Digital Projection E-Vision Laser 15000 Series Scheda tecnica

Rev B April2021

E-Vision Laser 15000 Series

High Brightness Digital Video Projector

INSTALLATION & QUICK START GUIDE

CONNECTION GUIDE

OPERATING GUIDE

REFERENCE GUIDE

121-000B

DigitalProjection E-Vision Laser15000 Series Introduction

Introduction

Congratulations on your purchase of this Digital Projection product. Your projector has the following key features:

lWUXGA native resolution delivering 15,000 ISO lumens.

lSupport for Frame Sequential 3D.

lSupport for Dual Pipe 3D format.

lHDBaseT® for transmission of uncompressed High Definition Video up to 100 m from the source.

l3G-SDI with loop-through.

lEdge Blend with black level correction.

lRed laser assist for enhanced color fidelity.

lBlanking control for custom input window sizing.

lCornerstone, Vertical & Horizontal Keystone, Pincushion & Barrel, and Image Rotation.

lControl via LAN HDBaseT and RS232.

lMotorised lens mount with Shift, Zoom and Focus using compatible lenses.

lSeparate control of screen and source aspect ratio.

A serial number is located on the side of the projector. Please record it here for future reference:

Follow the instructions in this manual carefully to ensure safe and long-lasting use of the projector.

Rev B April2021

page 2

Introduction

Notes

Aboutthis document DigitalProjection E-Vision Laser15000 Series

About this document

Symbols used in this document

Many pages in this document have a dedicated area for notes. The information in that area is accompanied by the following symbols:

LASER WARNING: this symbol indicates that there is a potential hazard of eye exposure to laser radiation unless the instructions are closely followed.

LIGHT HAZARD WARNING: this symbol indicates that there is a danger of exposure to intensive light that may result in personal injury unless the instructions are closely followed.

ELECTRICAL WARNING: this symbol indicates that there is a danger of electrical shock unless the instructions are closely followed.

WARNING: this symbol indicates that there is a danger of physical injury to yourself and/or damage to the equipment unless the instructions are closely followed.

NOTE: this symbol indicates that there is some important information that you should read.

Product revision

Because we at Digital Projection continually strive to improve our products, we may change specifications and designs, and add new features without prior

notice.

Additional Documentation

Updates to this manual may be available online.

Please use the QR code (also located on the projector) to access the latest E-Vision projector user guides and other documentation via the Digital

Projection website.

Or visit the products specification page on the Digital Projection website to download the latest user guide and other documentation.

Legal notice

Trademarks and trade names mentioned in this document remain the property of their respective owners. Digital Projection disclaims any proprietary interest in

trademarks and trade names other than its own.

Third Party Credits

Art-NetTM Designed by and Copyright Artistic License Holdings Ltd.

Introduction Rev B April2021

page 3

Notes

DigitalProjection E-Vision Laser15000 Series Electrical and PhysicalSpecifications

Electrical and Physical Specifications

Mains Voltage 200-240 VAC 8.2A 50/60Hz

100-130 VAC 11.9A 50/60Hz

Operating Temperature 0°C to 35°C (32°F to 95°F), 35°C to 40°C (95°F to 104°F) with reduced light output

Storage Temperature -20°C to 60°C (-4°F to 140°F)

Operating Humidity 10% to 90% non-condensing

Storage Humidity 10% to 90% non-condensing

Dimensions L:598.3mm (23.55in) X W: 500mm (19.68in) X H 218.5mm (8.6in)

Weight 29.5 kg (65 lb) without lens

Power Consumption at 110 VAC: 1025 W (Normal mode)

at 110 VAC: 990 W (Eco mode)

at 110 VAC: 1070 W (High Altitude mode)

at 240 VAC: 1570 W (Normal mode)

at 240 VAC: 1165 W (Eco mode)

at 240 VAC: 1590 W (High Altitude mode)

Standby Power < 0.5W (Network Off), < 6W (Network On)

Thermal Dissipation at 110 VAC: 3497 BTU/hr (Normal mode)

at 110 VAC: 3378 BTU/hr (Eco mode)

at 110 VAC: 3650 BTU/hr (High Altitude mode)

at 240 VAC: 5357 BTU/hr (Normal mode)

at 240 VAC: 3975 BTU/hr (Eco mode)

at 240 VAC: 5425 BTU/hr (High Altitude mode)

Fan Noise 48 dBA Max, 46 dBA Typical (Normal mode)

45 dBA Max, 43 dBA Typical (Eco mode)

59 dBA Max, 57 dBA Typical (High Altitude mode)

48 dBA Max, 46 dBA Typical (High Altitude Quiet mode)

Specifications are subject to change without notice.

Laser Parameters

Wavelength (Red) 635nm - 647nm

Wavelength (Blue) 450nm - 460nm

Mode of operation Pulsed, due to frame rate

Pulse duration (Red) 1.6ms

Pulse duration (Blue) 0.87ms

Maximum pulse energy (Red) 0.72mJ

Maximum pulse energy (Blue) 0.45mJ

Rev B April2021

page 4

Introduction

Notes

Compliance with InternationalStandards DigitalProjection E-Vision Laser 15000 Series

Compliance with International Standards

RF Interference

FCC

The Federal Communications Commission does not allow any modifications or changes to the unit EXCEPT those specified by Digital Projection in this manual.

Failure to comply with this government regulation could void your right to operate this equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant with Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference

to radio communications. Operation of this equipment in a residential area may cause harmful interference, in which case the user will be responsible for

correcting any interference.

Noise

GSGV Acoustic Noise Information Ordinance

The sound pressure level is less than 48 dB (A) at normal operating mode according to ISO 3744 or ISO 7779.

European Waste Electrical and Electronic Equipment (WEEE) Directive

Digital Projection Ltd is fully committed to minimising Waste Electrical and Electronic Equipment. Our products are designed with reuse, recycling and

recovery of all components in mind. To this end, at end of life, your projector may be returned to Digital Projection Ltd or its agent so that the

environmental impact can be minimised.

Introduction Rev B April2021

page 5

Notes

DigitalProjection E-Vision Laser15000 Series Contents

Introduction 2

About this document 3

Symbols used in this document 3

Product revision 3

Additional Documentation 3

Legal notice 3

Third Party Credits 3

Electrical and Physical Specifications 4

Laser Parameters 4

Compliance with International Standards 5

RF Interference 5

Noise 5

European Waste Electrical and Electronic Equipment (WEEE) Directive 5

Contents 6

General Precautions 10

What's in the box? 12

Projector overview 13

Location of Laser Aperture 14

Interlock Switches 15

Installation Precautions 16

Laser Safety Precautions 19

Risk Group 3 Laser Hazard Installation Precautions 20

Light Hazard Warning 20

Light Hazard Distance and Hazard Zone 20

Fitting a lens 21

Inserting a new lens 21

Removing the lens 22

Fitting a lens hood 23

Positioning the screen and projector 24

Power Supply 25

AC Power Precautions 25

Connecting the power supply 26

Voltage selection 26

Operating the projector 27

Control panel 27

Projector indicators 28

Remote control 29

Infrared reception 33

Switching the projector on 33

Switching the projector off 33

Interlock reset 33

Selecting an input signal 34

Selecting a test pattern 34

Adjusting the lens 35

Adjusting the image 35

Orientation 35

Geometry 35

Picture 35

Signal inputs 38

Digital inputs and outputs 38

EDID on the DisplayPort, HDMI, and HDBaseT inputs 39

Using DisplayPort / HDMI / HDBaseT switchers with the projector 39

Analog inputs and outputs 40

3D connections 41

3D frame packed, side-by-side and top and bottom formats 42

Frame sequential 42

Dual Pipe (Left/Right) 42

3D Sync 43

Control connections 44

LAN connection examples 45

RS232 connection example 46

Using the menus 48

Opening the Menu 48

Opening a submenu 48

Exiting menus and closing the OSD 49

Inside a menu 49

Accessing sub menus 50

Executing commands 50

Rev B April2021

page 6

Introduction

Notes

Contents

Contents DigitalProjection E-Vision Laser15000 Series

Editing projector settings 51

Using a slider to set a value 51

Editing numeric values 52

Using the projector 53

Main Menu 53

Lens menu 54

Lens control 54

Lens memory 55

Image 56

Position and Phase 57

Color 58

Color Space 58

Color Mode 59

ColorMax 59

Manual Color Matching 60

Color matching parameters explained 61

Color Temperature 62

Gains and Lifts 62

Geometry 63

Aspect Ratio 63

Theaterscope setting 64

Digital Zoom 65

Overscan 66

Blanking 67

Keystone 68

4 Corners 71

Top right corner example 72

Rotation 73

Rotation example 74

Pincushion / Barrel 75

Pincushion/ Barrel example 75

Arc 76

Custom Warp 77

Warp Filter 78

Edge Blend 79

Blend Start 80

Blend Width 81

Black Level Uplift 82

3D 83

3D types 84

Some 3D settings explained 85

Dark Time 85

Eye Swap 85

Sync Offset 86

Laser 87

Setup 88

ColorMax 90

Measured data/ target data 90

Power on/off 91

Clock Adjust 92

OSD Settings 92

Memory 93

Network 94

Network Setup 94

Art-Net Setup 95

Art-Net Channel Setting 95

PIP 96

Information 97

Signal Format 97

System Status 98

Thermal Status 98

Factory Reset 99

Served web pages 100

Appendix A: Product labels 110

Projector 110

Label Locations 111

Projector 111

Appendix B: Choosing a lens 112

Basic calculation 113

Basic calculation example 114

Full lens calculation 115

Introducing TRC 115

Calculating TRC 116

TRC table 116

Calculating the throw ratio with TRC 116

Full lens calculation example 117

Appendix C: Screen requirements 118

Fitting the image to the display 118

WUXGA images displayed full width 118

Introduction Rev B April2021

page 7

Notes

DigitalProjection E-Vision Laser15000 Series Contents

WUXGA images displayed with a height of 1200 pixels 118

WUXGA images displayed full height 119

Diagonal screen sizes 119

Appendix D: Positioning the image 120

Appendix E: Aspect ratios explained 121

Aspect ratios examples 121

Source: 4:3 121

Source: 16:9 122

Source: 16:10 (native) 122

Aspect ratio example: TheatreScope 123

Appendix F: Supported signal input modes 124

2D formats 124

3D formats 127

Appendix G: Wiring details 130

Signal inputs and outputs 130

HDMI 130

DisplayPort 131

3G-SDI in, 3G-SDI out 132

HDBaseT input 132

DVI-D input 133

VGA input 134

Control connections 134

LAN 134

RS232 135

Trigger 135

Appendix H: Glossary of terms 136

Rev B April2021

page 8

Introduction

Notes

Rev B April2021

E-Vision Laser 15000 Series

High Brightness Digital Video Projector

INSTALLATION & QUICK START GUIDE

121-000B

DigitalProjection E-Vision Laser15000 Series GeneralPrecautions

General Precautions

Warning! Death or Serious Injury could occur if the following precautions are ignored

Eye Hazard! Do not look directly into the lens when the light source is on. The high brightness can cause permanent eye damage

Fire Hazard! Keep any combustible material away from hot surfaces and the projected beam. Ensure cables do not contact hot surfaces

Shock Hazard! Use only authorised components, tools, accessories and replacement parts specified by the manufacturer

Trip Hazard! Locate cables where they cannot be pulled, tripped over or damaged by persons or objects

Operate the product in the specified operating environment and conditions

Product should be powered off and disconnected from the mains before any service or maintenance operation

Keep body parts, hair, clothing and jewellery away from moving parts in the product.

Do not operate the product without a lens installed

Use a lens plug when installing or moving the product

The unit is never to be operated if the unit is defective or the cover or seal is damaged.

No maintenance allowed by end user.

Do not open the cabinet. There are no user serviceable parts inside.

No service is allowed except by authorized personnel.

Use only the power cable provided.

Ensure that the power outlet includes a Ground connection, as this equipment MUST be earthed.

Take care to prevent small objects such as paper or wire from falling into the projector. If this does happen, switch off immediately, and have the

objects removed by authorised service personnel.

Do not expose the projector to rain or moisture, and do not place any liquids on top of the projector.

Unplug before cleaning, and use a damp, not wet, cloth.

Do not touch the power plug with wet hands.

Do not touch the power plug during a thunder storm.

Handle the power cable carefully and avoid sharp bends. Do not use a damaged power cable.

Rev B April2021

page 10

Introduction

Notes

Altri manuali per E-Vision Laser 15000 Series

Indice

Altri manuali Digital Projection Proiettore

Digital Projection

Digital Projection M-Vision Cine 320 Series Manuale utente

Digital Projection

Digital Projection TITAN SX+ 330-L Manuale utente

Digital Projection

Digital Projection Titan Pro Series III Manuale utente

Digital Projection

Digital Projection Titan series Manuale utente

Digital Projection

Digital Projection HIGHlite 6000 Manuale utente

Digital Projection

Digital Projection M-Vision Laser 18K Series Manuale utente

Digital Projection

Digital Projection Titan 1080p-500 Manuale utente

Digital Projection

Digital Projection TITAN Quad 1080p-3D Manuale utente

Digital Projection

Digital Projection E-Vision Laser 7500 Series Manuale utente

Digital Projection

Digital Projection LIGHTNING 30-1080p Manuale utente

Digital Projection

Digital Projection HIGHlite Cine 330 3D Series Manuale utente

Digital Projection

Digital Projection TITAN sx+ 3D Manuale utente

Digital Projection

Digital Projection HIGHlite 660 3D Series Manuale utente

Digital Projection

Digital Projection TITAN 1080p-600 Manuale utente

Digital Projection

Digital Projection TITAN Quad 1080p-3D Manuale utente

Digital Projection

Digital Projection E-Vision Laser 4K Series Manuale utente

Digital Projection

Digital Projection TheaterScope System Manuale utente

Digital Projection

Digital Projection HIGHlite Laser 4K Series Manuale utente

Digital Projection

Digital Projection Titan 800 3D series Manuale utente

Digital Projection

Digital Projection dVision 30sx+ Manuale utente

Digital Projection

Digital Projection M-Vision Laser 21000 WU Manuale operativo

Digital Projection

Digital Projection M-Vision Cine 320 3D series Manuale utente

Digital Projection

Digital Projection M-Vision 1080p-260 series Manuale utente

Digital Projection

Digital Projection Titan 930 Manuale utente

Manuali Proiettore popolari di altre marche

iEmmet

iEmmet MP-312 Manuale utente

Epson

Epson VS400 Manuale utente

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuale utente

Sony

Sony VPL-HW65ES Manuale di servizio

Toshiba

Toshiba TLP-791U Manuale utente

Philips

Philips LC1341 Guida di riferimento

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuale utente

NEC

NEC NP600S EDU Manuale utente

BenQ

BenQ SH753P Manuale utente

Eiki

Eiki EK-623U series Manuale utente

Epson

Epson PowerLite Pro Cinema 6020UB Manuale utente

Epson

Epson PowerLite Home Cinema 705HD Manuale utente

Christie

Christie LHD700 Manuale utente

Navitar

Navitar FX Manuale utente

InFocus

InFocus LitePro 560 Manuale utente

Sony

Sony SRX-R815P Manuale utente

Vivitar

Vivitar DP1500 X Manuale utente

Acer

Acer C20 Series Manuale utente
