MAINTENANCE AND OPERATION

INSTRUCTION MANUAL

Publish Date: 17-Jun-2016

DB44

Compact FM Radio Monitoring Receiver

and Basic Modulation Analyzer

Contents

Introduction........................................................................................................................................ 4

Typographic conventions .................................................................................................................. 5

General Information.......................................................................................................................... 6

Product Features ................................................................................................................................ 7

Technical Specications .................................................................................................................. 8

Block Diagram .............................................................................................................................. 10

Factory Default Settings .................................................................................................................. 11

Network Settings............................................................................................................................ 11

WEB Server ................................................................................................................................... 11

E-mail............................................................................................................................................ 11

Audio ............................................................................................................................................. 11

GSM MODEM............................................................................................................................... 11

SNMP Settings............................................................................................................................... 12

Management Settings .................................................................................................................... 12

Channel Presets Default Settings.................................................................................................. 13

How to reset the DB44 to its factory defaults without having access to the WEB Interface? 14

Safety Precautions............................................................................................................................ 15

Panel Indicators and Appointments ............................................................................................... 16

Front View ..................................................................................................................................... 16

Rear View ...................................................................................................................................... 17

Getting Started ................................................................................................................................ 18

Connection .................................................................................................................................... 18

Network Settings............................................................................................................................ 19

Login ............................................................................................................................................. 20

Device Control Interface ................................................................................................................. 21

Main Screen................................................................................................................................... 22

RDS/RBDS Screen......................................................................................................................... 23

ODA Screen ................................................................................................................................... 24

FM Graph Screen.......................................................................................................................... 25

MPX Screen................................................................................................................................... 26

Spectrum Analyzer Screen............................................................................................................. 27

Scope Screen.................................................................................................................................. 28

Bandscan Screen ........................................................................................................................... 29

Status Screen ................................................................................................................................. 30

LOG Screen ................................................................................................................................... 31

Settings Screen .............................................................................................................................. 32

Main Settings Screen ................................................................................................................ 32

Channel Settings Screen ........................................................................................................... 34

Alarm / Warning Triggers Dened ................................................................................................ 36

Alarm Notications ....................................................................................................................... 38

Management Screen ...................................................................................................................... 39

External GSM Modem Settings ..................................................................................................... 41

UPnP and DB44 discovery in Local Networks .............................................................................. 43

UPnP Activation ............................................................................................................................... 44

WARRANTY TERMS AND CONDITIONS................................................................................. 45

Product Registration Card.............................................................................................................. 46

THIS PAGE

IS INTENTIONALLY

LEFT BLANK

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria

Tel: +359 56 820027, Fax: +359 56 836700

E-mail: of[email protected] ,Web: www.devabroadcast.com

- 4 -

Introduction

DEVA Broadcast Ltd. is an international communications and high-technology manufacturing

organization, its corporate headquarters and facility located in Burgas, Bulgaria. The company

serves the broadcast and corporate markets worldwide – from consumers and small businesses to

the largest global organizations. It is dedicated to the research, design, development and provision

of advanced products, systems and services. DEVA launched its own brand back in 1997 and has

nowadays evolved to become known as a market leader and internationally reputed manufacturer

of user-friendly, cost-effective and innovative broadcast products.

Creativity and innovation are deeply woven into DEVA corporate culture. Through successful

engineering, marketing and management our team of dedicated professionals creates future-

oriented solutions to improve customers’ performance. You may rely that all issues communicated

to our crew would be addressed accordingly. We pride ourselves on our pre and post-sales support

and purchase services, which along with the outstanding quality of our radio gear have won us due

respect and the market authority position.

DEVA best-of-breed solutions have become the best sellers for our partners. The strategic

partnerships which have been formed with industry leaders during all these years that we have been

operating on the broadcasting market, have proved us a reliable business partner and a valuable

asset, as our dealers worldwide would conrm. In constant pursuit of precision and long-term

satisfaction, DEVA enhances the reputation of our partners and clients alike. Furthermore, we have

already a proven merit as a credible partner provider.

Our portfolio offers complete line of high quality and competitive products for FM and Digital

Radio, Radio Networks, Telecommunication Operators and regulation authorities. For almost

two decades of intensive software and hardware development, we have achieved a unique price-

performance and endurance of our product lines. Our company’s multitude of equipment and

services is in line with the latest technologies and key trends. The most recognizable characteristics

attributed to DEVA products are their clear-cut, streamlined design, easiness of use and cost-

effectiveness: simplicity of forms but multiplicity of functions.

For us there is no stage when we deem that we have reached the most satisfactory level in our

work. Our engineers are in constant pursuit of new ideas and technologies to be captured in DEVA

solutions. Simultaneously, a strict control is being exercised at each step of any new development.

Experience and hard work are our fundament but the continuous improving process is what we

never leave aside. DEVA participates on a regular basis in all landmark broadcasting events, not

only to promote its products, but to exchange valuable know-how and experience. We are also

engaged in international large-scale projects involving radio and audio solutions which makes us

even more competitive on the global market.

All DEVA products are developed and produced in accordance with the latest ISO 9001 quality

control standards.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria

Tel: +359 56 820027, Fax: +359 56 836700

E-mail: of[email protected] ,Web: www.devabroadcast.com

- 5 -

Typographic conventions

This manual uses the following typographic conventions:

Style Used for

NOTE Important notes and recommendations

Example Used when example text is cited

0 dB Menu element value

“Menu” on page XX. References

[OK] Front panel navigation and soft buttons.

WEB Interface interactive buttons.

Settings Menu element and soft button name. Menu path are represented as

follows: Settings> Security> Front Panel> Access control

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria

Tel: +359 56 820027, Fax: +359 56 836700

E-mail: of[email protected] ,Web: www.devabroadcast.com

- 6 -

General Information

Compact, Robust, Reliable and Clever - This is just a small part of all the benets of our DB44

FM Radio Monitoring Receiver and Basic Modulation Analyzer. Based on the latest technology,

the DB44 core is DSP based digital design for 24/7/365 operation.

After demodulating the FM signal, the MPX signal is digitalized and all signal processing

is then made through calculations. Digitizing in this way, at the input gives the equipment

measurement reproducibility over time. Digital lters’ accuracy, used in this equipment, enables

the FM multiplex signal’s components to be accurately and repeatedly reproduced from one device

to another, i.e. same signal applied to two devices will give the same result. The processing power

in this equipment enables all measurements to be refreshed simultaneously and synchronously,

thereby allowing for detailed readings of all the Multiplex FM signal components.

DB44 allows you through its TCP/IP and GSM Connectivity to monitor all the RDS and some

other signal parameters from anywhere. You can easily receive the channel status or listen to the

audio from anywhere, using your mobile phone. With the built-in Audio Streamer you can even

listen to, skim and record the audio from any station. DB44 is our most cost effective unit for

permanent monitoring of the quality and continuity FM Radio Stations or Radio Networks.

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria

Tel: +359 56 820027, Fax: +359 56 836700

E-mail: of[email protected] ,Web: www.devabroadcast.com

- 7 -

Product Features

• Fully DSP based core

• Built-in Oscilloscope allowing Left, Right and MPX display

• MPX Power measurement with data history

• MPX Spectrum analyzer for Left, Right and MPX measurements

• Scope with Cloud Lissajous and Star Stereo Signal Representation

• Selectable De-emphasis – 50µs and 75µs

• Built-in Stereo Decoder; Stereo Presence Detection

• Date & Time Settings for manual or automatic synchronization

• LAN port for full TCP/IP remote control and monitoring

• SNMP remote monitoring and conguration

• Up to 90dBµV direct RF Antenna Input

• Adjustable alarms for RF, Deviation, Audio, Pilot, RDS Signal and RGS Groups

• Firmware update for future-proof operation

• Parameters Factory Restore Option

• FM Band 87 - 108 MHz Basic Spectrum Analyzer

• MPX, PILOT & RDS deviation meters

• LEFT and RIGHT demodulated audio level meters

• Headphones audio output

• RDS and RBDS decoder with BER meter

• Alarm dispatch via E-mail, SMS, SNMP

• Channel status reporting via SMS

• RF and RDS Measurements

• Remote Listening via optional GSM modem

• Real Time Audio Program Streaming

• Dual level access - Administrator and User accounts

• Attractive price and very good price-performance ratio

• Very Intuitive Embedded WEB server for interactive supervision

• Proved and reliable hardware for 24/7/365 operating

• Easy Installation and Setup

• SNTP for automatic synchronization of the built-in clock

• Compact and Robust Aluminum Case for high RF immunity

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria

Tel: +359 56 820027, Fax: +359 56 836700

E-mail: of[email protected] ,Web: www.devabroadcast.com

- 8 -

TECHNICAL SPECIFICATIONS

RF INPUT

Frequency Range 87.0 to 108.0 MHz, Frequency Agile

Step Increment 50 kHz

Antenna Input 50Ω, BNC Connector, 10 dBµV sensitivity

Internal Attenuator 0, 10, 20 and 30dB, auto

Dynamic Range 0 dBµV to 100 dBµV

S/N 57dB, RF > 60dBµV, 30dB, RF > 10dBµV

METERING RESOLUTION & ACCURACY

RF Level 0 to 95 dBµV; resolution - 0.1 dBµV;

accuracy - ±1 dB (10 to 85 dBµV)

Multipath 0 to 100%; accuracy - ±1%

MPX Deviation ±120 kHz; resolution - 0.1kHz;

accuracy - ±10%, ±5% typically

MPX Power ±12 dBr; resolution - 0.1dBr, 10 sec. integration;

accuracy - ±0.2 dBr

Audio Level -50 to +5dB; resolution - 0.1dB; accuracy - ±5%

Pilot Level 0 to 12 kHz; resolution - 0.1 kHz;

accuracy - ±0.5 kHz, 1 to 12 kHz

RDS Level 0 to 9 kHz; resolution - 0.1 kHz;

accuracy - ±10% typical and not guaranteed

AUDIO, MPX, PILOT, RDS LEVELS

Validity RF level preferably > 50dBµV

Multiplex Level Peak level, 256 ksamples over 1 sec.

Audio Level Peak level, 64 ksamples over 1 sec.

Pilot Level Mean peak level, 256 ksamples over 1 sec.

RDS Level Mean peak level, 256 ksamples over 1 sec.

STEREO DECODER

Stereo Separation >25dB, typical >30dB

De-emphasis 50 or 75µs, Selectable

THD 0.5%

OUTPUTS

Audio stream Icecast/Shoutcast compatible audio stream

Alarms SMS, E-mail, SNMP

Headphone 1/8” (3.5mm) Phone Jack

GSM Modem 15-pin Male D-Sub Connector

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria

Tel: +359 56 820027, Fax: +359 56 836700

E-mail: of[email protected] ,Web: www.devabroadcast.com

- 9 -

RDS DATA DECODING

Standards European RDS CENELEC; United States RBDS NRSC

Error Correction & Counting Yes

AF Decoding Yes

CT (Time/Date) Yes

PI, PTY, DI, MS Yes

TA/TP Yes

RT (Radio Text) Yes

PS (Program Service name) Yes

PIN Yes

RT+ Yes

TMC Yes

FFT SPECTRUM ANALYSIS

Input Composite MPX, Audio

Dynamic Range 80 dB

FFT Length 1024

Sampling Rate 256 kHz - Composite, 64 kHz - Audio

SCOPE ANALYSIS

Input Composite MPX, Audio

Trigger Mode Auto, Fall

Dynamic Range ±120 kHz

Sampling Rate 256 kHz - Composite, 64 kHz - Audio

USER INTERFACE

Web interface Full monitoring and control; Interactive and easy to use

Indicators 3 LEDs (on front panel)

Headphone Output 1/8” (3.5mm) phone jack (on front panel)

TCP/IP COMMUNICATION

Type Ethernet 10/100M Base-T Port

Connector RJ45 (on rear panel)

OPERATING CONDITIONS

Temperature 10° to 60°C

EMC Immunity 6V/m

POWER REQUIREMENTS

Power Supply External, 12V/1A

SIZE AND WEIGHT

Dimensions (W x H x D) (125 x 31 x 160mm), (5” x 1.2” x 6.3”)

Shipping Weight 1,5 kg

65 Aleksandar Stamboliyski Str., 8000 Bourgas, Bulgaria

Tel: +359 56 820027, Fax: +359 56 836700

E-mail: of[email protected] ,Web: www.devabroadcast.com

- 10 -

BLOCK DIAGRAM

A simplied block diagram of DB44 is shown below

Because of the all-digital, minimalist-discrete-component nature of device circuitry, we have

not provided schematic diagrams of the DB44 in this Manual. Please, note that:

NO USER-SERVICEABLE COMPONENTS INSIDE.

REFER ALL SERVICING TO

QUALIFIED TECHNICAL PERSONNEL.

Altri manuali per DB44

Indice

Altri manuali DEVA Radio

DEVA

DEVA DB44 Manuale utente

Manuali Radio popolari di altre marche

EisSound

EisSound KBSound iSelect Manuale utente

Midland

Midland 1001LWX Manuale utente

Konig

Konig HAV-SR41 Manuale utente

Roberts

Roberts exprssion Manuale utente

VDigi

VDigi DD3.0 Manuale utente

Radio Shack

Radio Shack 21-1863 Manuale utente

Roberts

Roberts Stream 207 Manuale utente

Sony

Sony Walkman SRF-M97 Manuale utente

Stanley

Stanley FatMax FMC770 Manuale utente

auna

auna DAB-Radio 10026947 Manuale utente

SOUNDMASTER

SOUNDMASTER UR190 Manuale utente

HYT

HYT TC-320 Manuale utente

auna multimedia

auna multimedia Yellowstone 10026851 Manuale utente

B-Tech

B-Tech GMRS-V2 Manuale utente

Weierwei

Weierwei VEV-V8 Manuale utente

SOUNDMASTER

SOUNDMASTER DAB750 Manuale utente

Telefunken

Telefunken TF-1505 Manuale utente

Makita

Makita LXRM03 Manuale utente
