Bluetooth

. . .

BWide Sound indicator

Lit when the Wide Sound function is on.

CAuto Volume Adjust indicator

Lit when the Auto Volume Adjust function is on.

DHeadphones indicator

Lit when the headphones are used.

Contents Connections Playback

Setting procedure

Tips Appendix

Front panel Display

Rear panel

Remote Index
