DH Instruments MFC SWITCHBOX Manuale utente

MFC Switchbox™

User’s Manual

High pressure liquids and gases are potentially hazardous. Energy stored in these liquids and gases

can be released unexpectedly and with extreme force. High pressure systems should be assembled

and operated only by personnel who have been instructed in proper safety practices.

Information in this document is subject to change without notice. No part of this document may be reproduced or transmitted in any

form or by any means, electronic or mechanical, for any purpose, without the express written permission of DH Instruments, a

Fluke Company 4765 East Beautiful Lane Phoenix AZ 85044-5318 USA.

DH Instruments makes sincere efforts to ensure accuracy and quality of its’ published materials; however, no warranty, expressed

or implied, is provided. DH Instruments disclaims any responsibility or liability for any direct or indirect damages resulting from the

use of the information in this manual or products described in it. Mention of any product or brand does not constitute an

endorsement by DH Instruments of that product or brand. This manual was originally composed in English and was subsequently

translated into other languages. The fidelity of the translation cannot be guaranteed. In case of conflict between the English version

and other language versions, the English version predominates.

Products described in this manual are manufactured under international patents and one or more of the following U.S. patents:

5,142,483, 5,257,640, 5,331,838, 5,445,035. Other U.S. and international patents pending.

DH Instruments, DH, DHI, MFC-CB, MFC Switchbox, molbloc and molbox1 are trademarks, registered and otherwise, of DH Instruments, a

Fluke Company

Document No. 5500092b-01

020604

Printed in the USA.

TABLE OF CONTENTS

TABLE OF CONTENTS...............................................................I

TABLES.................................................................................III

FIGURES................................................................................III

ABOUT THIS MANUAL .............................................................IV

1. INTRODUCTION .................................................................1

1.1 PRODUCT OVERVIEW ...........................................................................................................................1

1.2 LOCATION OF THE COMPONENTS......................................................................................................2

1.2.1 FRONT PANEL..............................................................................................................................................2

1.2.2 REAR PANEL ................................................................................................................................................2

1.3 1.3 SUBASSEMBLY DESCRIPTION.......................................................................................................2

1.3.1 POWER SUPPLY...........................................................................................................................................2

1.3.2 RELAY BOARD .............................................................................................................................................2

1.3.3 FRONT PANEL ASSEMBLY.........................................................................................................................3

1.3.4 REAR PANEL ASSEMBLY ...........................................................................................................................3

1.4 SPECIFICATIONS ...................................................................................................................................3

1.4.1 GENERAL SPECIFICATIONS.......................................................................................................................3

1.4.2 MFC CONTROL FUNCTION SPECIFICATIONS ..........................................................................................3

1.4.2.1 MOLBOX1 OR MFC-CB MFC PORT.........................................................................................................3

1.4.2.2 MFC PORT 1 (DEVICE 1)..........................................................................................................................3

1.4.2.3 MFC / MFM PORT 2 - 5 (DEVICE 2 - DEVICE 5)......................................................................................4

1.4.2.4 MFC SWITCHBOX CONTROL (DIGITAL CONTROL FROM MOLBOX OR MFC-CB).............................4

2. INSTALLATION ..................................................................5

2.1 UNPACKING AND INSPECTION ............................................................................................................5

2.2 SITE REQUIREMENTS............................................................................................................................5

2.3 INITIAL SETUP........................................................................................................................................5

2.3.1 POWER CONNECTION.................................................................................................................................5

2.3.2 CONNECTING THE MFC SWITCHBOX TO A MOLBOX1 ...........................................................................5

2.3.3 CONNECTING THE MFC SWITCHBOX TO THE DEVICE TO BE CALIBRATED.......................................5

3. OPERATION.......................................................................7

3.1 OVERVIEW..............................................................................................................................................7

3.2 GENERAL OPERATION..........................................................................................................................7

3.3 MFC PROFILES.......................................................................................................................................8

3.4 UNITS OF MEASURE..............................................................................................................................8

4. REMOTE OPERATION .........................................................9

4.1 OVERVIEW..............................................................................................................................................9

5. MAINTENANCE AND ADJUSTMENTS .................................. 11

5.1 OVERVIEW............................................................................................................................................11

MFC SWITCHBOX USER’S MANUAL

6. TROUBLESHOOTING ........................................................ 13

6.1 SYMPTOMS / CAUSES / SOLUTIONS.................................................................................................13

7. MENU TREE..................................................................... 15

7.1 OVERVIEW............................................................................................................................................15

7.2 MOLBOX1 OR MFC-CB MFC FUNCTION KEY....................................................................................15

7.3 MOLBOX1 OR MFC-CB SETUP MENU................................................................................................15

8. WARRANTY STATEMENT .................................................. 17

TABLES AND FIGURES

Table 1. Troubleshooting Checklist ...........................................................................................................13

Table 2. DHI Authorized Service Providers...............................................................................................17

Figure 1. Front Panel ...................................................................................................................................2

Figure 2. Rear Panel....................................................................................................................................2

MFC SWITCHBOX USER’S MANUAL

Manual Conventions

(CAUTION) is used in throughout the manual to identify user warnings and cautions.

(NOTE) is used throughout the manual to identify operating and applications advice and

additional explanations.

[ ] indicates direct function keys (e.g., [RANGE]).

< > indicates PG7000 screen displays (e.g., <1yes>).

1. INTRODUCTION

1.1 PRODUCT OVERVIEW

The MFC Switchbox™ can be used to connect a molbox1™ MFC control option or an MFC-CB™ control

channel to up to five MFCs, or to one MFC and four MFMs. The rear panel of the MFC Switchbox

connects to the molbox1 or MFC-CB via a circular 5-pin connector and a 25-pin DSUB connector.

Cables are provided with the switchbox to facilitate these connections. A power cable is also provided.

The MFC Switchbox contains its own power supply which allows it to maintain continuous power on all

five devices under test (DUTs). The MFC Switchbox provides up to 55 watts of power. This allows it to

provide 260 mA per MFC when fully loaded. MFCs typically require a maximum of 200 mA. Therefore,

all five ports of the MFC Switchbox can be used simultaneously in most situations. Occasionally, when

calibrating older, power hungry MFCs, it may only be feasible to connect four MFCs at a time.

The front panel of the MFC Switchbox has five 25-pin DSUB connectors. These connectors are used to

connect the switchbox to the various DUTs.

Current controlled MFCs can only be used on channel 1. When testing MFMs, an MFC can be used for

controlling the flow in the test while taking the measurement data from the currently selected MFM.

This controlling MFC must be a voltage based MFC.

MFC SWITCHBOX USER’S MANUAL

1.2 LOCATION OF THE COMPONENTS

1.2.1 FRONT PANEL

1. Connection

point for DUT 2

2. Connection

point for DUT 4

3. Connection

point for DUT 5

4. Connection

point for DUT 3

5. Connection

point for DUT 1

Figure 1.Front Panel

1.2.2 REAR PANEL

1. External

Drivers

Connection

2. Fan

3. Power Entry

4. Product Label

5. Electrical

Connection

Figure 2. Rear Panel

1.3 1.3 SUBASSEMBLY DESCRIPTION

1.3.1 POWER SUPPLY

Powers the electronics inside the MFC Switchbox and provides continuous power to up to

five connected DUTs. The switching power supply provides +5 volts at 0.5 amps and +15

volts at 4 amps. This 15 volt signal is converted via a DC-to-DC converter to -15 volts at 1.3

amps (leaving approximately 2 amps for the +15 volt signal). The enclosure is cooled by

active air circulation using a fan on the rear panel.

1.3.2 RELAY BOARD

Provides the control and signal switching required to connect (one at a time) up to five DUTs

to the molbox’s single MFC port.

1. INTRODUCTION

1.3.3 FRONT PANEL ASSEMBLY

Provides connecting ports for up to five DUTs.

1.3.4 REAR PANEL ASSEMBLY

Supports power, signal communication with molbox1 or MFC-CB, control communication with

molbox1 or MFC-CB and carries the cooling fan.

1.4 SPECIFICATIONS

1.4.1 GENERAL SPECIFICATIONS

Power Requirements 85 to 264 VAC, 50/60 Hz, 55 VA maximum consumption

Weight 1.5 kg (3.25 lb)

Dimensions 22.5 cm W x 7.5 cm H x 20.0 D (8.85 in. x 2.95 in. x 7.87 in.)

1.4.2 MFC CONTROL FUNCTION SPECIFICATIONS

The MFC Switchbox works with any MFC that can be used with the molbox1 or MFC-CB.

The switchbox provides the MFCs with continuous power, but the molbox1 or MFC-CB still

provides all the control and measurement. For detailed specifications regarding MFC control

please refer to specifications section of the molbox1 or MFC-CB Operation and Maintenance

Manual.

Current based MFCs can only be used when connected to device 1 of the MFC Switchbox.

It is not possible to switch between multiple current based MFCs.

The Valve Test Point signal is only available on device 1 of the MFC Switchbox.

1.4.2.1 MOLBOX1 OR MFC-CB MFC PORT

Connector One 25 Pin Female DSUB Metal Case Socket (Back Panel)

Signals (16) +15 VDC

-15 VDC

Power Supply Common

Setpoint Voltage (0 to 5 VDC)

Setpoint Common

MFC Measure (0 to 5 VDC)

MFC Measure Common

Setpoint Sense (0 to 5 VDC)

Setpoint Sense Common

Valve Test

Valve Test Common

Setpoint Current (4 to 20 mA Output)

MFC Measure (4 to 20 mA Input)

Case Ground (Earth Ground)

RS485 TXRX+

RS485 TXRX-

1.4.2.2 MFC PORT 1 (DEVICE 1)

Connector One 25 Pin Female DSUB Metal Case Socket (Front Panel Device 1)

Signals (16) +15 VDC

-15 VDC

Power Supply Common

Setpoint Voltage (0 to 5 VDC)

Setpoint Common

MFC Measure (0 to 5 VDC)

MFC Measure Common

Setpoint Sense Common

Valve Test

Valve Test Common

Setpoint Current (4 to 20 mA Output)

MFC Measure (4 to 20 mA Input)

Case Ground (Earth Ground)

RS485 TXRX+

MFC SWITCHBOX USER’S MANUAL

Setpoint Sense (0 to 5 VDC) RS485 TXRX-

1.4.2.3 MFC / MFM PORT 2 - 5 (DEVICE 2 - DEVICE 5)

Connector Four 25 Pin Female DSUB Metal Case Socket (Front Panel)

Signals (16) +15 VDC

-15 VDC

Power Supply Common

Setpoint Voltage (0 to 5 VDC)

Setpoint Common

Setpoint Sense Common

MFC Measure (0 to 5 VDC)

MFC Measure Common

Setpoint Sense (0 to 5 VDC)

Case Ground (Earth Ground)

1.4.2.4 MFC SWITCHBOX CONTROL (DIGITAL CONTROL

FROM MOLBOX OR MFC-CB)

Connector One 5 Pin Female Socket (Back Panel)

Signals Clock for Shift Register

Data Line for Shift Register Load Latch for Shift Register

Ground
